Image preview - the first page of the document
IC7000


>> Download IC7000 documenatation <<

Text preview - extract from the document
     SERVICE
     MANUAL


HF/VHF/UHF ALL MODE TRANSCEIVER




S-14214HZ-C1
Dec. 2005
                    INTRODUCTION                                                              DANGER
This service manual describes the latest service information           NEVER connect the transceiver to an AC outlet or to a DC
for the IC-7000 HF/VHF/UHF ALL MODE TRANSCEIVER                        power supply that uses more than 16 V. Such a connection
at the time of publication.                                            could cause a fire or electric hazard.
      VER.NO.          VERSION                   SYMBOL                DO NOT expose the transceiver to rain, snow or any liquids.
        #02              Europe                    EUR
        #03              France                    FRA                 DO NOT reverse the polarities of the power supply when
        #04               Spain                    ESP                 connecting the transceiver.
        #05               U.S.A.                   USA
        #08               Export                   EXP                 DO NOT apply an RF signal of more than 20 dBm (100 mW)
        #10          United Kingdom                 UK                 to the antenna connector. This could damage the trans-
                                                                       ceiver's front end.
To upgrade quality, all electrical or mechanical parts and internal
circuits are subject to change without notice or obligation.




                 ORDERING PARTS                                                          REPAIR NOTES
Be sure to include the following four points when ordering             1. Make sure the problem is internal before disassembling
replacement parts:                                                        the transceiver.
                                                                       2. DO NOT open the transceiver until the transceiver is
1.   10-digit Icom parts number                                           disconnected from its power source.
2.   Component name and informations                                   3. DO NOT force any of the variable components. Turn
3.   Equipment model name and unit name                                   them slowly and smoothly.
4.   Quantity required                                                 4. DO NOT short any circuits or electronic parts. An
                                                                          insulated turning tool MUST be used for all adjustments.
                                                         5. DO NOT keep power ON for a long time when the
                                                                          transceiver is defective.
5030002820 LCD   LTA025A161A        IC-7000      Front unit 5 pieces   6. DO NOT transmit power into a signal generator or a
8810009610 Screw FH M2.6
