Image preview - the first page of the document
>> Download Kyocera F-2010 Parts Manual documenatation <<
Text preview - extract from the document
LASERBEAM PRINTER
F-2010
PARTS CATALOGUE
13-11-1998
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 1
F-2010 Parts Catalogue
Table of Contents
Covers (Fig.1) 3
Upper Frame (Fig.2) 5
Lower Frame (Fig.3) 8
Unit Bottom (Fig.4) 10
Drive Mechanism (Fig.5) 12
Paper-feed Assembly (Fig.6) 14
Face-down Unit (Fig.7) 17
Laser Scanner Unit (Fig.8) 19
Drum Cartridge (Fig.9) 21
Developer (Fig.10) 24
Fuser (Fig.11) 26
Paper Cassette (Fig.12) 28
Transfer Charger (Fig.13) 30
Upper-Half (Electrical) (Fig.14) 32
Lower-Half (Electrical) (Fig.15) 34
Paper-Feed (Electrical) (Fig.16) 36
Face-Down Unit (Electrical) (Fig.17) 38
Fuser (Electrical) (Fig.18) 40
Upper-Half (Harness) (Fig.19a) 42
Lower-Half (Harness) (Fig.19b) 44
Sorter (Optional) (Fig.20) 46
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
Consumables and Maintanence Kits
TK-3 Toner Kit
DK-3 Drum (10K pages)
DV-5 Developer (50K pages)
W-3 Fuser (80K pages)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 2
Fig.1 - Covers
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 3
Ref No. Part Code Description Quantity
01-00A 5AAMW1****09 Tray Assy 2
01-001 Print Tray B 2
01-002 Print Tray A 2
01-003 5MVB873SH008 DLP Cover 1
01-004 FD Sub Cover 1
01-005 Top Cover 1
01-006 Right Cover 1
01-007 5AAYF2010*23 Keyboard Assy 1
01-008 Base 1
01-009 Front Cover 1
01-010 Lock Nut 3
01-011 Open-Cover 1
01-012 Controller Panel F 2
01-013 FD ES Eliminator 1
01-014 Rear Cover 1
01-015 5MVX942SW001 Blind Cover 1
01-016 Left Cover 1
01-017 Controller Panel R 1
01-018 Cord Press 2
01-019 Option Cover 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 4
Fig.2 - Upper Frame
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 5
Ref No. Part Code Description Quantity
02-00A 5AAYF1010*63 DLP Lever Assy 1
02-001 5MMW162LJ003 DLP Spring 2
02-002 5MVX632CX002 DLP Lever R 1
02-003 5MMW162LJ004 Lever B Spring 1
02-004 5MVX622CB007 DLP Lever B 2
02-005 5MVX632CX001 DLP Lever F 1
02-006 5MMT866SZ013 DLP Shaft 1
02-007 DLP Guide R 1
02-008 DLP Guide F 1
02-009 Torsion Bar A 1
02-010 Torsion Bar B 1
02-011 Frame Assy 1
02-012 Wire Support 1
02-013 5MVG138DB002 Drum Gear Z30 1
02-014 5MVX665CB01% Drum Bearing 1
02-015 Nozzle B 1
02-016 5AAYW3****01 Filter Assy 1
02-017 Nozzle Seal 1
02-018 Wind Seal 1
02-019 Top Cover Plate 1
02-020 Toner Shutter 1
02-021 Scanner Pad 1
02-022 Cleaner Pressure 2
02-023 Fuser Upper Pad B 1
02-024 Fuser Upper Pad A 1
02-025 5MMX474RJ001 Earth Plate C 1
02-026 5MMX653SL006 Connector BKT 1
02-027 5MVU122DB002 Inter Lock SW Lever 1
02-028 5MVX443DB001 Inter Lock SW Bkt B 1
02-029 5AAXSW020GEA Hopper SW Assy 1
02-030 M Feed Upper Guide 1
02-031 5MMP153CJ001 Frame Earth F` 1
02-032 5MMW161LJ008 Sensor Spring 1
02-033 5MVX442SB003 M Feed Sens Actuator 1
02-034 Drum Bushing R 1
02-035 5MVX622DB001 DLP Cam Lever B 1
02-036 5MVX643CX001 DLP Cam Lever 1
02-037 Hinge Arm 1
02-038 5MML144SL001 Hook Plate B 1
02-039 5MVX632DN001 Hinge Hook B 1
02-040 Hinge Spring 1
02-041 Unit Rail A 1
02-043 5MMX433SL002 Hook Plate A 1
02-044 5MVX632DN001 Hinge Hook A 1
02-045 Edging Saddle 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 6
Ref No. Part Code Description Quantity
02-046 Wire Saddle 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 7
Fig.3 - Lower Frame
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 8
Ref No. Part Code Description Quantity
03-001 5MVS618RB005 Seal A 1
03-002 5MMX641LJ001 TC UP Spring 1
03-003 5MMX852AJ001 TC Discharger 1
03-004 Blind Sheet 1
03-005 5MMU833SN002 Paper Guide Plate 1
03-006 5MVS218RB005 Seal D 1
03-007 Seal C 1
03-008 Base Hinge Plate R 1
03-009 Frame Arm R 1
03-010 Frame Arm L 1
03-011 5MVX865SB001 Inner Cover R 1
03-012 Cord Press 8
03-013 Base Hinge Plate L 1
03-014 Bar Stopper 1
03-015 Bar Stopper Spring 1
03-016 5MMX762CJ001 Controller Earth B 1
03-017 Earth Plate 1
03-018 5MVX964SB001 Inner Cover F 1
03-019 Toner Tank Cap 1
03-020 Toner Tank 1
03-021 5MMX222RJ001 Sensor Earth Plate 1
03-022 5MMS746SB001 Sensor Plate 1
03-023 5MVS622KF001 Guide Sheet R 1
03-024 5MVS722KF001 Guide Sheet F 1
03-025 Tank Pad A 1
03-026 Tank Pad B 1
03-027 Base Support 1
03-028 Foot 4
03-029 Controller Guide B 1
03-030 Controller Earth A 1
03-031 Controller Guide A 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 9
Fig.4 - Unit Bottom
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 10
Ref No. Part Code Description Quantity
04-001 Knob 2
04-002 5EZNF2402501*01 Fan Motor B 1
04-003 Cont. Box R Cov Assy 1
04-004 Conn Cord Assy CA4 1
04-005 Conn Cord Assy CA3 1
04-006 5AAEZW-1***3 DC Power Supply 240V 1
04-007 P/S Support KC 1
04-008 Sheet MT 1
04-009 Socket Main Logic 4
04-010 Pan Head Screw 2
04-011 PCB Guide Rail 2
04-012 5AAPRCZG4001AH P.W.B Assy KP-017 1
04-013 Cont Middle Plate KC 1
04-014 Conn Cord Assy CA9 1
04-015 Cont Box Stopper 1
04-016 Cont Boc Assy KC 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 11
Fig.5 - Drive Mechanism
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 12
Ref No. Part Code Description Quantity
05-00A 5AAYMT910*20 Drive Unit 1
05-001 Joint Spring 1
05-002 Joint Gear Plate 1
05-003 Collar 58 1
05-004 Joint Gear Z54 1
05-005 Drum Earth 1
05-006 Plate B 1
05-007 Gear Z44 1
05-008 Gear Z48 2
05-009 Plate A 1
05-010 5MMG138SX005 Motor Gear Z30 1
05-011 5EZNS180R401*01 DC Motor Assy 1
05-012 Wire Saddle 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 13
Fig.6 - Paper-feed Assembly
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 14
Ref No. Part Code Description Quantity
06-000 5AAYF2010*07 Paper-Feed Assembly 1
06-001 Feed Sol Bracket 1
06-002 M Feed CL Cam Spring 3
06-003 5MVX432DW001 M Feed CL Cam Lev B 1
06-004 Solenoid Pad 3
06-005 5MVX442DN001 M Feed CL Cam Lev A 2
06-00A 5AAVCLTCH005 Manual Feed Clutch 1
06-006 M Feed Clutch Boss 3
06-007 M Feed Wrap Spring B 1
06-008 Ratchet Spring 3
06-009 Brake Ring 3
06-010 M Feed CL Ratchet B 1
06-011 M Feed CL Spring 8
06-012 Spring Stopper 2
06-013 M Feed Clutch Gear Z16 2
06-014 5MMM176CJ001 Metal Bush KD 2
06-00B 5AAVCLTCH004 Paper Feed Clutch A 2
06-015 M Feed Wrap Spring A 2
06-016 M Feed CL Ratchet 2
06-017 Feed Clutch Gear Z26 2
06-018 5MVG138DN011 Feed Unit Gear Z28 2
06-019 5MVG169DB001 Feed Unit Gear Z65 2
06-020 5MMM121XJ001 Regist Roller Bush 2
06-021 5MMW241LJ009 Regist Spring 2
06-00C 5AAVCLTCH003 Regist Clutch 1
06-022 Feed Clutch Boss 1
06-023 Regist Clutch Cam 1
06-024 Regist Wrap Spring 1
06-025 Regist CL Gear Z16 1
06-026 Cassette Guide UR 1
06-027 Cassette Guide LR 1
06-028 5MMW341LJ001 M Feed Spring 2
06-029 MF Bush 2
06-030 Feed Unit Frame R 1
06-031 Guide Sheet PS 1
06-032 M Feed Paper Chute A 1
06-033 M Feed Paper Chute B 1
06-034 Paper Guide 1
06-035 5MVX331DB003 Actuator B 1
06-036 5MVX532DB002 Actuator A 1
06-038 5MVX532DD002 TC Guide 1
06-039 TC Supporter 1
06-040 Seal B 1
06-041 Cover Sheet 1
06-00E 5AAMF2010*01 MF Plate Assy 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 15
Ref No. Part Code Description Quantity
06-042 MF Size Label 1
06-043 MF Paper Guide 2
06-044 MF Plate 1
06-045 SAM Screw M4X10 2
06-046 MF Gear Z20 1
06-047 MF Guide Rack 2
06-048 Feed Unit Stay A 1
06-049 Sensor Cover 2
06-050 Paper Holder 4
06-051 Feed Unit Stay B 1
06-052 Sensor Plate A 1
06-053 M Feed Roller B 1
06-054 5MMT876SN008 M Feed Roller A 1
06-055 Feed Roll Shaft 2
06-056 Regist Roller A 1
06-057 5MMT876SN006 Regist Roller B 1
06-00D 5AAVROLL*007 Feed Tyre Assy 4
06-058 Feed Tyre 4
06-059 Feed Wheel 4
06-060 Cassette Guide UF 1
06-061 Cassette Guide LF 1
06-062 5MVG127DN017 Regist Gear Z20 1
06-063 5MVG147DN001 Regist Gear Z32 1
06-064 Feed Unit Frame F 1
06-065 Main SW BKT 1
06-066 Paper Chute Guide 2
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 16
Fig.7 - Face-down Unit
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 17
Ref No. Part Code Description Quantity
07-000 5AAYF2010*02 Face-Down Unit 1
07-001 5MVX422DB002 Jam Actuator 1
07-002 FU Actuator Spring 1
07-003 FD Paper Guide 1
07-004 Exit Pulley Bracket 4
07-005 FD Feed Pulley 4
07-006 5MMT876SN011 FD Enter Roller 1
07-007 Seal C 2
07-008 5MMT876SN012 FD Exit Roller 1
07-009 5MMW163LJ001 FD Actuator SP 1
07-010 5MVX422DB003 FD Jam Actuator 1
07-011 FD Guide 1
07-012 Side Plate 1
07-013 5MVM176DN009 Bearing 6
07-014 5MVG127DB002 FD Exit Gear 1
07-015 5MVG022DB001 Belt Pulley Gear 1
07-016 Pulley Flange 1
07-017 5MVX917RB001 FD Belt 1
07-018 5MVM177DB004 Belt Idle Pulley 3
07-019 5MVG327DB001 Belt Pulley 2
07-020 Idle Spring 1
07-021 Idle Bracket 1
07-022 5MVG127DB001 FD Joint Gear Z20 1
07-023 FD Spring R 1
07-024 FD Magnet Plate 4
07-025 FD Magnet 2
07-026 FD Cover 1
07-027 5MMX822LJ001 FU ES Eliminator 1
07-028 5MVM174DB001 FD Exit Pulley 11
07-029 FD Pin 2
07-030 5MMU131LJ001 FD Pressure 4
07-031 5MVM474DB001 FD Pulley B 2
07-032 5MMT876SN010 FD Middle Roller 1
07-033 FD Outlet Cover 1
07-034 FD Switch Cover 1
07-035 Solenoid Spring 1
07-036 FD Spring F 1
07-037 5MVX211DB002 Link Plate 1
07-038 Change Plate 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 18
Fig.8 - Laser Scanner Unit
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 19
Ref No. Part Code Description Quantity
08-000 5AAYF1010*14 Scanner Unit 240V 1
08-001 Scanner Cover 1
08-002 5MVS422SB001 Scanner Cover Lid 1
08-003 LENS SUPPORT ASSY 1
08-004 LENS A 1
08-005 LENS B 1
08-006 LENS SPRING A 1
08-007 MIRROR STOPPER A 2
08-008 MIRROR A 1
08-009 MIRROR STOPPER BE 1
08-010 MIRROR B 1
08-011 MIRROR STOPPER BR 1
08-012 MIRROR C 2
08-013 MIRROR HOLDER ASSY 1
08-014 MIRROR BASE ASSY 1
08-015 S MIRROR CAM 1
08-016 SENSOR HOLDER 1
08-017 POLYGON UNIT 1
08-00A LASER MODULE 1
08-018 LO PWB 1
08-019 LASER BRACKET 1
08-020 LASER DIODE 1
08-021 S LENS BRACKET 1
08-022 APERTURE 1
08-023 SELFOC LENS 1
08-024 S LENS HOLDER 1
08-025 SCANNER FRAME 1
08-026 MIRROR C SUPPORT 1
08-027 C LENS SUPPORT 1
08-028 CLYNDRICAL LENS 1
08-029 TORIC LENS 1
08-030 COVER GLASS 1
08-031 TORIC PAD 2
08-032 T LENS GUIDE 1
08-033 SCANNER SEAL 1
08-034 PD PWB 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 20
Fig.9 - Drum Cartridge
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 21
Ref No. Part Code Description Quantity
09-000 DK-3 DRUM CARTRIDGE 1
09-001 DRUM WIPER R 1
09-002 COVER MAGNET 1
09-003 DRUM WIPER F 1
09-004 DRUM COVER 1
09-005 ERASE CLEANING PAD 1
09-006 MCH SPRING 1
09-007 MCH END BLOCK R 1
09-008 CORONA WIRE 1
09-009 CHG SPRING B 1
09-010 MCH WIRE HOOK F 1
09-011 MCH END BLOCK F 1
09-012 MCH SHIELD 1
09-013 MCH CLEANER ROD 1
09-014 MCH CLEANER ASSY 1
09-015 DRUM ACTUATOR 1
09-016 ACTUATOR SPRING 1
09-017 DRUM SPRING STOPPER 1
09-018 DRUM BUSHING R 1
09-019 DRUM SHAFT 1
09-020 PRINTED W.BOARD 1
09-021 SCREW GEAR Z20 1
09-022 SCREW BUSHING 2
09-023 CLEANER SCREW 1
09-024 SEAL EARTH TAB A 1
09-025 M3 PLATE 2
09-026 DRUM FRAME 1
09-027 REFRECTOR SHEAL 1
09-028 ERASE REFLECTOR 1
09-029 BLADE BUSHING 1
09-030 CL BLADE ASSY 1
09-031 CLEANER SPRING 2
09-032 BLADE HOLDER 1
09-033 BLADE EARTH TAB 1
09-034 DRUM ASSY 1
09-035 MCH GRID 1
09-036 BLADE SEAL R 1
09-037 SEAL MAGNET 1
09-038 DRUM SEAL 1
09-039 BLADE SEAL F 1
09-040 MCH F STOPPER 1
09-041 REFRECTOR SHEAL R 1
09-042 CLEANER PLATE 2
09-043 GUIDE SPUR RING 3
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 22
Ref No. Part Code Description Quantity
09-044 REFRECTOR SHEAL F 1
09-045 DRUM FRAME COVER F 1
09-046 MCH CLEANER KNOB 1
09-047 DRUM BUSHING F 1
09-048 MCH GRID SPRING 1
09-049 ZENER DIODE ASSY 1
09-050 SCREW BRACKET ASSY 1
09-051 CABLE ASSY PCA2033 1
09-052 DRUM EARTH PLATE 1
09-053 MCH GRID TAB 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 23
Fig.10 - Developer
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 24
Ref No. Part Code Description Quantity
10-000 DV-4 DEVELOPER 1
10-001 DLP HANDLE 1
10-003 DLP SEAL A 2
10-004 DLP BLADE BKT B 1
10-00A PADDLESHAFT ASSY 1
10-006 DLP SPRING 3
10-007 TONER SPRING 1
10-008 CABLE ASSY PCA5040 1
10-009 TONER SENSOR ASSY 1
10-010 CARTRIDGE STOPPER 1
10-011 Z50 SPRING 1
10-012 GEAR Z50 1
10-013 DLP COVER CAM 1
10-014 DLP SIDE COVER 1
10-015 MAGNET BRACKET 1
10-016 DLP PULLEY 2
10-017 DLP BEARING 2
10-018 DLP SIDE FRAME 1
10-019 MAGNET BKT B 1
10-020 DLP SEAL F 1
10-021 DLP SEAL J 2
10-022 DLP SEAL G 2
10-023 DLP SEAL D 2
10-024 DLP SEAL C 1
10-025 DLP SEAL E 1
10-026 DLP SEAL H 1
10-027 DLP SEAL B 1
10-028 DLP SEAL K 1
10-029 DLP CASE 1
10-030 SCREW BUSHING 1
10-031 GEAR Z28 M 1
10-032 GEAR Z12-Z22 1
10-033 GEAR Z14-Z20 1
10-034 DLP BLADE BKT A 1
10-035 DLP BLADE 1
10-036 BLADE MAGNET 1
10-037 MAGNET ROLLER 1
10-038 ROLLER COVER 1
10-039 GEAR Z11 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 25
Fig.11 - Fuser
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 26
Ref No. Part Code Description Quantity
11-000 5AAYW3****02 FUSER 220V-240V 1
11-001 FUSER COVER SHEET B 1
11-002 ROLLER CLEANER 1
11-003 FUSER COVER A 1
11-004 SEPARATOR 4
11-005 SEPARATOR SPRING 4
11-006 FUSER COVER B 1
11-007 FUSER PAPER GUIDE B 1
11-008 GEAR Z28 1
11-009 FUSER GEAR Z31-Z43 1
11-010 GEAR PIN 1
11-011 GEAR SPRING 1
11-012 GEAR PLATE 1
11-013 FUSER GEAR Z35 1
11-014 GEAR BRACKET 1
11-015 FUSER GEAR Z20 1
11-016 FUSER JOINT COLLAR 1
11-017 FUSER GEAR Z15 B 1
11-018 JOINT PIN 1
11-019 FUSER GEAR Z15 A 2
11-020 FUSER JOINT SPRING 1
11-021 FUSER JOINT PLATE 1
11-022 STOP RING 2
11-023 FUSER GEAR Z28 1
11-024 FUSER BEARING 2
11-025 BEARING SLEEVE 2
11-026 PRESS PLATE PIN 2
11-027 FUSER SPRING 2
11-028 PRESSURE PLATE 2
11-029 PAPER CHUTE ASSY 1
11-030 5MMT877AX001 FIXING ROLLER 1
11-031 FUSER FRAME 1
11-032 5MMT886SX009 PRESS ROLLER 1
11-033 PRESS ROLLER BEARING 2
11-034 SEPARATE PLATE 4
11-035 FUSER PAPER GUIDE A 1
11-036 EXIT COVER 1
11-037 SEPARATOR GUIDE 2
11-038 FUSER PAPER GUIDE C 2
11-039 5EZPB2413320202 FUSER HEATER LAMP 1
11-040 5ENTTC180P1.203 THERMISTOR 1
11-041 5AAXTF00SVDA THERMAL FUSE 1
11-042 5AAVCLEAN006 FUSER CLEANING PAD 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 27
Fig.12 - Paper Cassette
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 28
Ref No. Part Code Description Quantity
12-000 PC2-LTR CASSETTE LETTER 1
12-000 PC2-A4 CASSETTE A4 1
12-000 PC2-B4 CASSETTE B5 1
12-000 PC2-LGL CASSETTE LEGAL 1
12-001 CASSETTE COVER LETTER/A4/B5 1
12-001 CASSETTE COVER LEGAL 1
12-002 PAPER END M 1
12-003 PAPER LIMIT LABEL 1
12-004 PAPER BOTTOM LTR 1
12-004 PAPER BOTTOM A4 1
12-004 PAPER BOTTOM B5 1
12-005 NAIL SUPPORT R 1
12-006 CASSETTE PIN 2
12-007 PAD LETTER 1
12-007 PAD A4 1
12-007 PAD B5 1
12-008 NAIL R 1
12-009 CASSETTE SPRING 2
12-010 MAGNET 1
12-011 NAIL SUPPORT F 1
12-012 SIZE PLATE LTR 1
12-012 SIZE PLATE A4 1
12-012 SIZE PLATE B5 1
12-012 SIZE PLATE RGL 1
12-013 CASSETTE CASE LETTER A4 B5 1
12-013 CASSETTE CASE B LEGAL 1
12-014 NAIL F 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 29
Fig.13 - Transfer Charger
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 30
Ref No. Part Code Description Quantity
13-000 5AAVSHILD033 Transfer Charger 1
13-001 TC End Block Lid A 1
13-002 TC Wire Hook A 1
13-004 TC Contact 1
13-005 TC End Block A 1
13-006 TC End Block Lid B 1
13-007 5MMW801XJ003 TC Corona Wire 1
13-007 CHG Spring B 1
13-008 TC Wire Hook B 1
13-009 TC End Block B 1
13-010 TC Paper Chute A 1
13-011 Shield Sheet 1
13-012 TC Paper Chute B 1
13-013 Earth Plate 1
13-014 TC Shield Case 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 31
Fig.14 - Upper-Half (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 32
Ref No. Part Code Description Quantity
14-001 5ETNB60101***01 Developer Bias PWB 1
14-002 5AAPRCZG2001AH P.W.B Assy KP-018 1
14-003 TR-Press Plate 1
14-004 Total Counter 1
14-005 5MMZ252SL001 Counter Bkt KC 1
14-006 5MMC776SL001 Panel Cont Bkt 1
14-007 5ETNB66202***01 Main HV Unit 1
14-008 5MVX543XN001 MCH Connect 1
14-009 5ENXGP1A05HR*01 Sensor GP1A05HR 2
14-010 5EZNF2403001*01 Fan Motor A 1
14-011 APC PWB 1
14-0A 5AAMW****02 Eraser Assy 1
14-012 L.E.D. Assy 1
14-013 Erase Lamp Holder 1
14-014 5AAPRAPC1004AH P.W.Board Assy 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 33
Fig.15 - Lower-Half (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 34
Ref No. Part Code Description Quantity
15-001 5AAACAC278EEA Power Cord 250V 6A 1
15-003 5AACCNBB2GEA Inlet Assy CCA4001 1
15-004 5MML643SL003 Inlet Bracket 1
15-005 5ETNB66201***01 Transfer HV Unit HVC-3MC60 1
15-006 Edging Saddle EDS-1 2
15-007 Cord Part Plate 1
15-008 5EFNZSB22100501 Noise Filter 250V 15A 1
15-009 5EZR1G012301*01 Solid State Relay 120V 1
15-010 Elec. Plate 1
15-011 5AAPRHC002BA Heat Control PWB 1
15-012 5AAXAP002GEA Cassette Sensor Assy 1
15-013 5AAPRSS005FA PEP Board Assy B 1
15-015 5MMX633SL006 SW Bracket 1
15-016 5ESC020103***01 Main Switch J-U1054 1
15-017 5EYFBP10301**01 Line Fuse 125V 10A 1
15-018 5EYHF103101**01 Fuse Block 120V 1
15-019 5EYFBQ50205**01 Line Fuse 250V 5A 1
15-020 5EYHF102004**01 Fuse Block 220V-240V 1
15-021 5MVX332XH001 TC Receptable 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 35
Fig.16 - Paper-Feed (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 36
Ref No. Part Code Description Quantity
16-001 Cable Assy PCA2032 1
16-002 5EZSA2403010305 Solenoid A-3 1
16-003 5EZSA2403010304 Solenoid A-2 1
16-004 5EZSA2403010302 Solenoid A-1 1
16-005 5EZSA2403010102 Solenoid B 1
16-006 Solenoid Pad 1
16-007 5ENXGP1A05HR*01 Sensor GP1A05HR 1
16-009 5AAPRSS005CA PEP PWB Assy C LED 1
16-010 5AAPRSS005EA PEP Board Assy E 1
16-011 5AAPRSS05DA PEP Board Assy D 1
16-012 Cable Assy CCA5022 1
16-013 Mini Clamp 1
16-014 Inter Lock SW Assy 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 37
Fig.17 - Face-Down Unit (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 38
Ref No. Part Code Description Quantity
17-001 Cable Assy CCA2020 1
17-002 5ENXGP1A05HR*01 Sensor GP1A05HR 1
17-003 5EZSA2401020301 Solenoid C TDS-KN07A 1
17-004 5AAXSW019GEA FD SW Assy 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 39
Fig.18 - Fuser (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 40
Ref No. Part Code Description Quantity
18-001 HEATER 240V 800W 1
18-002 THERMISTOR TC180PR2KBW-3 1
18-003 FUSE BRACKET 1
18-004 CABLE ASSY PCA4024 1
18-005 CABLE ASSY PCA3023 1
18-006 THERMAL FUSE ASSY 1
18-007 TEMP FUSE COVER 1
18-008 LAMP HOLDER R 1
18-009 CABLE ASSY PCA2031 1
18-010 TERMINAL COVER 1
18-011 LAMP HOLDER F 1
18-012 LAMP HOLDER BRACKET 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 41
Fig.19a - Upper-Half (Harness)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 42
Ref No. Part Code Description Quantity
19-101 Cable Assy PCA2039 1
19-102 Cable Assy PCA3041 1
19-103 Hopper SW Assy 1
19-104 Bushing 2
19-105 Cable Assy CA2 1
19-106 Cable Assy CCA3021 1
19-107 Cable Assy CA1 1
19-109 Ferrite Core NF35UU26 2
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 43
Fig.19b - Lower-Half (Harness)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 44
Ref No. Part Code Description Quantity
19-201 Cable Assy CA1 1
19-202 Cable Assy CA8 1
19-203 Cable Assy CCA4002 1
19-204 Cable Assy CCA3023 1
19-205 Cable Assy CCA4004 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 45
Fig.20 - Sorter (Optional)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 46
Ref No. Part Code Description Quantity
20-000 AAVSORTR002 Sorter Entirety 1
20-001 Sensor Plate 1
20-002 Link Plate (C) 2
20-003 Spring Roll Tension 2
20-004 Bearing BushU 4
20-005 Spring Arm 2
20-006 Gear Feed Roller 1
20-007 Arm Assy 2
20-008 Idle Gear 1
20-009 Collar Idle Gear 1
20-010 Idler B 1
20-011 Spring-Idler 1
20-012 PWB Assy Main 1
20-013 Cushion Up-side Frame 2
20-014 P/S Bracket 1
20-015 Pib Phiti Assy (U) 1
20-016 Paper Holder (#1) 1
20-017 PWB Spacer 1
20-018 Side Frame L Assy 1
20-019 Tray Guide 2
20-020 Baffle (B) Up 1
20-021 Cont. Cable Assy 1
20-022 Roller 2
20-023 Shaft Feed 1
20-024 Feed Pulley 2
20-025 Cushion Motor (S) 1
20-026 Harness Assy Motor 1
20-027 Side Frame R Assy 1
20-028 Motor Gear 1
20-029 Baffle (B) Down 1
20-030 Tray (A) 1
20-031 Tongue #2 3
20-032 Tray (B) 4
20-033 Link Plate (A) 8
20-034 Paper Gate (R) 1
20-035 Link Plate (B) 2
20-036 Clank Pulley Gear 1
20-037 PWB Support 1
20-038 Grd Wire Assy 1
20-039 Cushion 2
20-040 Erase Assy 1
20-041 Joint Bracket 1
20-042 Cabinet 1
20-043 Base Plate 1
20-044 Pib Photo Assy (L) 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 47
Ref No. Part Code Description Quantity
20-045 Support Tongue 12
20-046 Stand Cover 2
20-047 Stand 1
20-048 Spring Stand 1
20-049 Paper Gate (L) 1
20-050 Drive Shaft 1
20-051 Harness Cover 1
20-052 Tie Plate 1
20-053 Paper Stopper F 2
20-054 Tongue #3-#5 9
20-055 Paper Stopper R 8
20-056 Serial No. ID 1
20-057 Feed R/L Assy 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-2010 Page 48
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
