Image preview - the first page of the document
IC-T2H_SM


>> Download IC-T2H_SM documenatation <<

Text preview - extract from the document
144 MHz FM TRANSCEIVER

iC-t2h
iC-t2e-t
                    INTRODUCTION
This service manual describes the latest service information for
the IC-T2H/E-T FM TRANSCEIVER at the time of publication.

        MODEL             VERSION                SYMBOL
                              U.S.A.               USA
                            Europe                 EUR
                               U.K.                 UK
        IC-T2H                 Italy                ITA
                              Asia                 SEA
                       C.S. America/-1            CSA/-1
                            Taiwan                 TWN
                              Asia-1                ANI
        IC-T2E-T           Thailand                THA
To upgrade quality, all electrical or mechanical parts and inter-
nal circuits are subject to change without notice or obligation.


                         DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 16 V. Such a connection
could cause a fire hazard and/or electric shock.

DO NOT expose the transceiver to rain, snow or any liq-
uids.

DO NOT reverse the polarities of the power supply when
connecting the transceiver.

DO NOT apply an RF signal of more than 20 dBm (100
mW) to the antenna connector. This could damage the
transceiver's front end.



                   ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required


1140006560 S.IC HD6433875A45H IC-T2H        MAIN UNIT 1 piece
8810009560 Screw B0 2
