Kyocera Duplexer DU-25 Parts Manual


>> Download Kyocera Duplexer DU-25 Parts Manual documenatation <<

Text preview - extract from the document
                                    Printer Options


                                    DU-25




      PARTS CATALOGUE
                                       16-12-1998


Printer Options - Parts Catalogue      KYOCERA DU-25   Page 1
DU-25 Parts Catalogue
Table of Contents

Covers (Fig.1)                                                                    3
Handler/Stacker (Fig.3)                                                           6
Duplex Drawer Outer (Fig.4a)                                                      8
Duplex Drawer Inner (Fig.4b)                                                     10

Introduction

The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:

'Ref No.'          Reference number which corresponds to the parts in the figure
'Part code'                                   Part code which identifies the part
'Part description'                                 A brief description of the part
'Quantity'                      Quantity of the part used in the printer or option

Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.




Printer Options - Parts Catalogue   KYOCERA DU-25                            Page 2
                                                                                02-005

                                                                                                                                                                          01-005
Printer Options - Parts Catalogue




                                                                                                                                           02-032

                                                                                                                                                      02-005

                                                                                                                                                                                                                           01-008
                                                                                                   02-019
                                                                                                                                                                                   02-010

                                                                                                                     02-019




                                                                                                                                                                                       02-006


                                                                                 02-014




                                                                                                                                                    02-030
                                                                       02-035



                                                                                                                                                                                                    02-007
                                                                                                                                                                                                                                         02-011
KYOCERA DU-25




                                                              02-003
                                    Fig.1 - Covers




                                                                                                            02-015                                                                                 02-008
                                                                                                                                 02-013


                                                                                                                                                                                                02-029

                                                                                                     02-016                                             02-020

                                                                                                                                           02-024
                                                                                                                                                                                                         02-034


                                                                                                            02-033
                                                                                         02-009                                                                    02-027




                                                                                                                              02-031



                                                     02-012                               02-017


                                                                                                                                                                 02-028




                                                                                                                                                                                                                                02-004
Page 3




                                                                                                                                  02-001                                                                          02-012
Ref No.       Part Code             Description            Quantity

01-001        5MVB876SH057          LEFT COVER FEED               1
01-002        5MVB876SH058          RIGHT COVER FEED              1
01-003        5MVX876SH019          REAR COVER FEED               1
01-004        5SNSP0012409          JUNCTION PLATE COVER          1
01-005        5SNSP0012382          PROTECTING PLATE COR          1
01-006        5SNSP0012384          LEFT SUPPORT PLATE            1
01-007        5SNSP0012385          RIGHT SUPPORT PLATE           1
01-008        5SNSP0012389          REAR COVER                    1
01-009        5SNSP0012433          MAGNET LOOP SECTION           1
01-010        5MBTPB3006TZ          BIND T.T.SCREW(+)             1

02-000        5SNSADU25J02          BASE ASSY                     1
02-001        5MML993SL001          BASE DUPLEX MACHINE           1
02-002        5MMS986SL017          UPPER REINFORCEMENT           1
02-003        5MVB966SH007          LEFT COVER FRAME              1
02-004        5MVB966SH008          RIGHT COVER FRAME             1
02-005        5MVX721SH001          COVER HANDLE                  1
02-006        5SNSP0012353          UPPER GUIDE                   1
02-007        5SNSP0012354          LOWER GUIDE                   1
02-008        5SNSP0012355          PROTECTING PLATE POW          1
02-009        5SNSP0012356          MOUNT DRAWER                  1
02-010        5SNSP0012357          LEFT FRAME                    1
02-011        5SNSP0012358          RIGHT FRAME TURNOVER          1
02-012        5SNSP0012359          SPACER DUPLEX                 1
02-013        5SNSP0012381          MOUNT SAFETY SWITCH           1
02-014        5SNSP0012394          WIRE JUNCTION BOX             1
02-015        5SNSP0012396          WIRE SAFETY SWITCH            1
02-016        5SNSP0012397          UPPER WIRE JUNCTION           1
02-017        5SNSP0012398          LOWER WIRE JUNCTION           1
02-018        5SNSP0012408          RETAINING PIN DRAWER          1
02-019        5SNSP0012411          PLATE SPRING A                1
02-020        5SNSP0012412          LOWER GROUND PLATE            1
02-021        5SNSP0012417          CUSHION CONTACT               1
02-022        5SNSP0012419          RETAINING PIN DRAWER          1
02-023        5SNSP0012423          SAFTEY SWITCH                 1
02-024        5SNSP0012438          CASSETTE CATCHER              1
02-025        5SNSP0012443          BINDING BAND PLTIM
02-026        5SNSP0012448          EDGING EDS-1208U              1
02-027        5SNSP0012449          SPACER KGPS-4S                1
02-028        5SNSP0012450          CORNER POST KGCP-80           1
02-029        5SNSP0012451          WIRE SADDLE LWS-3S            1
02-030        5SNSP0012452          WIRE SADDLE LWS-2NS           1
02-031        5SNSP0012400          WIRE DRAWER                   1
02-032        5SNSP0012463          EDGING CE-012                 1
02-033        5SNSP0012464          WIRE SADDLE LSW8S             1


Printer Options - Parts Catalogue   KYOCERA DU-25              Page 4
Ref No.       Part Code             Description         Quantity

02-034        5AAPRCZC1006AH        MOTOR CONTROL PWB          1
02-035        5AAPRIFC1022AH        DRIVER PWB                 1




Printer Options - Parts Catalogue   KYOCERA DU-25           Page 5
                                                                                                                                                                                                                           03-028
                                                              01-001                                                                                                                        03-006
                                                                                                                            03-005
Printer Options - Parts Catalogue




                                                                                                                                                                                                                                                                                    01-003

                                                                                                                        03-012                                                                                                        01-009
                                                                                                                                                                                                                           03-034


                                                                                                          03-025   03-003
                                                                                             03-024
                                                                                                                   03-027




                                                                                             03-025                                  03-023


                                                                                                                                                                                                                       01-006

                                                                                                                                                            03-018

                                                                                    03-025
                                                                                                                                                                03-008

                                                                                                                                                                         03-003
                                                                                                                                                                                   03-026

                                                                                                                                                                                                                                                             01-004
                                                                                                                                 03-010
                                    Fig.3 - Handler/Stacker




                                                                                                                                                       03-007                                                               03-024
KYOCERA DU-25




                                                                                                                                                                                                                                      03-023


                                                                                                                                                                                                                                                                                             03-007
                                                                                                                                              03-004                                                                                                                       03-031
                                                                                                                                                                                                                                                           03-022

                                                                                                                                                                                                                                                    03-030
                                                                                   03-009
                                                                                                                                                                                              03-011                                                    03-025


                                                                                                                                                                                                                                                                          03-002

                                                                         03-008                                                                                                                                                                                                                       03-015
                                                                                                                                                                                                                                    03-025


                                                                                                                                                                                                                                                    03-002
                                                                                                                                                                          03-032
                                                                                                                                                                                                                                                                 03-024
                                                                          03-008
                                                                                                                                                          03-001                            03-036                                                 03-023                      01-002
                                                                                                                                                                          03-033




                                                                                                      03-029
                                                                                                                                                 03-035


                                                                                                                                                                                                     03-038
                                                                                                                             03-021                                                                                                            03-013
                                                                                                                                                                                                                            03-036
                                                                                                                                                                                                                                                  03-019
Page 6




                                                                03-014
                                                                                                                                                                                       03-017
                                                                                                                                                                                                              03-016




                                                                                                                                                                                                                                03-037
Ref No.       Part Code             Description            Quantity

03-001        5MMX876SL023          GUIDE EJECT                   1
03-002        5MVG348DN004          PULEY 38MXL                   1
03-003        5MVX521DN003          HOOK FEED SHIFT               1
03-004        5MVX863CN001          GUIDE CONVEYING               1
03-005        5MVX863SH014          UPPER COVER LED               1
03-006        5MVB875SH021          UPPER COVER RELEASE           1
03-007        5SNSP0012374          UPPER ROLER FEED              1
03-008        5SNSP0012375          LOWER ROLLER FEED             1
03-009        5SNSP0012376          UPPER GUIDE EJECT             1
03-010        5SNSP0012377          LEFT FRAM FEED                1
03-011        5SNSP0012378          RIGHT FRAME FEED              1
03-012        5SNSP0012379          SHAFT RELEASE LEVER           1
03-013        5SNSP0012380          MOUNT REED SHIFT              1
03-014        5SNSP0012383          PROTECTING PLATE ACT          1
03-015        5SNSP0012386          BELT 224 MXL 4.8              1
03-016        5SNSP0012387          PROTECTING PLATE DRI          1
03-017        5SNSP0012388          PROTECTING PLATE WIR          1
03-018        5SNSP0012390          HANDLE FEED SHIFT             1
03-019        5SNSP0012393          MOTOR DUPLEX FEED             1
03-020        5SNSP0012395          WIRE CN4                      1
03-021        5SNSP0012403          WIRE 1 SWITCH                 1
03-022        5SNSP0012410          TENSION PLATE PAPER           1
03-023        5SNSP0012413          BUSHING 6                     1
03-024        5SNSP0012415          PRESSING SPRING FEED          1
03-025        5SNSP0012416          BUSHING 6 REGIST              1
03-026        5SNSP0012420          SPING SIDE REGIST             1
03-027        5SNSP0012422          STOP RING 4                   1
03-028        5SNSP0012426          PLATE SPRING DUPLEX           1
03-029        5SNSP0012429          SWITCH DUPLEX                 1
03-030        5SNSP0012431          SPRING BLADE                  1
03-031        5SNSP0012432          TENSION PULLEY 20             1
03-032        5SNSP0012434          SPRING REVERSE                1
03-033        5SNSP0012435          SOLENOID LOOP                 1
03-034        5SNSP0012437          PAPER CONVEYING PULL          1
03-035        5SNSP0012440          MINIATURE CLAMP UAMS          1
03-036        5SNSP0012444          BINDING BANDSG-130            1
03-037        5SNSP0012445          MINIATURE CLAMP UAMS          1
03-038        5SNSP0012447          EDGING EDS-2                  1




Printer Options - Parts Catalogue   KYOCERA DU-25              Page 7
                                                                                                                                              04-001
Printer Options - Parts Catalogue




                                                                                                                   04-003



                                                                   04-005




                                                                                                      04-023




                                                                                                                                               04-002
                                                                            04-023                                     04-019



                                                                                                                   04-004


                                                                                        04-050
                                    Fig.4a - Duplex Drawer Outer




                                                                                                          04-014
KYOCERA DU-25




                                                                                                 04-023




                                                                               04-008                                                                   04-007
Page 8




                                                                                                                                04-052




                                                                                                                                     04-024
Ref No.       Part Code             Description            Quantity

04-001        5MVB872SB023          UPPER REAR GUIDE              1
04-002        5MVG873SB049          LOWER REAR GUIDE              1
04-003        5MVX875SC001          UPPER FRONT GUIDE             1
04-004        5MVX873SC001          LOWER FRONT GUIDE             1
04-005        5MVB766CB001          COVER CONVEYING MOTO          1
04-007        5MVB762SB066          WIRE COVER                    1
04-008        5MVB966SH006          FRONT COVER                   1
04-014        5SNSP0012365          MOUNT MOTOR                   1
04-019        5SNSP0012370          MAGNET CONVEYING COV          1
04-023        5SNSP0012392          MOTOR DUPLEX CONVEY           3
04-024        5SNSP0012399          WIRE LED                      1
04-050        5SNSP0012445          MINIATURE CLAMP UAMS          1
04-052        5AAPRLDC1003AH        LED PWB                       1




Printer Options - Parts Catalogue   KYOCERA DU-25              Page 9
                                                                                                                                  04-033


                                                                                                                                                                                                                                         04-027
                                                                                                                                                    04-031

                                                                                                                                                             04-018
                                                                                              04-006
                                                                                                                             04-038

                                                                                                        04-038
Printer Options - Parts Catalogue




                                                                                                                                                                                                                                                   04-011
                                                                                                                                                                          04-010
                                                                                               04-042
                                                                   04-053


                                                                                04-034



                                                                                                                                                              04-047


                                                                                                                                                                                              04-020
                                                                            04-031                                                         04-047
                                                                                                                                                                        04-010


                                                                                                                                                                                                                                                                            04-033

                                                                                                                                      04-013                                                                                                                                             04-031
                                                                                                                                                               04-022


                                                                                                                                                                                                                                                                          04-038

                                                                                                                    04-012                                                                                                                                                                04-040
                                    Fig.4b - Duplex Drawer Inner




                                                                                                                             04-035
                                                                                     04-021                                                                                               04-047
KYOCERA DU-25




                                                                                                                                                                                                                                                      04-033
                                                                   04-010                                                                                                                                                                                     04-031


                                                                                                                                                                                                                                                                                04-039             04-043
                                                                                                                                                                                                                          04-050                            04-038




                                                                                                                                                                                                                                04-049               04-040
                                                                                                                                                                                                                                                                       04-036
                                                                                                                                                                                                                                                  04-033                                                    04-016

                                                                                                                                                                                 04-017
                                                                                                                                                                                                                                                  04-042
                                                                                                                                               04-051
                                                                                                                                                                                          04-033            04-031
                                                                                                                                                                                                                     04-031
                                                                                                                 04-050                                                                                                       04-037




                                                                                                                                       04-041                             04-044                   04-034




                                                                                                                                                                                    04-015
Page 10




                                                                                                           04-009




                                                                                                                                                                                   04-050
Ref No.       Part Code             Description            Quantity

04-006        5MVG147DN015          DRIVE GEAR 38                 1
04-009        5SNSP0012360          INNER ROLLER CONVEYI          1
04-010        5SNSP0012361          UPPER ROLLER CONVEYI          1
04-011        5SNSP0012362          GUIDE SUPPORT PLATE           1
04-012        5SNSP0012363          GUIDE FEED SHIFT              1
04-013        5SNSP0012364          ROLLER 30 CONVEYING           1
04-015        5SNSP0012366          GUIDE SWITCH MOUNT            1
04-016        5SNSP0012367          BELT 170MXL4.8                1
04-017        5SNSP0012368          RIGHT FRAME                   1
04-018        5SNSP0012369          LEFT FRAME                    1
04-020        5SNSP0012371          REAR ROLLER CONVEYIN          1
04-021        5SNSP0012372          ROLLER CONVEYING EJE          1
04-022        5SNSP0012373          FRONT ROLLER CONVEY           1
04-025        5SNSP0012401          WIRE A TURNOVER               1
04-026        5SNSP0012402          WIRE B TURNOVER               1
04-027        5SNSP0012404          WIRE 3 SWITCH                 1
04-028        5SNSP0012405          WIRE B MOTOR CONVEYI          1
04-029        5SNSP0012406          WIRE MOTOR REVERSE            1
04-030        5SNSP0012407          WIRE MOTOR EJECT              1
04-031        5SNSP0012413          BUSHING 6                     1
04-032        5SNSP0012414          PIN ORIGINAL HOLDER           1
04-033        5SNSP0012415          PRESSING SPRING FEED          1
04-034        5SNSP0012416          BUSHING 6 REGIST              1
04-035        5SNSP0012418          SWITCH VERTICAL CONV          1
04-036        5SNSP0012421          SPRING PAPER EJECT            1
04-037        5SNSP0012424          GEAR 15 AGITATION             1
04-038        5SNSP0012425          BUSHING 8                     1
04-039        5SNSP0012427          TENSION PLATE DUPLEX          1
04-040        5SNSP0012428          PULLEY 20 DUPLEX              1
04-041        5SNSP0012429          SWITCH DUPLEX                 1
04-042        5SNSP0012430          BUSHING 8 PF                  1
04-043        5SNSP0012436          TIMING PULLEY 30              1
04-044        5SNSP0012439          CASSETTE STOPPER              1
04-045        5SNSP0012440          MINIATURE CLAMP UAMS          1
04-046        5SNSP0012442          CLAMP UAMS-09-0               1
04-047        5SNSP0012442          EDGING EDS-0607U              1
04-048        5SNSP0012443          BINDING BAND PLTIM            1
04-049        5SNSP0012444          BINDING BAND SG-130           1
04-051        5SNSP0012446          PLUG QR/P15-40S               1
04-053        5AAVGEAR*032          GEAR 38 ASSY                  1




Printer Options - Parts Catalogue   KYOCERA DU-25             Page 11



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
