Image preview - the first page of the document
Kyocera Duplexer DU-30 Parts Manual


>> Download Kyocera Duplexer DU-30 Parts Manual documenatation <<

Text preview - extract from the document
                                   PRINTER OPTION


                                    DU-30




     PARTS CATALOGUE

PRINTER OPTION - Parts Catalogue       KYOCERA DU-30   Page 1
DU-30 Parts Catalogue
Table of Contents

DU-30 Duplex Unit (Fig.30)                                                       3

Introduction

The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:

'Ref No.'          Reference number which corresponds to the parts in the figure
'Part code'                                   Part code which identifies the part
'Part description'                                 A brief description of the part
'Quantity'                      Quantity of the part used in the printer or option

Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.




PRINTER OPTION - Parts Catalogue   KYOCERA DU-30                             Page 2
                                                                                                 30-046


                                                                                            30-047
                                                                                                                                                                                                                                                                                                                                                       30-092

                                                                          30-045                                                                                                                                                                                                             30-067
PRINTER OPTION - Parts Catalogue




                                                                                                                                                                                                                                                                          30-064
                                                                                                                                  30-046
                                                                                                                                                                                                  30-034                                                    30-069             30-056
                                                                30-048                                                                                                                                                                            30-068
                                                                                                                       30-047
                                                                                                                                                                   30-088                                                              30-097

                                                                                                                                                                                                                                                                30-058
                                                                                                                                                                                                                                                                                                                           30-066
                                                                                                                                                                                                                    30-044     30-028                 30-098
                                                                                                                                                                                                                                               30-065     30-061

                                                                                                                                                                                                                                                                                    30-059
                                                                                                                                                                                                                                                                                                                                    30-043
                                                                                                                                                                                                                                                     30-060                        30-062
                                                                                                                                                                                          30-102
                                                                                                                                                                                                                                      30-095

                                                                                                                                                              30-095                                                                                                                                  30-063      30-094
                                                                                                                                                                                                                                                               30-074                                                                                           30-037

                                                                                                                                                                                                                             30-023                                                                30-027
                                                                 30-044                                                                             30-094
                                                                                                                                                                                                                                               30-057                                                                                                                                30-091
                                                                                                                                                                                                                                                                                          30-039
                                                                                                                                               30-005                                                                                      30-014
                                                                                                                                                             30-002
                                                                                                                                                                                                                                                                        30-104
                                                                                                                                                                                                                               30-013                                                                                                                                             30-035
                                                                                                                                                         30-028                                                                                             30-075
                                                                                                                       30-081
                                                                              30-087                      30-083                                                                                                                                                                          30-037
                                   Fig.30 - DU-30 Duplex Unit




                                                                                                                                          30-103                                                           30-017                                                             30-100
                                                                                                                                                                                                                                                            30-086
                                                                                                                                                                                                                                                   30-029
                                                                                                                                                                                                                                                                         30-030
KYOCERA DU-30




                                                                                                                                                                                                                                                                                            30-006                                                     30-038                     30-042
                                                                                                            30-080

                                                                                                                                                                                                                                                                                                                30-041
                                                                                                                                                                                                                                                                                                                                30-040
                                                                                                                                                                                 30-101
                                                                                                                                                                                     30-032                                                       30-015                                               30-027
                                                                                                                                                                                                                                                                                 30-026
                                                                                                                                                                                                           30-016
                                                                                                              30-082                                                                              30-089
                                                                                       30-012
                                                                                                                        30-105                 30-004
                                                                                                                                                                                                                                                                                                                           30-007
                                                                                                                                                             30-096                                                                                                  30-001                                                                   30-024

                                                                                                                                                                                                                                                                                 30-107
                                                                                                                                           30-008                                                                                                                                                      30-036
                                                                                                                                                                  30-029
                                                                                                                                 30-009
                                                                                                                                                          30-010             30-030                                                                                                                               30-025
                                                                     30-093

                                                                                                                                                                                                                             30-108                                                                                           30-051
                                                                                                                                                    30-009                                                                                                                                                                                                               30-050
                                                                                                                                                                            30-008             30-003       30-011
                                                                                                                                                                                                                                                                                                                30-049

                                                                                                                                                                                                                              30-018
                                                                                                                                                                                               30-084                                                                                                                                             30-053
                                                                                                             30-077

                                                                                                                                                                                                30-100                       30-019
                                                                                                                                                                                                                                                                                                                                                  30-052
                                                                                        30-076                                                                      30-085
                                                                                                                                                                                                                                                                                                                                         30-055
                                                                                                                                                                                                                                                                                                                  30-054
Page 3




                                                                                                                                                                                         30-104                                                                                           30-079




                                                                                                                                                                                 30-020


                                                                                                                                                                                              30-090
                                                                                                                                                                                                                                               30-078
                                                                                                                                                30-021
Ref No.      Part Code             Description              Quantity

30-000       DU-30                 Duplex Unit                     1
30-001       5MVB886SB008          Frame Main DU                   1
30-002       5MMT866SN026          Shaft L                         1
30-003       5MMM121CX001          Bush Drum                       1
30-004       5MVG1216DN012         Pulley P18                      1
30-005       5AAPRCZR2005AH        PWB Assy                        1
30-006       5AAVCLTCH009          Clutch Assy                     1
30-007       5MMT876SN053          Shaft M                         1
30-008       5MVG337DN004          Pulley P24                      1
30-009       5MVF182DN001          Cover Pulley                    1
30-010       5MVM190RB020          Belt S2M328                     1
30-011       5MMS852LD001          Plate Earth A                   1
30-012       5MVB865SB040          Cover Front DU                  1
30-013       5MVM460DB001          Roller Idle                     1
30-014       5MMT555SN001          Shaft B                         1
30-015       5MMW155LD001          Spring Bottom                   1
30-016       5MVB843SB002          Guide Paper R                   1
30-017       5MVB843SB003          Guide Paper L                   1
30-018       5MVB822DW001          Rack DU                         1
30-019       5MVG147DN010          Gear Z25-P36                    1
30-020       5MVM190RB024          Belt S2M426                     1
30-021       5MVB883SB014          Frame Bottom DU                 1
30-023       5EYYAFAAM01**02       Spring Clutch                   1
30-024       5MVM687DB001          Roller Guide                    1
30-025       5MMT866SN024          Shaft S                         1
30-026       5MMM176CJ003          Metal Bush KD                   1
30-027       5MVM190RB021          Belt S2M 630                    1
30-028       5MMM121CX001          Bush Drum                       1
30-029       5MMM121CX001          Bush Drum                       1
30-030       5MMM121CX001          Bush Drum                       1
30-032       5ENXGP1A73A**01       Photo Sencor                    1
30-034       5MVB873SB048          Plate Paper                     1
30-035       5MVB873CC001          Plate Bottom                    1
30-036       5MMT876SN053          Shaft M                         1
30-037       5MMM121CX001          Bush Drum                       1
30-038       5ENXGP1A73A**01       PT. Sencor                      1
30-039       5MVX433DB004          Actuator H                      1
30-040       5MVX433DB003          Actuator S                      1
30-041       5AACCNQF1GEA          Conn. Cord Assy S02099          1
30-042       5MVB753SB020          Cover PB                        1
30-043       5MVS522KC003          Sheet BU                        1
30-044       5MVB882CC001          Plate Top                       1
30-045       5MVM687DB001          Roller Guide                    1
30-046       5MMW521LX001          Spring PA                       1
30-047       5MVM374DN001          Pulley PA                       1


PRINTER OPTION - Parts Catalogue   KYOCERA DU-30                Page 4
Ref No.      Part Code             Description            Quantity

30-048       5MMT666SN002          Shaft P                       1
30-049       5MVB662DW001          Guide Turn                    1
30-050       5MMT866SN025          Shaft PI                      1
30-051       5MMT666SN001          Shaft PU                      1
30-052       5MVM190RB019          Belt S2M 124                  1
30-053       5AAROLL*034           Torque Limiter                1
30-054       5AAVROLL*036          Roller DU Assy                1
30-055       5AAYDU30**09          Roller Return Assy            1
30-056       5MMX776SD003          Plate Drive A                 1
30-057       5MMS766SD005          Plate Drive B                 1
30-058       5MVG158DN024          Gear H50-Z36                  1
30-059       5MVG148DN024          Gear Z36-Z29                  1
30-060       5MVG148DN025          Gear Z36-Z24                  1
30-061       5MVG137DN020          Gear Z24                      1
30-062       5MVG138DN034          Gear Z30                      1
30-063       5MVG137DN021          Gear Z30-P30                  1
30-064       5MMM121CX001          Bush Drum                     1
30-065       5MMM176CJ005          Bushing SBK                   1
30-066       5AAXMT031GEA          Main Motor Assy               1
30-067       5MVS622SC001          Sheet MO                      1
30-068       5MMT466SN001          Sheet D                       1
30-069       5MVG147DN011          Gear Z36                      1
30-070       5MVG148DN026          Gear Clutch Z36               1
30-071       5AAVCLTCH010          Oneway Clutch                 1
30-072       5MVG137DN019          Gear Clutch Z24               1
30-073       5AAVCLTCH010          Oneway Clutch                 1
30-074       5AACCNQE6GEA          Conn Cord Assy S2094          1
30-075       5MMS527SD002          BKT Connector                 1
30-076       5MMU932SD001          Rail Case L                   1
30-077       5MMM165SN002          Roller DU                     1
30-078       5MMU932SD002          Rail Case R                   1
30-079       5MMM165SN002          Roller DU                     1
30-080       5EZSA2401020308       Solenoid                      1
30-081       5MMW261LD028          Spring Sol                    1
30-082       5MMS447SD001          BKT Solenoid                  1
30-083       5MVX443SG001          Arm DU                        1
30-084       5AAXMT027GEA          Stepping Motor Assy           1
30-085       5MML373SD006          BKT Step                      1
30-086       5MVM176DB014          Pulley Belt PU                1
30-087       5MML211SN002          Plate Catch L                 1
30-088       5MML211SN001          Plate Catch R                 1
30-089       5MVX622SB012          Cover PT                      1
30-090       5MVB861SB007          Cover Bottom                  1
30-091       5MVB864SB013          Cover Rear DU A               1
30-092       5MVB766SB003          Cover Rear DU B               1


PRINTER OPTION - Parts Catalogue   KYOCERA DU-30              Page 5
Ref No.      Part Code             Description             Quantity

30-093       5MVS735CC004          Sheet DU                       1
30-094       5AACCNQJ8GEA          Conn Cord Assy                 1
30-095       5AACCNQJ9GEA          Conn Cord Assy                 1
30-096       5AACCNQK0GEA          Conn Cord Assy                 1
30-097       5AAVGEAR*029          Gear Clutch Z36 ASSY           1
30-098       5AAVGEAR*030          Gear Clutch Z24 ASSY           1
30-100       5MMK224FJ001          Magnet                         1
30-101       5AACCNQF2GEA          Conn Cord Assy S02100          1
30-102       5AACCNQE3GEA          Conn Cord Assy S02100          1
30-103       5MVM150RB008          Rubber Pin                     1
30-104       5MMS426SN003          Plate Magnet                   1
30-105       5MVS766KN001          Sheet PU                       1
30-106       5MML232LD002          Plate Earth Manual             1
30-107       5MVS854CB001          Sheet Turn                     1
30-108       5MMS612LD003          Plate Earth DU                 1
30-109                             Ser. No. Plate                 1
30-110                             Label Front DU                 1
30-111       5AAXAP026GEA           Mo PWB Assy                   1




PRINTER OPTION - Parts Catalogue   KYOCERA DU-30               Page 6



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
