Image preview - the first page of the document
>> Download Kyocera F-3000 Parts Manual documenatation <<
Text preview - extract from the document
LASERBEAM PRINTER
F-3000
PARTS CATALOGUE
18-11-1998
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 1
F-3000 Parts Catalogue
Table of Contents
Covers (Fig.1) 3
Upper Frame (Fig.2) 5
Lower Frame (Fig.3) 7
Unit Bottom (Fig.4) 9
Drive Mechanism (Fig.5) 11
Paper-feed Assembly (Fig.6) 13
Face-down Unit (Fig.7) 16
Laser Scanner Unit (Fig.8) 18
Developer (Fig.9) 20
Upper-Half (Electrical) (Fig.10) 22
Lower-Half (Electrical) (Fig.11) 24
Paper-Feed (Electrical) (Fig.12) 26
Face-Down Unit (Electrical) (Fig.13) 28
Fuser (Electrical) (Fig.14) 30
Upper-Half (Harness) (Fig.15a) 32
Lower-Half (Harness) (Fig.15b) 34
Sorter (Optional) (Fig.16) 36
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
Consumables and Maintanence Kits
TK-2 Toner Kit
DK-2 Drum (10K pages)
DV-3 Developer (50K pages)
FK-2 Fuser (80K pages)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 2
Fig.1 - Covers
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 3
Ref No. Part Code Description Quantity
01-00A 5AAMW1****09 Tray Assy 2
01-00B 5AAVCOVER121 Top Cover Assy 1
01-00C 5AAVCOVER123 Front Cover Assy 1
01-00D 5AAVBASE*006 Base Assy 1
01-005 5MVX875SW003 Right Cover 1
01-006 5AAYF2010*23 Keyboard Assy 1
01-009 Lock Nut 3
01-011 5MVX864SH001 Controller Panel F 1
01-012 5MVX531SH001 Panel Cover 1
01-013 5MVX962SW002 Rear Cover 1
01-014 5MVX942SW001 Blind Cover 1
01-015 5MVB762SW012 Left Cover 1
01-016 5MVB873SH011 Controller Panel R 1
01-017 5MVB222RB001 Cord Press 2
01-018 5MVX631SH001 Option Cover 1
01-019 5MVX866SW003 FD Sub Cover 1
01-020 5MMX863SX001 FD ES Eliminator 1
01-022 5MMW904LJ002 Paper Stopper 2
5MVB873SH012 DLP COVER 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 4
Fig.2 - Upper Frame
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 5
Ref No. Part Code Description Quantity
02-00A 5AAVLEVER010 DLP Lever Assy 1
02-007 5MVX662SB011 DLP Guide R 1
02-008 5MVX662SB012 DLP Guide F 1
02-009 5MMW905SM001 Torsion Bar A 1
02-010 5MMW905SM002 Torsion Bar B 1
02-011 5AAVFRAME048 Frame Assy 1
02-012 5MMX744SL001 Wire Support 1
02-013 5MVG138DB002 Drum Gear Z30 1
02-014 5MVX665CB01% Drum Bearing 1
02-015 5MVB773SB002 Nozzle B 1
02-016 5AAYW3****01 Filter Assy 1
02-017 5MVS229RB008 Nozzle Seal 1
02-018 5MVS619RB001 Wind Seal 1
02-019 5MMS876SL003 Top Cover Plate 1
02-020 5MVS732KN001 Toner Shutter 1
02-021 5MVS838RB002 Scanner Pad 1
02-022 5MMX433LJ002 Cleaner Pressure 2
02-023 5MVS648RB003 Fuser Upper Pad B 1
02-024 5MVS768RB003 Fuser Upper Pad A 1
02-025 5MMX474RJ001 Earth Plate C 1
02-026 5MMX653SL006 Connector Bkt 1
02-027 5MVU122DB002 Inter LOck SW Lever 1
02-028 5MVX443DB001 Inter Lock SW Bkt B 1
02-029 5AAXSW020GEA Hopper SW Assy 1
02-030 5MVB862SB001 M Feed Upper Guide 1
02-031 5MMP153CJ001 Frame Earth F 1
02-032 5MMW161LJ008 Sensor Spring A 1
02-033 5MVX442SB003 M Feed Sens Actuator 1
02-034 5MVM177DJ001 Drum Brushing R 1
02-035 5MVX622DB001 DLP Cam Lever B 1
02-036 5MVX643CX001 DLP Cam Lever 1
02-037 5MVX861SL003 Hinge Arm 1
02-038 5MML144SL001 Hook Plate B 1
02-039 5MVX632DN001 Hinge Hook B 1
02-040 5MMW172LJ003 Hinge Spring 1
02-041 5AAMF3000*02 Unit Rail C Assy 1
02-042 5MMU541SL001 Sorter Connector Bkt 1
02-043 5MMX433SL002 Hook Plate A 1
02-044 5MVX654DN001 Hinge Hook A 1
02-045 5MVK121NN001 Edging Saddle 1
02-046 5MVX331NN002 Wire Saddle 1
02-047 5MVX221DN005 Frame Guide R 1
02-048 5MVX221DB006 Frame Guide F 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 6
Fig.3 - Lower Frame
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 7
Ref No. Part Code Description Quantity
03-00A 5AAYF3000*01 Lock Plate Assy 1
03-00B 5AAYF3000*02 Pressure Arm Assy 1
03-001 5MVS618RB005 Seal A 1
03-002 5MMX641LJ001 TC UP Spring 1
03-003 5MMX852AJ002 TC Discharger 1
03-004 5MVS533KN001 Blind Sheet 1
03-005 5MMU863SX001 Paper Guide Plate 1
03-006 5MVS218RB005 Seal D 1
03-007 5MVS618RB003 Seal C 1
03-008 5MMX662SL003 Base Hinge Plate R 1
03-009 5MMX764SL002 Frame Arm R 1
03-010 5MMX764SL004 Frame Arm L 1
03-011 5MVX865SB002 Inner Cover R 1
03-012 5MVB222RB001 Cord Press 8
03-013 5MMX622SL001 Base Hinge Plate L 1
03-014 5MMT264LJ006 Bar Stopper 1
03-015 5MML622LJ001 Bar Stopper Spring 1
03-016 5MMX762CJ001 Controller Earth B 1
03-017 5MMZ173SL001 Earth Plate 1
03-018 5MVX964SB002 Inner Cover F 1
03-021 5MMX222RJ001 Sensor Earth Plate 1
03-022 5MMS746SB001 Sensor Plate 1
03-023 5MVS622KF001 Guide Sheet R 1
03-024 5MVS722KF001 Guide Sheet F 1
03-025 5MVS428RH002 Tank Pad A 1
03-026 5MVS439RH002 Tank Pad B 1
03-027 5MMC832SL001 Base Support 1
03-029 5MVX832DB001 Controller Guide B 1
03-030 5MMX752CJ001 Controller Earth A 1
03-031 5MVX822DB001 Controller Guide A 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 8
Fig.4 - Unit Bottom
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 9
Ref No. Part Code Description Quantity
04-001 5MVN273SB002 Knob 2
04-002 5EZNF2402501*01 Fan Motor B 1
04-003 5AAVCOVER102 Cont.Box R Cov Assy 1
04-005 5AACCNDE8GEA Conn Cord Assy CA3 1
04-006 5AAEZF1000*4 DC Power Supply 240V 1
04-007 5MML876SL002 P/S Support KC 1
04-008 5MVS872KF001 Sheet MT 1
04-009 5MMT263SN001 Socket Main Logic 4
04-011 5MVC811CL001 PCB Guide Rail 2
04-012 5AAPRCZG4004CH P.W.B KP-017 1332.40 1
04-013 5MMX876SL007 Cont Middle Plate KC 1
04-014 5AACCNBZ2GEA Conn Cord Assy CA9 1
04-015 5MMX421SL002 Cont Box Stopper KC 1
04-016 5AAVFRAMEE044 Cont Boc Assy KC 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 10
Fig.5 - Drive Mechanism
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 11
Ref No. Part Code Description Quantity
05-00A 5AAYF3000*09 Drive Unit 1
05-010 5MMG138SX005 Motor Gear Z30 1
05-011 5EZNS200R701*01 DC Motor Gear Assy 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 12
Fig.6 - Paper-feed Assembly
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 13
Ref No. Part Code Description Quantity
06-000 5AAYF3000*37 Paper-Feed Assy
06-00A 5AAVCLTCH005 Manual Feed Clutch
06-00B 5AAMF2010*01 MF Plate Assy
06-00E 5AAVROLL*008 Feed Tyre Assy
06-001 Feed Clutch Bkt
06-002 M Feed CL Cam Spring
06-003 5MMVX432DW001 M Feed CL Cam Lev B
06-004 Solenoid Pad
06-013 5MMM176CJ003 Metal Bush KD
06-016 5MVG136DN011 Feed Unit Gear Z28
06-017 5MVG169DB001 Feed Unit Gear Z65
06-018 5MMM121XJ001 Regist Roller Bush
06-019 5MMW345LJ002 Regist Spring A
06-020 Cassette Guide UR
06-021 Cassette Guide LR
06-022 5MMW341LJ001 M Feed Spring
06-023 MF Bush
06-024 Feed Unit Frame R
06-025 Guide Sheet PS
06-026 M Feed Paper Chute A
06-027 M Feed Paper Chute B
06-028 Paper Guide
06-029 5MVX331DB003 Actuator B
06-030 5MVX532DB002 Actuator A
06-031 5MMW163LJ002 Sensor Spring
06-032 5MVX532DD002 TC Guide
06-033 TC Supporter
06-034 Seal B
06-035 Cover Sheet
06-042 Feed Unit Stay A
06-043 Sensor Cover
06-044 Paper Holder
06-045 Feed Unit Stay B
06-046 Sensor Plate A
06-047 5MMT876SN009 M Feed Roller B
06-048 5MMT876SN008 M Feed Roller A
06-049 5MMT866SN003 Regist Roller A
06-050 5MMT876SN018 Regist Roller B
06-051 Cassette Guide UF
06-052 Cassette Guide LF
06-053 5MVG127DN017 Regist Gear Z20
06-054 5MVG147DN001 Regist Gear Z32
06-055 5MMX875SL001 Feed Unit Frame F
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 14
Ref No. Part Code Description Quantity
06-056 5MVX532SB002 Main SW Bkt
06-057 5MVS521KC001 Paper Chute Guide
06-059 Feed Roll Shaft
06-063 Joint Gear Plate
06-064 5MVG148DN008 Gear Z36
06-065 5MVM197DN001 Collar 40
06-066 5MVG169DN003 Feed Gear Z65
06-067 Joint Support
06-068 5MMW241LJ009 Regist Spring
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 15
Fig.7 - Face-down Unit
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 16
Ref No. Part Code Description Quantity
07-000 5AAYF3000*41 Face-Down Unit 1
07-001 5MVX422DB002 Jam Actuator 1
07-002 FU Actuator Spring 1
07-003 5MVX852CB001 FD Paper Guide 1
07-004 5MMX321LJ005 Exit Pulley Bracket 4
07-005 5MVM123DB001 FD Feed Pulley 4
07-006 5MMT876SN016 FD Enter Roller 1
07-007 Seal C 2
07-008 5MMT876SN015 FD Exit Roller 1
07-009 5MMW163LJ001 FD Actuator SP 1
07-010 5MVX422DB003 FD Jam Actuator 1
07-011 FD Guide 1
07-012 Side Plate 1
07-013 5MVM176DN009 Bearing 6
07-014 5MVG127DB002 FD Exit Gear 1
07-015 5MVG022DB001 Belt Pulley Gear 1
07-016 Pulley Flange 1
07-017 5MVX917RB001 FD Belt 1
07-018 5MVM177DB004 Belt Idle Pulley 3
07-019 5MVG327DB001 Belt Pulley 2
07-020 Idle Spring 1
07-021 Idle Bracket 1
07-022 5MVG127DB001 FD Joint Gear Z20 1
07-023 FD Spring R 1
07-024 FD Magnet Plate 4
07-025 FD Magnet 2
07-026 FD Cover 1
07-028 5MVM174DB001 FD Exit Pulley 11
07-029 FD Pin 2
07-030 5MMU131LX001 FD Presser 4
07-031 5MVM474DB001 FD Pulley B 2
07-032 5MMT876SN017 FD Middle Roller 1
07-033 FD Outlet Cover Assy 1
07-034 FD Switch Cover 1
07-035 Solenoid Spring 1
07-036 FD Spring F 1
07-037 5MVX211DB002 Link Plate 1
07-038 Change Plate 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 17
Fig.8 - Laser Scanner Unit
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 18
Ref No. Part Code Description Quantity
08-000 5AAYF3000*11 Scanner Unit 240V 1
08-002 5MVS422SB001 Scanner Cover Lid 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 19
Fig.9 - Developer
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 20
Ref No. Part Code Description Quantity
09-000 DV-3 Developer Unit 1
09-009 5AAXTS003GEA Toner Sensor Assy 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 21
Fig.10 - Upper-Half (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 22
Ref No. Part Code Description Quantity
10-00A 5AAYF3000*29 Eraser Assy 1
10-001 5ETNB60101***01 Developer Bias PWB 1
10-002 5AAPRCZG2003BH Panel Cont.Board 1
10-003 5AAPRZZ003BA Motor Control PWB 1
10-004 Total Counter 1
10-005 Counter Bkt KC 1
10-006 Panel Board Bkt 1
10-007 5ETNB66202***01 Main Hv Unit 1
10-008 5MVX543XN001 MCH Connect 1
10-009 5ENXGP1A05HR*01 Sensor GP1A05HR 2
10-010 5EZNF2403001*01 Fan Motor A 1
10-011 5AAPRAPC1004*01 APC PWB 1
10-015 5AAPRZZC1005AH Polygon Driver PWB 1
10-016 5AAPRZZ005AA PWB Assy Life Count 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 23
Fig.11 - Lower-Half (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 24
Ref No. Part Code Description Quantity
11-001 5AACAC278EEA POWER CORD ASSY 250V 6A 1
11-002 INLET COVER 1
11-003 5AACCNDE7GEA INLET ASSY CCA4001 1
11-004 INLET BRACKET 1
11-005 5ETNB66201***01 TRANSFER HV UNIT HVC-3MC60 1
11-006 EDGING SADDLE EDS-1 2
11-007 CORD PART PLATE 1
11-008 5EFNZSB22100501 NOISE FILTER 250V 15A(EUROPE) 1
11-009 5EZRlG012301*01 SOLID STATE RELAY 220V-240V 1
11-010 ELEC.PLATE 1
11-011 5AAPRHCG2004AH HEAT CONTROL PWB 1
11-012 5AAXAP002GEA CASSETTE SENSOR ASSY 1
11-013 5AAPRSS005FA PEP BOARD ASSY B PHOTOTRANSISTOR
1
11-015 SW BRACKET 1
11-016 5ESC020103***01 MAIN SWITCH J-U1054 1
11-017 LINE FUSE 125V lOA 1
11-018 FUSE BLOCK 120V 1
11-019 5EYFBQ50205**01 LINE FUSE 250V 5A 1
11-020 5EYHF102004**01 FUSE BLOCK 220V-240V 1
11-021 5MVX332XHOO1 TC RECEPTACLE 1
11-022 HARNESS 1
11-023 HVC PLATE 1
11-024 HVC HOLDER 1
11-025 HVC SPRING 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 25
Fig.12 - Paper-Feed (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 26
Ref No. Part Code Description Quantity
12-001 Cable Assy PCA2032 1
12-002 5EZSA2403010305 Solenoid A-3 1
12-003 5EYYAFAAE03**01 Micro Clutch 1
12-004 5EYYAFAAE02**01 Micro Clutch 1
12-005 5EYYAFAAE01**01 Micro Clutch 1
12-006 Solenoid Pad 1
12-007 5ENXGP1A05HR*01 Sensor GP1A05HR 1
12-008 5AAXAP002GEA Cassette Sensor Assy 1
12-009 5AAPRSS005HA PEP PWB Assy H LED 1
12-010 5AAPRSS005EA PEP Board Assy E 1
12-011 5AAPRSS005DA PEP Board Assy D 1
12-012 Cable Assy CCA5022 1
12-013 Mini Clamp 1
12-014 5AAXSW018GEA Inter Lock SW Assy 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 27
Fig.13 - Face-Down Unit (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 28
Ref No. Part Code Description Quantity
13-001 Cable Assy CCA2020 1
13-002 5ENXGP1A05HR*01 Sensor GP1A05HR 1
13-003 5EZSA2401020301 Solenoid C TDS-KN07A 1
13-004 5AAXSW019GEA FD SW Assy CCA2017 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 29
Fig.14 - Fuser (Electrical)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 30
Ref No. Part Code Description Quantity
14-000 FK-2 Fuser 220V-240V 1
14-001 5EZPB2413320202 Heater Lamp 240V 800W 1
14-002 5ENTTC180P1.203 Thermistor 1
14-006 5AAXTF005VDA Thermal Fuse Assy 1
14-007 5MMT887AM003 FIXING ROLLER 1
14-008 5MMT886SX012 PRESS ROLLER 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 31
Fig.15a - Upper-Half (Harness)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 32
Ref No. Part Code Description Quantity
15-001 Cable Assy PCA2039 1
15-002 Cable Assy PCA3041 1
15-003 Bushing 2
15-004 Cable Assy YC-5 1
15-005 Cable Assy CCA3021 1
15-006 Cable Assy Sorter 1
15-007 Cable Assy CA1 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 33
Fig.15b - Lower-Half (Harness)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 34
Ref No. Part Code Description Quantity
15-002 Cable Assy CA8 1
15-009 Cable Assy CCA4002 1
15-010 Cable Assy CCA4023 1
15-011 Cable Assy CCA4004 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 35
Fig.16 - Sorter (Optional)
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 36
Ref No. Part Code Description Quantity
16-001 Cabinet 1
16-002 Base Plate 1
16-003 Foot 3
16-004 5SNSP0006964 Photo Sensor Assy L 1
16-005 Cushioning 2
16-006 Stand 1
16-007 Stand Cover 2
16-008 Stand Spring 1
16-010 5SNSP0006970 Solenoid Assy 1
16-011 Stopper Assy 1
16-012 Cable Clamp DNK-05 2
16-013 Side Frame R H 1
16-014 Tray Guide 2
16-015 Sheet R 1
16-016 5SNSP0006981 Motor 1
16-017 Motor Harness Assy 1
16-018 Motor Gear 1
16-019 SE RING 1
16-020 Ground Wire Assy 2
16-021 Left Frame 1
16-023 Sheet L 1
16-025 Arm 2
16-027 Stud Spring 2
16-028 Link Plate B 2
16-029 Bearing Bush 3
16-030 Drive Shaft 1
16-031 Clank Pulley Gear 1
16-032 Stopper Plate 1
16-033 Link Plate C 1
16-035 Sensor Plate 1
16-037 Feed Roller Shaft 1
16-038 Roller 2
16-039 Feed Pulley 2
16-040 Bearing Bush 2
16-041 Down B Baffle 1
16-042 Front Paper Stopper 2
16-043 Up B Baffle 1
16-045 Feed Shaft 1
16-046 Roller 2
16-047 Idler Bkt Assy 1
16-048 Idler Spacer 1
16-049 Feed Roller Gear 1
16-050 Idler Gear Collar 1
16-051 Idler Gear 1
16-052 Gear Idler 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 37
Ref No. Part Code Description Quantity
16-053 Roller Rension Spring 2
16-054 5SNSP0007021 Main PWB Assy 1
16-055 PWB Spacer 1
16-056 Joint Bracket 1
16-057 Control Cable Assy 1
16-059 Sensor Bracket 1
16-060 5SNSP0007028 Up Sensor 1
16-064 L-50 Support Wire 1
16-065 Tray Spring 2
16-067 5 Bin A Tray 1
16-068 Tongue 12
16-069 Paper Stopper 2
16-070 Paper Guide Tongue 2
16-071 5 Bin B Tray 4
16-072 Rear Paper Stopper 8
16-073 Cushion Tray Assy 2
16-074 A Plate Link 8
16-075 Erase Assy 1
16-076 Support Bracket 1
16-077 #1 Paper Holder 1
16-078 PWB Support 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA F-3000 Page 38
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
