Image preview - the first page of the document
>> Download PRX Series Interface PCB Parts List documenatation <<
Text preview - extract from the document
138927-1 REV. 3 PWA, MRX SPEAKER INTERFACE MAMPJB0
REVISION HISTORY
E.C.N REV DESCRIPTION DATE DWN PE CM
INITIAL RELEASE DERIVED FROM 138927-1 REV. 1 WITH THE
2 FOLLOWING CHANGES: ADDED W3A-W3H. REMOVED W1, 12/06/05 KLW EB
W2, WP101, WP102, WP201, WP202, WP301, & WP302.
INITIAL RELEASE DERIVED FROM 138927-1 REV. 2 WITH THE
3 12/30/05 KLW EB
FOLLOWING CHANGE: UPDATED NOTE 1 TO REV 3.
UNLESS OTHERWISE SPECIFIED, THIS PRINTED WIRING ASSEMBLY SHALL MEET
THE SPECIFICATION DESCRIBED IN IPC-A-610_ CLASS 2 STANDARDS.
NOTES:
1. PRINTED WIRING BOARD PART NUMBER 138926-1 REV 3.
2. SEE 138927-1_3.TIF FOR SCHEMATIC AND COMPONENT MAP
3. ALL LEADS SHALL BE TRIMMED TO 0.125" OR LESS.
4. POSITION COMPONENTS AS SHOWN ON COMPONENT MAP.
5. THE PRINTED WIRING ASSEMBLY PART NUMBER FOR THIS ASSEMBLY SHALL
BE MARKED ON THE PRINTED WIRING BOARD.
6. MAP LOCATIONS DENOTED BY AN ASTERISK (*), INDICATE COMPONENTS
MOUNTED ON THE BOTTOM SIDE OF THE PRINTED WIRING BOARD.
UNCONTROLLED
UNLESS OTHERWISE MARKED IN RED INK BY CM AS A CONTROLLED COPY, COPIES OF THESE DOCUMENTS
INCLUDING ASSOCIATED ELECTRONIC REPRODUCTIONS ARE FOR REFERENCE ONLY
THESE DRAW INGS AND SPECIFICATIONS ARE THE PROPERTY OF CROWN INTERNATIONAL, INC. AND SHALL NOT BE
REPRODUCED, COPIED, OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES
WITHOUT PERMISSION.
DWN KLW 12/30/05 PE EB 12/30/05 CM DIST.
FR2 Spk Interface Bom 138927-1_3.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 1 OF 3
138927-1 REV. 3 PWA, MRX SPEAKER INTERFACE MAMPJB0
REF. DES. CPN DESCRIPTION MAP LOC.
C98 A11369-102J2 .001UF 50V 5% NPO MLC 0805 T/R C1
C99 A11369-102J2 .001UF 50V 5% NPO MLC 0805 T/R C1
C186 A11369-102J2 .001UF 50V 5% NPO MLC 0805 T/R C1
C187 A11369-102J2 .001UF 50V 5% NPO MLC 0805 T/R C1
C286 A11369-102J2 .001UF 50V 5% NPO MLC 0805 T/R B1
C287 A11369-102J2 .001UF 50V 5% NPO MLC 0805 T/R B1
C386 A11369-102J2 .001UF 50V 5% NPO MLC 0805 T/R B1
C387 A11369-102J2 .001UF 50V 5% NPO MLC 0805 T/R B1
J99 138974-1 CONN, 8 PIN MOLEX MINI-FIT JR. B 1*
PWB1 138926-1 PWB, MRX SPEAKER INTERFACE A1
W3A WIRE PAD 16GA C1
W3B WIRE PAD 16GA C1
W3C WIRE PAD 16GA B1
W3D WIRE PAD 16GA B1
W3E WIRE PAD 16GA B1
W3F WIRE PAD 16GA B1
W3G WIRE PAD 16GA C1
W3H WIRE PAD 16GA C1
FR2 Spk Interface Bom 138927-1_3.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 2 OF 3
138927-1 REV. 3 PWA, MRX SPEAKER INTERFACE MAMPJB0
Count of CPN
CPN Total
(blank) 0
138926-1 1
138974-1 1
A11369-102J2 8
Grand Total 10
FR2 Spk Interface Bom 138927-1_3.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 3 OF 3
