Image preview - the first page of the document



>> Download 1502237_PC_XT_Technical_Reference_Apr83 documenatation <<

Text preview - extract from the document

                            LIMITED WARRANTY

The International Business Machines Corporation warrants this IBM Personal
Computer Product to be in good working order for a period of 90 days from the
date of purchase from IBM or an authorized IBM Personal Computer dealer.
Should this Product fail to be in good working order at any time during this
90-day warranty period, IBM wilL at its option, repair or replace this Product
at no additional charge except as set forth below. Repair parts and replacement
Products will be furnished on an exchange basis and will be either reconditioned
or new. All replaced parts and Products become the property of IBM. This
limited warranty does not include service to repair damage to the Product
resulting from accident, disaster, misuse. abuse, or non-IBM modification of
the Product.

Limited Warranty service may be obtained by delivering the Product during the
90-day warranty period to an authorized IBM Personal Computer dealer or IBM
Service Center and providing proof of purchase date. If this Product is delivered
by mail, you agree to insure the Product or assume the risk of loss or damage in
transit, to prepay shipping charges to thc warranty service location and to use the
original shipping container or equivalent. Contact an authorized IBM Personal
Computer dealer or write to IBM Personal Computer. Sales and Service, P.O.
Box I328-W, Boca Raton, Florida 33432. for further information.

ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT
INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO A
PERIOD OF 90 DAYS FROM THE DATE OF PURCHASE, AND NO
WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER
THIS PERIOD. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS. SO THE ABOVE LIMIT ATIONS
MA Y NOT APPLY TO YOu.

IF THIS PRODUCT IS NOT IN GOOD WORKING ORDER AS WARRANTED
ABOVE, YOUR SOLE REMEDY SHALL BE REPAIR OR REPLACEMENT
AS PROVIDED ABOVE. IN NO EVENT WILL IBM BE LIABLE TO YOU FOR
ANY DAMAGES, INCLUDING ANY LOST PROFITS, LOST SAVINGS OR
OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF
THE USE OF OR INABILITY TO USE SUCH PRODUCT, EVEN IF IBM OR
AN AUTHORIZED IBM PERSONAL COMPUTER DEALER HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR FOR ANY
CLAIM BY ANY OTHER PARTY.

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMIT A TION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR CONSUMER
PRODUCTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT
APPLY TO YOU.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO ST ATE.
- -- --
-- - -
- - --
  -
- -- -
       -
           Personal Computer XT
- - ----
 -
--_.-
-    ---
     --    Hardware Reference
           Library




Technical
Reference
FEDERAL COMMUNICATIONS COMMISSION
        RADIO FREQUENCY INTERFERENCE
                                 STATEMENT




W ARNIN G:            This equipment has been certified to comply with
                      the limits for a Class B computing device,
                      pursuant to Subpart J of Part 15 of FCC rules,
                      Only peripherals (computer input/output devices,
                      terminals, printers, etc.) certified to comply with
                      the Class B limits may be attached to this
                      computer. Operation with non-certified
                      peripherals is likely to result in interference to
                      radio and TV reception.

Notice: As sold by the manufacturer, the IBM Prototype Card
does not require certification under the FCC's rules for Class B
devices. The user is responsible for any interference to radio or TV
reception which may be caused by a user-modified prototype card.

CAUTION:             This product is equipped with a UL-listed and
                     CSA-certified plug for the user's safety. It is to be
                     used in conjunction with a properly grounded
                     115 Vac receptacle to avoid electrical shock.



Revised Edition (April 1983)

Changes are periodically made to the information herein; these changes will be
incorporated in new editions of this publication.

Products are not stocked at the address below. Requests for copies of this product and for
technical information about the system should be made to your authorized IBM Personal
Computer dealer.

A Reader's Comment Form is provided at the back of this publication. If this form has
been removed, address comments to: IBM Corp., Personal Computer, P.O. Box 1328-C,
Boca Raton, Florida 33432. IBM may use or distribute any of the information you supply
in any way it believes appropriate without incurring any obligations whatever.
