Image preview - the first page of the document
>> Download INDEX509 documenatation <<
Text preview - extract from the document
INDEX 367/183-1
367/183
Quantity Quantity
Part. No. Description Fig. No. Part. No. Description Fig. No.
230V 240V 230V 240V
18300140 LOWER EJECT PULLEY ASS'Y 2 2 41 18307110 SHAFT,SEPARATION PULLEY 1 1 39
18302080 SHEET,MAIN PCB 1 1 42 18307140 STAY,SEPARATION BELT 1 1 38
18303010 LEFT HINGE 1 1 42 18307150 SHAFT,JOINT PAPER FEED 1 1 42
18303020 RIGHT HINGE 1 1 42 18307170 PRESSING PLATE,ORIGINAL PAPER FEED 2 2 39
18303030 SUPPORT BAR,HINGE 2 2 42 18307190 MOUNT SOL,PRESSURE 1 1 39
18303040 MOUNT,DF SAFETY SWITCH 1 1 42 18307200 FRONT FULCRUM PLATE,SEPARATION BELT 1 1 38
18303050 LEVER,DF SAFETY SWITCH 1 1 42 18307210 REAR FULCRUM PLATE,SEPARATION BELT 1 1 38
18304010 FRONT COVER 1 1 36 18307220 FRONT POSITIONING PLATE,SEPARATION 1 1 39
18304020 REAR COVER 1 1 36 18307230 REAR POSITIONING PLATE,SEPARATION 1 1 39
18304030 COVER,PAPER FEED 1 1 36 18307240 MOUNT,CONVEYING SWITCH 1 1 39
18304040 COVER,EJECT 1 1 36 18307250 MOUNT,SAFETY SWITCH 1 1 39
18304050 INNER REAR COVER 1 1 36 18307260 LEVER,PRESSING PLATE SOLENOID 1 1 39
18304070 COVER,LED 1 1 36 18307270 JUNCTION PLATE,PRESSURE SOLENOID 1 1 39
18305030 LABEL,ORIGINAL INDICATION (EUR) 1 1 36 18307280 UPPER FEED GUIDE,PAPER FEED 2 2 38
18306010 TABLE,ORIGINAL 1 1 37 18307290 HOLDER,SEPARATION SHAFT 2 2 38
18306020 FRONT CURSOR 1 1 37 18307300 PULLEY 20P2M,MOTOR 1 1 42
18306030 REAR CURSOR 1 1 37 18307310 PULLEY 34/18P2M,JOINT 1 1 42
18306040 LEFT RACK,TABLE 1 1 37 18307320 PULLEY 40/20,REGISTRATION 1 1 42
18306050 RACK,TABLE MIDDLE 1 1 37 18307330 GEAR 36,JOINT 1 1 42
18306060 RIGHT RACK,TABLE 1 1 37 18307340 PULLEY 26P2M/22,SEPARATION 1 1 42
18306070 GEAR,TABLE 2 2 37 18307350 GEAR 26,SEPARATION 1 1 39
18306080 ADJUSTING PLATE,CURSOR 1 1 37 18307360 PULLEY 32P2M,PAPER FEED 1 1 39
18306090 MOUNT,PULLEY 1 1 37 18307370 PULLEY 25/18P2M,PAPER FEED 1 1 39
18306100 MOUNT,SIZE SENSOR 2 2 37 18307380 PULLEY 28P2M,JOINT 1 1 42
18306110 GUIDE,MOVING 1 1 37 18307390 BELT 166,LEADING FEED 1 1 39
18306120 MOUNT,MOVING SENSOR 1 1 37 18307410 MOUNT,ORIGINAL SET SW 2 2 39
18306130 PROJECTION,RACK 2 2 37 18307420 MOUNT,MOTOR PAPER FEED 1 1 42
18306140 COVER,RACK 2 2 37 18307430 MOUNT,SEPARATION PIN 1 1 42
18306150 RIGHT SHEET,TABLE WIRE 1 1 37 18307450 SHEET ,PAPER FEED/ LOOP 1 1 38
18306160 LEFT SHEET,TABLE WIRE 1 1 37 18307470 RETAINER,SEPARATION BELT 2 2 38
18306170 MOUNT,MOVING PULLEY 1 1 37 18307480 PROJECTION,LEADING FEED DRIVE 1 1 39
18307010 HOUSING,PAPER FEED 1 1 38 18307490 SPRING,PAPER FEED PRESSURE 1 1 39
18307020 REINFORCEMENT,PAPER FEED 1 1 39 18307510 GUIDE ,REGISTRATION/ LOOP 1 1 38
18307030 GUIDE,PAPER FEED 1 1 39 18307520 BELT 146,JOINT 1 1 42
18307040 GUIDE,REGISTRATION 1 1 39 18307530 SPRING,HOOK PAPER FEED 2 2 39
18307050 HOOK,PAPER FEED 2 2 39 18307540 FRONT FULCRUM PLATE,REGISTRATION GUIDE 1 1 38
18307060 MOUNT SOL,STOPPER 1 1 39 18307550 PULLEY 18P2M,LEADING FEED 1 1 39
18307070 STOPPER,ORIGINAL SET 1 1 39 18307560 LEVER,SAFETY SWITCH 1 1 38
18307090 SHAFT,PAPER FEED 2 2 39 18307570 PULLEY,PAPER FEED 2 2 39
18307100 SHAFT,PRESSING PLATE PAPER FEED 1 1 39 18307580 PULLEY,SEPARATION 1 1 39
