Image preview - the first page of the document
>> Download 22 documenatation <<
Text preview - extract from the document
367
2-2-1 Paper misfeed detection
When a paper misfeed occurs, the copier immediately stops copying and displays a
message announcing the paper misfeed on the operation unit touch panel, indicating
the location of the misfeed and shows how to remove the misfed paper. Paper misfeed
counts sorted by the detection conditions can be checked by misfeed code in simulation
74.
To remove paper misfed in the copier, open the cassette, paper feed cover or front
cover.
When paper is misfed in the RDH, open the RDH cover or the RDH eject cover to
remove the misfed paper.
To clear a misfeed in the feedshift and duplex sections, open the eject cover or draw
duplex unit.
To reset the paper misfeed detection, open and close the front, eject or paper feed
cover to turn each safety switch off and on. To reset the paper misfeed detection, open
and close the RDH cover, RDH reverse cover or RDH eject cover to turn each safety
switch off and on. The detection of misfeeds in the feedshift and duplex sections can be
reset by reinserting the duplex unit or opening and closing the eject cover to turn the
eject cover safety switch off and on.
5
3
4 2
6
1
1 Paper feed section
2 Paper conveying section
3 Fixing and eject section
4 Feedshift and duplex sections (duplex unit)
5 RDH
6 Sorter
Figure 2-2-1 Misfeed location indication
2-2-1
DC5090S/M(2-2MCE)# 1 10/31/97, 09:34
367
2-2-2 Paper misfeed detection conditions
( 1 ) Paper feed, conveying, fixing and eject sections
ESW FCL1
RCL
RSW FSW BYPCL
FCL2
PFSW1
FCL3
PFSW2
LPDPPSENS2 LPDPPSENS1
LPDPFCL2 LPDCCL LPDPFCL1
FCL4
PFSW3
FCL5
PFCL-U PFSW4
FCL6
PFCL-L PFSW5
Figure 2-2-2 Paper feed, conveying, fixing and eject sections
2-2-2
DC5090S/M(2-2MCE)# 2 10/31/97, 09:34
367
1. Paper feed section
