Image preview - the first page of the document
>> Download Kyocera F-1000 Parts Manual documenatation <<
Text preview - extract from the document
LASERBEAM PRINTER
F-1000
PARTS CATALOGUE
10-11-1998
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 1
F-1000 Parts Catalogue
Table of Contents
Covers (Fig.1) 3
Upper Frame (Fig.2a) 5
Face Down Unit (Fig.2b) 7
Upper-Half Electrical (Fig.3) 9
Lower Frame (Fig.4) 11
Lower-Half Electrical (Fig.5) 13
Controller (Fig.6) 15
Motor and Main Drive Gears (Fig.7) 17
Paper-Feed Assembly (Fig.8) 19
Paper-Feed Electrical (Fig.9) 21
Developer (Fig.10) 23
Scanner (Fig.11) 25
Fuser (Fig.12) 27
Harnesses - Upper Half (Fig.13) 29
Harnesses - Lower Half (Fig.14) 31
Harnesses - Controller Etc. (Fig.15) 33
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
Consumables and Maintanence Kits
TK-4 Toner Kit
DK-3 Drum (10K pages)
DV-4 Developer (50K pages)
FK-4 Fuser (80K pages)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 2
Fig.1 - Covers
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 3
Ref No. Part Code Description Quantity
01-00A 5AAVCOVER115 Assy F Cov 220-240V 1
01-00B 5MVB986SH006 Assy Top Cover 1
01-001 5AAFZF1000*1 Assy Keyboard 1
01-003 5MVL832SH002 FD Subcover 1
01-006 5MVX876SH024 Rear Cover 1
01-007 5MVB873SH013 Cover Right 1
01-008 5MVX843SH002 Blind Cover 1
01-010 5AAMF1000*03 Assy Base 1
01-012 5MVX872SH001 Print Tray 1
01-024 5MML822SL006 Bracket Subcover 1
01-025 5MVX821XJ001 Discharger FD 1
01-026 5MMS323RD001 Plate FD Ground 1
01-027 5MVS623KF001 Sheet Top Cover 1
01-028 5MMW904LJ002 Holder Paper 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 4
Fig.2a - Upper Frame
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 5
Ref No. Part Code Description Quantity
02-00A 5AAYF1010*63 Assy DLP Lock Lever 1
02-001 5MMZ871SL001 Cover Scanner Area 1
02-002 5AAMF1000*04 Assy Rail A 1
02-003 5MMX644LD002 Cleaner Press 2
02-004 5AAVFRAME045 Frame Assy 1
02-006 5MVS838RB003 Pad Scanner Seal 1
02-007 5MVS635CH001 Sheet Cover 1
02-024 5MVS663KF001 Plate Barrier Top 1
02-027 5MMX644SL001 Plate A Hook 1
02-028 5MMX444SL003 Plate B Hook 1
02-029 5MVX654DN001 Hook A Hinge 1
02-030 5MVX632DN001 Hook B Hinge 1
02-031 5MMX861SL001 Arm Hinge 1
02-032 5MMW172LJ003 Spring Hinge 1
02-033 5MMX474RJ001 Plate Ground C 1
02-034 5MMS334RJ001 Plate Ground A 1
02-035 5MVX221DB006 Guide Frame F 1
02-036 5MVX221DN005 Guide Frame R 1
02-037 5MVB773SB005 Guide Regist Roller 1
02-038 5MVB862SB001 Guide Upper M-Feed 1
02-039 5MVX422SB003 Actuator Sens M-Feed 1
02-040 5MMW161LJ008 Spring Sensor 1
02-041 5MMX653SL006 Bracket Interlock 1
02-042 5MVU122DB002 Lever Interlock 1
02-043 5MVX443DB001 Bracket Interlock 1
02-048 5MVX665CB01% Bearing Drum 1
02-049 5MVG138DB002 Gear Drum Z30 1
02-050 5MVB773SB002 Nozzle B 1
02-051 5AAMW1****20 Filter Assy 1
02-052 5MVS229RB001 Seal Nozzle 1
02-053 5MVS519RB001 Seal 1
02-054 5MVX643CX001 Lever DLP CAM 1
02-055 5MVX622DB001 Lever DLP CAM B 1
02-056 5MVM177DJ001 Bushing R Drum 1
02-062 5MVX662SB011 Guide R DLP 1
02-063 5MVX662SB012 Guide F DLP 1
02-081 5MVS227RF009 Sheet Seal 1
02-083 5MVS622KF002 Switch Interlock 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 6
Fig.2b - Face Down Unit
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 7
Ref No. Part Code Description Quantity
02-000 5AAYF1000*63 Face Down Unit 1
02-005 5MVB651SB003 Cover Switch 1
02-011 5MMT8668Z015 Shaft FD Cover 1
02-012 5MMT876SN013 Roller FD B 1
02-013 5MVG127DB003 Gear FD Z20 1
02-014 5MMT876SN014 Roller FD C 1
02-015 5MMW161LJ021 Spring Idle 1
02-016 5MMX765SL005 Plate FD Side R 1
02-017 5MMS767SL003 Plate FD Side F 1
02-018 5MVB773SB005 Guide FD 1
02-019 5MVB854CB001 Guide FD Paper 1
02-020 5MVM176DB002 Flange Pulley 1
02-021 5MMX311LD001 Bracket Ext Pulley 2
02-022 5MVX811RB001 Belt FD 1
02-023 5MVM123DB001 Pulley FD Feed 2
02-064 5MVM177DB003 POulley Outlet 2
02-065 5MMW161LJ012 Spring Jam Actuator 1
02-066 5MVX422DB002 Jam Actuator 1
02-067 5MMT421SL001 Bracket Idle 1
02-068 5MMU131LJ002 Spring FD Enter 2
02-069 5MVM176DN009 Bearing 6
02-070 5MVX422DB003 Jam Actuator FD 1
02-071 5MMW163LJ001 Spring FD Actuator 1
02-072 5MVM474DB001 Pulley FD B 2
02-073 5MMU131LD001 FD Pressure 4
02-074 5MVG127DN015 Gear Joint FD 1
02-075 5MMT876SN010 Roller Middle FD 1
02-076 5MVM177DB004 Pulley Idle Belt 4
02-077 5MMX421SL001 Bracket Idle 1
02-078 5MVG022DB001 Gear Belt Pulley 1
02-079 5MVG327DB001 Pulley Belt 2
02-084 5MVB876SH025 Cover FD 1
02-085 Switch Interlock 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 8
Fig.3 - Upper-Half Electrical
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 9
Ref No. Part Code Description Quantity
03-0A 5AAYF1000*53 Eraser LED Assy 1
03-001 5ETNB60101***01 Assy PWB DLP Bias 1
03-002 5EZKD6Z02301*01 Counter Print 1
03-003 5MML252SL001 Bracket Counter 1
03-004 5AAPRZZ003AA PWB Motor Control 1
03-005 5ETNB66202***01 Main HV Unit 1
03-006 5EZNF2403001*01 Fan DC 1
03-007 5ENXGP1A05HR*01 Photosensor 3
03-008 5AAPRZZ005AA PWB Drum Life 1
03-010 Connect MCH 1
03-012 Support PWB 6
03-013 5AAPRZZC1004BH Assy PWB Polygon 1
03-014 5AAXSW020GEA Switch Interlock 1
03-015 Cover FD Switch 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 10
Fig.4 - Lower Frame
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 11
Ref No. Part Code Description Quantity
04-001 5MMU832SL001 Support Base 2
04-002 5MMZ886SL001 Plate Sheild 1
04-003 5MML232RD001 Plate Ground 2
04-005 5MMX431RD002 Plate Ground 2
04-007 5MVB866SB002 Cover Inside F 1
04-008 5MVS836CB001 Plate Fuser 1
04-010 5MMS746SB001 Plate Sensor 1
04-011 5MMX222RJ001 Plate Ground Sensor 1
04-015 5MMU833SM001 Plate Paper Ramp 1
04-016 5MVS618RB005 Seal A 1
04-017 5MVS213RB005 Seal D 1
04-018 5MVS618RB003 Seal C 1
04-019 5MVS732KN002 Guide R 1
04-020 5MVS632KN001 Guide F 1
04-021 5MVS439RH002 Pad B Tank 1
04-022 5MVS428RH002 Pad A Tank 1
04-023 5MMX542RJ001 Plate B Ground 1
04-024 5MMX332RJ001 Plate Ground Fuser 2
04-025 5MVX764SB002 Cover Inside RB 1
04-026 5MVX764SB003 Cover Inside RA 1
04-027 5MMS657SL010 Plate Hinge Base 2
04-028 5MMT326LJ001 Pin Stopper 2
04-029 5MMX763SL006 Arm Frame L 1
04-030 5MMX763SL005 Arm Frame R 1
04-031 5MMS637SL003 Stopper L 1
04-032 5MML264SL001 Stopper R 1
04-033 5MMW172LJ004 Spring Stopper 1
04-034 5MMS226SL002 Stopper 1
04-035 5MMW908SM002 Rod Torsion A 1
04-036 5MMW908SM001 Rod Torsion B 1
04-037 5MMX852AJ001 Discharger Transfer 1
04-039 5MVB222RB001 Rubber Piece 5
04-040 5MMX641LJ001 Hold Corotron 1
04-041 Ass'y Actuator HVU 1
04-064 5AAUSHILD033 Assy TR Corotron 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 12
Fig.5 - Lower-Half Electrical
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 13
Ref No. Part Code Description Quantity
05-001 5ETNB66201***01 HV Unit Transfer 1
05-002 5EZR1G012301*01 Relay SS 220-240V 1
05-003 5AAXAP002GEA PWB Assy Cassette 1
05-005 5AAPRSS005BA Assy PWB Paper 1
05-008 Base SSR Etc. 1
05-009 5AAVHOLDR016 Assy Actuator HVU 1
05-010 5MVX332XH001 Receptacle TC 1
05-011 5MVS533KN001 Blind 1
05-012 5ESC020103***01 Switch Power 1
05-013 Bracket. Sensor Cas. 1
05-014 Bracket Switch Power 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 14
Fig.6 - Controller
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 15
Ref No. Part Code Description Quantity
06-001 5MMU886SL002 Box Controller 1
06-002 5MML861SM001 Panel Rear 1
06-003 5MMX533Sl001 Bracket Connector 1
06-004 5MML452SL002 Bracket Filter 1
06-005 5MVS875VF001 Insulator 1
06-006 5MVX221NN019 Spacer Locking 1
06-007 5MVX221NN022 Spacer Card 1
06-008 5MVL631WN49 Decal Fuse 220-240V 1
06-009 5EYFBQ50205**01 Fuse 220-240V 3
06-010 5EYHF102004**01 Block Fuse 220-240V 1
06-011 5EZNF2403401*01 Fan DC 1
06-012 5AACCNCP0GEA Inlet Assy 1
06-013 5EFNZSB22100501 Filt Noise 220-240V 1
06-014 5AAEZF1000*2 Regulator Swing 240V 1
06-015 5AAPRCZG2005AH PWB Assy 220-240V 1
06-018 5AACCNCH4GEA Cable Ass'y 1
06-019 5AACAC278EEA Cable Power 220-240V 1
06-020 5MVS627SH002 Cover Blind 1
06-021 PWB Support Nylon 1
06-022 PWB Ass'y 1MB RAM 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 16
Fig.7 - Motor and Main Drive Gears
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 17
Ref No. Part Code Description Quantity
07-00A 5AAYF1000*37 Assy Drive Gears 1
07-001 5EZNS180R401*01 Motor DC 1
07-002 5MMX642SL005 Plate Motor 1
07-003 5MMG138SX005 Gear Z30 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 18
Fig.8 - Paper-Feed Assembly
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 19
Ref No. Part Code Description Quantity
08-00A 5AAYF1000*36 Paper-Feed Assembly 1
08-00B 5AAYF1000*52 Assy Cover Sensor 1
08-00C 5AAYF1010*26 Assy Clutch M-Feed 1
08-00D 5AAYF1010*27 Assy Clutch Feed 1
08-00E 5AAYF1010*28 Assy Clutch Regist 1
08-001 5MMX766SL002 Bracket Solenoid 1
08-002 5MMW171LJ004 Spring Cam M 1
08-003 5MVX442DN001 Lever Cam M 1
08-004 5MVS226RB005 Pad Solenoid 2
08-005 5MMW171LJ003 Spring Cam 1
08-006 5MVX552DN001 Lever Cam 1
08-015 5MMM176CJ003 Bush Metal KD 6
08-016 5MMX776SL001 Frame R 1
08-017 5MMW171LJ002 Spring Roller M 2
08-018 5MVX322DB001 Bush R 1
08-023 5MVG138DN011 Gear Z28 3
08-024 5MMW241LJ009 Spring Regist 2
08-025 5MMM121XJ001 Bush Roller Regist 2
08-029 5MML833SL002 Support TC 1
08-030 5MVS852K1002 Cover 1
08-031 5MVX532DD002 Guide TC 1
08-032 5MVS618RB004 Seal B 1
08-037 5MMX543LJ001 Bracket Sensor 1
08-038 5MMX865SN001 Paper Chute A 1
08-039 5MMS856SN001 Paper Chute B 1
08-040 5MVX332DB002 Bush Tension F 1
08-041 5MMX866SN002 Roller B M 1
08-042 5MMT876SN007 Roller A M 1
08-043 5MVX764SB001 Guide Cassette R 1
08-044 5MMT866SN003 Roller A Regist 1
08-045 5MMT876SN019 Roller B Regist 1
08-047 5MVX763SB003 Guide Cassette F 1
08-048 5MVG127DN017 Gear Z20 1
08-049 5MVG147DN001 Gear Z32 1
08-050 5MML531SL001 Actuator Interlock 1
08-051 5MMX775SL001 Frame F 1
08-066 5AAMF1000*05 Assy Wheel Feed 1
08-067 5MMT866SJ001 Shaft Roller Feed 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 20
Fig.9 - Paper-Feed Electrical
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 21
Ref No. Part Code Description Quantity
09-001 5AACCNAN8GEA Cable Assy 1
09-002 5EZSA2403010302 Solenoid Feed 1
09-003 5EZSA2403010303 Solenoid Manual 1
09-004 5AAPRSS005AA Assy PWB 1
09-005 5AACCNAG4GEA Cable Assy 1
09-006 5EZSA2403010102 Solenoid Regist 1
09-007 5ENXGP1A05HR*01 Photosensor 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 22
Fig.10 - Developer
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 23
Ref No. Part Code Description Quantity
10-00A DV-4 Ass'y Developer 1
10-012 5AAXTS002GEA Sensor Toner 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 24
Fig.11 - Scanner
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 25
Ref No. Part Code Description Quantity
11-00A 5AAYF1000*63 Assy Scn'r 220-240V 1
11-023 5MVS422SB001 Lid Adjust 1
11-033 5AAPRAPC1003AH Assy PWB APC 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 26
Fig.12 - Fuser
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 27
Ref No. Part Code Description Quantity
12-00A FK-4 Assy Fuser 200-240V 1
12-043 5EZPB2413320101 Heater 800W / 220-240V 1
12-044 5AACCNAP6GEA Thermistor 1
12-045 5AAXTF005VDA Fuse Thermal 220-240V 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 28
Fig.13 - Harnesses - Upper Half
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 29
Ref No. Part Code Description Quantity
13-002 5AACCNCG9GEA Harness 1
13-003 5AACCNCR7GEA Harness 1
13-007 5AACCNCR9GEA Harness 1
13-009 5AACCNAP2GEA Harness 1
13-010 5AACCNAP4GEA Strain Relief 2
13-011 5AACCNDB7GEA Strain Relief 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 30
Fig.14 - Harnesses - Lower Half
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 31
Ref No. Part Code Description Quantity
14-001 Harness 1
14-003 Harness 1
14-004 Clamp 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 32
Fig.15 - Harnesses - Controller Etc.
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 33
Ref No. Part Code Description Quantity
15-001 Harness 1
15-002 Harness 1
15-003 Harness 1
15-004 Harness 220-240V 1
15-005 Harness 220-240V 1
15-006 Harness 1
15-007 Harness 1
15-008 Clamp 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-1000 Page 34
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
