Image preview - the first page of the document
Kyocera Envelope Feeder EF-1 Parts Manual


>> Download Kyocera Envelope Feeder EF-1 Parts Manual documenatation <<

Text preview - extract from the document
                              PRINTER OPTIONS


                                    EF-1




     PARTS CATALOGUE

PRINTER OPTIONS - Parts Catalogue   KYOCERA EF-1   Page 1
EF-1 Parts Catalogue
Table of Contents

Exploded View (Fig.1)                                                            3

Introduction

The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:

'Ref No.'          Reference number which corresponds to the parts in the figure
'Part code'                                   Part code which identifies the part
'Part description'                                 A brief description of the part
'Quantity'                      Quantity of the part used in the printer or option

Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.




PRINTER OPTIONS - Parts Catalogue   KYOCERA EF-1                             Page 2
                                                                                                                                     03-003
                                                                                                                                                                                                           02-020
                                                                     03-002
                                                                                                                                                                                                                                                                              05-005
PRINTER OPTIONS - Parts Catalogue




                                                                                          03-001



                                                                                                                                                                                       02-001A
                                                                                                                                                                                                               02-019                                                                               02-022
                                                                                                                                                            02-021
                                                                                                                                     03-004

                                                                                                                                                                                                                                                                                       04-001B


                                                                                                               03-004

                                                                                                                                                                                                                                                                     02-003
                                                                                                                                                                                                                                                                                                              04-001A



                                                                                           03-005
                                                                                                                                                                                                                                                                  02-002
                                    Fig.1 - Exploded View
KYOCERA EF-1




                                                                                                                                                                                                                                                                  02-013

                                                            05-002                                                                                                                                                                                      04-002A
                                                                                                         02-005
                                                                                                                                                                                                                                                                                                               04-006
                                                                                                                                                                                                 02-018
                                                                              02-006
                                                                                                                                                                              02-017

                                                                                                                                                                                                                         02-018
                                                                                                                                                                                                                                                                                                 04-003                 04-004

                                                                                                          02-012
                                                                                                                                                                                                                                  04-002B                                                            04-005
                                                                                             02-007                                                             02-003                                          02-016
                                                                                                                                                                                                  02-015

                                                                                 02-008        02-014
                                                                                                                                                                                                                                                                                                                           04-007

                                                                                                                            02-011                                   02-002                                                                 04-008




                                                                                                                                          02-013
                                                                                                      02-009
                                                            05-004
                                                                                                                                 02-011
                                                                                                         02-010
                                                                                                                        02-004                                                                                                                       05-001C
                                                                                                                                                                                                                                                                                                                        02-006
Page 3




                                                                                                                                                                                                                                                                                                   05-001A

                                                                                                                                                   05-002
                                                                                                                                                                                                                                                                                                                   05-001B
Ref No.      Part Code              Description        Quantity

02-000       EF-1                   ENVELOPE FEEDER           1
02-001       5SNSP0008507           FRAME SUB ASSY            1
02-001A      5SNSP0008508           FRAME                     1
02-001B      5SNSP0008509           PLATE CONTROL             1
02-002       5SNSP0008510           HOOK                      2
02-003       5SNSP0008511           BUTTON RELEASE            2
02-004       5SNSP0008512           GEAR Z12                  1
02-005       5SNSP0008513           GEAR Z23-Z63              2
02-006       5SNSP0008514           GEAR Z27-Z58              1
02-007       5SNSP0008515           GEAR Z26A                 1
02-008       5SNSP0008516           GEAR Z26B                 1
02-009       5SNSP0008517           GEAR Z18                  1
02-010       5SNSP0008518           GEAR Z19                  1
02-011       5SNSP0008520           BUSHING A                 2
02-012       5SNSP0008521           BUSHING B                 1
02-013       5SNSP0008523           SPRING B                  2
02-014       5SNSP0008524           SPRING CLUTCH             1
02-015       5SNSP0008525           ROLLER ASSY A             1
02-016       5SNSP0008528           ROLLER ASSY B             1
02-017       5SNSP0008554           PAD MOTOR                 1
02-018       5SNSP0008555           DC MOTOR ASSY             1
02-019       5SNSP0008556           SENSOR ASSY A             1
02-020       5SNSPO008558           PWB MAIN                  1
02-021       5SNSP0008536           LEVER SENSOR              1
02-022       5SNSP0008827           SPRING EARTH              1
03-001       5SNSP0008532           PLATE CENTER              1
03-002       5SNSP0008533           PLATE GUIDE R             1
03-003       5SNSP0008534           PLATE GUIDE L             1
03-004       5SNSP0008535           RACK                      2
03-005       5SNSP0008519           GEAR Z16                  1
04-001       5SNSP0008537           ARM ASSY                  1
04-001A      5SNSP0008538           ARM                       1
04-001B      5SNSP0008539           SHAFT WEIGHT              1
04-002       5SNS130008543          SEPARATER ASSY            1
04-002A      5SNSP0008544           HOLDER SEPARATER          1
04-002B      5SNSP0008545           PAD SEPARATER             1
04-003       5SNSP0008542           HOLDER WEIGHT             1
04-004       5SNSP0008546           SHAFT LATCH               1
04-005       5SNSP0008560           SPRING PAD                1
04-006       5SNSP0008557           SENSOR ASSY B             1
04-007       5SNSP0008522           SPRING A                  1
04-008       5SNSP0008541           CHANNEL SENSOR            1
05-001       5SNSP0008547           COVER TOP ASSY            1
05-001A      5SNSP0008548           COVER TOP                 1
05-001B      5SNSP0008549           HOLDER CONNECTOR          1


PRINTER OPTIONS - Parts Catalogue   KYOCERA EF-1           Page 4
Ref No.      Part Code              Description          Quantity

05-001C      5SNSP0008559           PWB CONNECTOR ASSY          1
05-002       5SNSP0008550           COVER UNDER                 1
05-003       5SNSP0008551           TRAY STACKER                1
05-004       5SNSP0008552           COVER RIGHT                 1
05-005       5SNSP0008553           COVER LEFT                  1
05-006       5MVVSEF1**1            LABEL SERIAL                1
