Image preview - the first page of the document



>> Download Disassembling-Complete-Disassembly-2952 documenatation <<

Text preview - extract from the document

IBM ThinkPad T42 Teardown




                      IBM ThinkPad T42 Teardown
         Tools used in this guide
             Small Flathead Screwdriver
             Small Phillips Screw Driver



                                             Step 1 - Complete Disassembly
                                               Removing the battery
                                                    Unplug the power cable before removing the
                                                    battery.
                                                    Slide the 2 sliders on the under side of the laptop
                                                    to the unlock position, as shown.
                                                    Grasp the battery and pull it straight out - not at
                                                    an angle.
