Image preview - the first page of the document
>> Download Kyocera FS-6500 Parts Manual documenatation <<
Text preview - extract from the document
PAGE PRINTER
FS-6500 / FS-6500+
PARTS CATALOGUE
11-11-1998
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 1
FS-6500 / FS-6500+ Parts Catalogue
Table of Contents
Frame Unit (Fig.1) 3
Enclosure Unit (Fig.2) 5
Developer Unit (Fig.3) 7
Fuser Unit (Fig.4) 9
Controller Unit (Fig.5) 11
Drum LED Head Unit (Fig.6) 13
Feed Trans Unit (Fig.7) 16
Drive Unit (Fig.8) 19
Paper Cassette (Fig.9) 21
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
Consumables and Maintanence Kits
TK-12 Toner Kit
G-2 Grid Cleaner
MK-5 / MK- Maintenance Kit (300K pages)
Drum
Developer
Fuser
Drive Assy
Feed Trans Assy
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 2
01-007
PAGE PRINTER - Parts Catalogue
01-420
01-014
01-416
01-409
01-410
01-418
01-002
01-414
01-415
01-405
KYOCERA FS-6500 / FS-6500+
01-001
01-013 01-401
Fig.1 - Frame Unit
01-404
01-308
01-311
01-403
01-001
01-301 01-310
01-406
01-305
01-407
01-308
01-309
01-005
01-305
01-302
01-304
01-303
01-306
01-307
Page 3
Ref No. Part Code Description Quantity
01-001 5MMU211SD007 CASE STOPPER 2
01-002 5MVX832SW001 ROD SW POWER 1
01-003 5AAY6500J*60 FRONT FRAME ASSY 1
01-004 5AAY6500J*61 LEFT FRAME ASSY 1
01-005 5EZNF2402501*03 FAN MOTOR 1
01-006 5MMS443SL001 PLATE HINGE R 1
01-007 5MMS643SL001 PLATE HINGE L 1
01-008 5MMW567LD002 SPRING FD L 1
01-009 5MMW567LD003 SPRING FD R 1
01-010 5MVS321KF016 SHEET FRAME A 2
01-011 5AACCNNS2GEA CON CORD ASSY 1
01-012 5AACCNNW8GEA CON CORD ASSY 1
01-013 5AAXTR033VDA TRANS ASSY 1
01-014 5AAPRPWC1004GH PWB ASSY 1
01-025 5EYBF4601200101 FERRIE CODE 1
01-301 5MVX976SB001 CHANNEL FRONT 1
01-302 5MVX864SB009 LATCH COVER 1
01-303 5MMW261LD007 SPRING LATCH 1
01-304 5MMT976SN005 ROLLER MANUAL UP 1
01-305 5MVX322SB012 ACTUATOR MANUAL 1
01-306 5MVM176DN018 BUSH MANUAL 2
01-307 5EYYAFAAQ01**02 CLUTCH FEED 1
01-308 5MML121LD003 PLATE EARTH EF 2
01-309 5MML232LD002 PLATE EARTH MANUAL 1
01-310 5AAPRSSC1006EH PWB ASSY 1
01-311 5AACCNNV8GEA CONN. CORD ASSY 1
01-313 5MVM176DN016 BUSH A 2
01-401 5MVX876CB002 FRAME LEFT 1
01-403 5MMU411LD001 PLATE RECEPTACLE A 1
01-404 5MMZ142LD002 PLATE RECEPTACLE B 1
01-405 5AAXRD012GEA HIGH MEG R ASSY 1
01-406 5MMU311LD002 PLATE EARTH SPRING 1
01-407 5MMZ221LD001 LOCK DLP 1
01-409 5MVB322SB004 GUIDE SENSOR 1
01-410 5MMW161LD022 SPRING GUIDE 1
01-414 5AAPRSSC1010AH AC PWB ASSY 1
01-415 5AACCNNS1GEA CONN. CORD ASSY 1
01-416 5AACCNNT5GEA CONN. CORD ASSY 1
01-417 5AACCNNT4GEA CONN. CORD ASSY 1
01-418 5AAY3400E*19 DRUM THERMISTOR ASSY 1
01-420 5AAXCB003GEA W74 COUNTER ASSY 1
01-00X 5AAPRIFC1004AH CONNECTOR BOARD 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 4
06-006
06-005
PAGE PRINTER - Parts Catalogue
06-011
02-003
02-009
01-008
06-013
06-010
KYOCERA FS-6500 / FS-6500+
Fig.2 - Enclosure Unit
02-001 02-002
06-007
02-011
02-008
02-007
02-006 01-009
02-010
01-005
06-002
06-001
02-004
01-005
06-015
Page 5
06-014
06-008
06-004
Ref No. Part Code Description Quantity
06-001 5MVB984SH005 COVER FRONT 1
06-002 5AAFZ6500E*1 KEYBOARD ASSY(FS-6500) 1
06-002 5AAFZ6500NE1 KEYBOARD ASSY(FS-6500+) 1
06-004 5MVX862SH004 LID COVER FRONT 1
06-005 5MVB986SH021 COVER TOP 1
06-006 5MVB762SH024 TRAY FACE DOWN 1
06-007 5MVB883SH030 COVER LEFT 1
06-008 5MVB883SH029 COVER RIGHT 1
06-009 5MVVS6500E*1 SER NO. PLATE 1
06-010 5MVN260SH001 KNOB RELEASE 1
06-011 5MVM273DB002 PULLEY FD 4
06-013 5MMW266LD002 SPRING KNOB 1
06-014 5MMW561LD001 SPRING COVER 1
06-015 5MVM476SW001 CAP PRESS COVER 1
06-016 5MMW361LD006 SPRING POWER 1
06-017 5MVVL871WN12 LABEL DIAGRAM 1
06-019 5MMX322LD011 BKT PULLEY FD 4
06-020 5AAPRZZC2004CH PWB ASSY 1
02-001 5MVX866SH010 GUIDE FD 1
02-002 5MMT875LD003 ROLLER FD 1
02-003 5MVM176DB008 BUSHING STOP 1
02-004 5MMX632SL008 PLATE FD JOINT 1
02-005 5MVG138DB020 GEAR FD Z30 1
02-006 5MVG148DB010 GEAR FEED Z34 1
02-007 5MVS813AQ001 BRUSH DISCHARGER 1
02-008 5MVG127DB039 GEAR EXIT Z18 1
02-009 5MMZ665SL001 PLATE FD HINGE L 1
02-010 5MMZ665SL002 PLATE FD HINGE R 1
02-011 5MMM176CJ005 BUSHING SBK 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 6
03-027
PAGE PRINTER - Parts Catalogue
03-015
03-026
03-028
KYOCERA FS-6500 / FS-6500+
Fig.3 - Developer Unit
03-014
03-012 03-010
03-030
03-029 03-024
03-025
03-023
03-003
03-033
03-022
03-018
03-031
03-004
03-008
03-001 03-005
Page 7
03-002
03-011
03-009 03-006
03-007
03-013
03-019
Ref No. Part Code Description Quantity
03-000 DV-56 DEVELOPER KIT (5PLPZQUAPKE) 1
03-001 5MVB876SB010 CASE DLP 1
03-002 5AAXTS019GEA TONER SENSOR ASSY 1
03-003 5MVS651KJ001 TAPE SENSOR FACE 1
03-004 5MVM170DB005 BUSH MIXER B 1
03-005 5MVG148DB027 GEAR MIXER Z38-Z40 1
03-006 5MVG138DB046 GEAR IDLE Z29-Z14 1
03-007 5MVG138DB050 GEAR Z27 1
03-008 5MVG127DB037 GEAR Z14 1
03-009 5MVS511YF001 SEAL SIDE DLP 2
03-010 5AAVROLER028 ROLLER MAGNET 1
03-011 5MVX764CB001 FLANGE MG DLP 1
03-012 5MMS323LD001 PLATE BIAS 1
03-013 5MVF176CW001 CAP MG L 1
03-014 5MVF276CW001 CAP MG R 1
03-015 5MVS869FD002 SHUTTER MG 1
03-018 5MVB543SB003 COVER PWB 1
03-019 5MVM166DN004 BUSH MIXER GEAR 1
03-022 5MVVL732WN10 LABEL DLP 1
03-023 5AAY6500J*62 MIXER ASSY 1
03-024 5AAY6500J*65 BLADE ASSY 1
03-025 5AAY6500J*66 COVER MG ASSY 1
03-026 5AAY6500J*67 COVER SHUTTER ASSY 1
03-027 5AAY6500J*68 TONER MOTOR ASSY 1
03-028 5AAY6500J*69 LID ASSY 1
03-029 5MVS541KF004 SHEET CASE 1
03-030 5MVS327KF001 SHEET MIXER 1
03-031 5MMX668RB001 OIL SEAL 1
03-032 5MBWK41805NN FLAT S WASHER 1
03-033 5AAPRCZC1004BH PWB ASSY 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 8
04-038
PAGE PRINTER - Parts Catalogue
04-044
04-035
04-001
04-004
04-045
04-A03
04-005
04-010
04-015 04-017
04-046 04-006
KYOCERA FS-6500 / FS-6500+
04-024
04-040
04-009
Fig.4 - Fuser Unit
04-020 04-002
04-008 04-016
04-012
04-003 04-036
04-021
04-030
04-025
04-023
04-032
04-027 04-042
04-012
04-043
04-031
04-028
04-018
04-014
04-013
04-018
04-028
Page 9
04-033
04-033
04-019
04-029 04-026
04-041
Ref No. Part Code Description Quantity
04-000 FK-56 FUSER KIT (5PLPZQSAPKE) 1
04-001 5MVX875XB002 FRAME FUSER UP 1
04-002 5EYFFQ16101**01 THERMO STAT 1
04-003 5MMX633RD001 HOLDER LAMP R 1
04-004 5AAXTM008GEA THERMISTOR ASSY 1
04-005 5MMW351LD002 SPRING SEPARATOR 5
04-006 5MVX332XN003 SEPARATOR 5
04-008 5MMT833SN003 SHAFT EXIT 1
04-009 5MVM174DB002 PULLEY EXIT 4
04-010 5MMW251LD016 SPRING PULLEY 2
04-012 5MVM148XN001 BUSH HEAT 2
04-013 5MVG158XN002 GEAR Z44S 1
04-014 5MVX832XB002 HOLDER FUSER UP 1
04-015 5MVG138XN007 GEAR JOINT Z26 1
04-016 5MVG137DB026 GEAR IDLE Z21 1
04-017 5MVG137DB025 GEAR M FEED Z25 1
04-018 5MMW181SB001 RING STOP 2
04-019 5MVX875XB001 FRAME FUSER LOW 1
04-020 5MVX822XB003 GUIDE ENTRANCE 1
04-021 5MVX732CB002 ACTUATOR FUSER 1
04-023 5MMT875LD002 ROLLER EXIT 1
04-024 5MVM176DB006 BUSHING POM 1
04-025 5MMM176CJ005 BUSHING SBK 1
04-026 5MMX321LD022 PLATE EARTH FUSER 1
04-027 5MMT886SX019 ROLLER PRESS 1
04-028 5MVM166XN001 BUSHING PRESS 2
04-029 5MMS727SL001 PLATE PRESS 1
04-030 5MMX432SL004 PLATE RELEASE L 1
04-031 5MMX432SL005 PLATE RELEASE R 1
04-032 5MVG127DB018 GEAR EXIT Z16 1
04-033 5MMW251LD022 SPRING PRESS 2
04-035 5MVX665XB001 COVER FUSER L 1
04-036 5MVX763XB001 COVER FUSER R 1
04-038 5MMX321RD005 HOLDER LAMP L 1
04-040 5AACCNNS4GEA CON. CORD ASSY 1
04-041 5MML737SD001 PLATE PRESS R 1
04-042 5MMT888AX009 ROLLER HEAT 1
04-043 5MMW362LD001 SPRING ACTUATOR 1
04-044 5MVVL721WN25 LABEL FUSER CAUTION 1
04-045 5EZPZ2412920101 LAMP HEATER 240V 1
04-046 5MVX842CB005 GUIDE CHANGE 1
04-A03 5AAPRIFC1005AH P.W. BOARD ASSY 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 10
05-011
PAGE PRINTER - Parts Catalogue
05-021
05-006
05-002
KYOCERA FS-6500 / FS-6500+
05-005
Fig.5 - Controller Unit
05-020
05-028 05-005
05-008
05-003
05-A02
05-027
05-023
05-024
05-A04
Page 11
05-022
05-004 05-004
05-010
Ref No. Part Code Description Quantity
05-002 5MMS646SD007 PLATE CONNECT 8N 1
05-003 5MMB851SD004 PANEL REAR 1
05-004 5MVM160RB025 FOOT 4
05-005 5MVM266SB003 PULL KNOB 2
05-006 5MVS636VB003 SHEET ENGINE POM 1
05-007 5MVS532KF002 SHEET TRANS 1
05-008 5MVX732SL002 RAIL PWB MAIN 1
05-010 5AAVBOX**002 BOX ASSY 1
05-011 5MMS986SD003 LID CONTROLLER 1
05-013 5AACCNNS5GEA CONN. CORD ASSY 1
05-014 5AACCNNS7GEA CONN. CORD ASSY 1
05-015 5AACCNNS8GEA CONN. CORD ASSY 1
05-016 5AACCNNT2GEA CONN. CORD ASSY 1
05-017 5AACCNNS9GEA CONN. CORD ASSY 1
05-018 5AACCNNR6GEA CONN. CORD ASSY 1
05-019 5AACCNNR7GEA CONN. CORD ASSY 1
05-020 5AAEZ3600E*1 SWITCHING REGULATOR 1
05-021 5MMC621LD002 PLATE RELEASE CAS 1
05-022 5MMS337SD003 PLATE FAN 1
05-023 5MVS853KN002 SHEET CONT BOX 1
05-024 5MVS447XF001 SEAL BOX FAN 1
05-025 5EYBE1641600102 FERRITE CORE 1
05-026 5MVS775CC001 SHEET PWB ASSY 1
05-027 5EZNF0509001*02 FAN MOTOR 1
05-028 5AAPRZZC1043AH PWB ASSY SENSOR 1
05-A02 5AAPRCZC2001BH PWB ASSY ENGINE(FS-6500) 1
05-A02 5AAPRCZC2002BH PWB ASSY ENGINE(FS-6500+) 1
05-A04 5AAPRLGG4022DH PWB ASSY MAIN(FS-6500) 1
05-A04 5AAPRLGG4022HH PWB ASSY MAIN(FS-6500+) 1
05-00X 5MVB544SB002 HOLDER ACTUATOR 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 12
07-013
07-040
07-047
PAGE PRINTER - Parts Catalogue
07-039
07-011
07-048
07-041
07-004
07-003 07-047
07-006
07-005
07-012
07-002
KYOCERA FS-6500 / FS-6500+
07-009
Fig.6 - Drum LED Head Unit
07-023
07-008
07-022 07-007
07-016
07-045
07-033 07-035
07-017
07-010
07-028
07-018
07-036 07-042
07-015
07-001
07-029
07-024 07-025
07-049 07-035
07-044
07-027
07-034
Page 13
07-030
07-037 07-026
07-019
07-046
07-021
Ref No. Part Code Description Quantity
07-000 DK-56 DRUM KIT (5PLPZQWAPKE) 1
07-000 LK-55 LED HEAD (5PLPZQVAPKE) 1
07-001 5AAY6500J*70 MCH ASSY 1
07-002 5AAY6500E*22 DRUM ASSY 1
07-003 5AAY6500J*63 CASE BELT ASSY 1
07-004 5MVB966CB001 FRAME DRUM UP 1
07-005 5AAXLD026GEA LED ASSY 1
07-006 5MMT343SN004 PIN IDLER D 2
07-007 5MVG127DN039 GEAR H14 1
07-008 5MVG047DN002 GEAR H37-H18 1
07-009 5MMZ322LD004 PLATE ZENNER A 1
07-010 5MMX433LD003 PLATE ZENNER B 1
07-011 5MMZ332LD002 PLATE MCH 1
07-012 5MVB632SB007 COVER ZENNER 1
07-013 5MVB654CB001 HOLDER CASE BELT 1
07-015 5MVX966CB001 FRAME DRUM LOW 1
07-016 5AAVBRUSH039 CONTACT BRUSH L ASSY 1
07-017 5MVS226RF013 SHEET BRUSH A 1
07-018 5MVS222XF008 SHEET BRUSH B 1
07-019 5MML811LD003 PLATE SHEET 1
07-020 5MVS816RN001 SHEET DRUM 1
07-021 5MVS821KN017 SHEET CLN 1
07-022 5MVS328LN001 SEAL RING LEFT 1
07-023 5MMT864CB003 SCREW 1
07-024 5MMT876SN024 ROLL CLN 1
07-025 5MVT860SN002 ROLL MAGIC 1
07-026 5MVQ321DN004 BUSH A 1
07-027 5MVQ321XN001 BUSH B 1
07-028 5MVQ321XN002 BUSH C 1
07-029 5MVG127DN038 GEAR H14S 1
07-030 5MVG137DN013 GEAR H22 1
07-033 5MMW241LD011 SPRING ROLL E 1
07-034 5MMW241LD005 SPRING ROLL B 1
07-035 5MVS318KN001 SEAL BLADE 1
07-036 5MVS428LN004 SEAL DRUM L 1
07-037 5MVS428LN005 SEAL DRUM R 1
07-039 5MMB211SB009 LED STOPPER 2
07-040 5MMW254LD003 SPRING CASE BELT 1
07-041 5MMS831AX003 SEAL HEAT UP 2
07-042 5MMS921AX001 SEAL HEAT LOW 1
07-044 5MVS811XF005 TAPE PLATE DRUM 1
07-045 5AAPRCZC1003AH PWB ASSY 1
07-046 5MVS823KN002 SHEET DRUM LOW 1
07-047 5MVS217RF019 SHEET MCM 3
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 14
Ref No. Part Code Description Quantity
07-048 5MMS721AX001 SEAL HEAT A 2
07-049 5AAY6500J*77 BLADE UNIT 1
07-00T 5AAPRLDC2004DH PWB ASSY 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 15
08-029
08-063
08-009 08-001
08-054
08-059
08-042
PAGE PRINTER - Parts Catalogue
08-035
08-057 08-040
08-019
08-046
08-036
08-067 08-059
08-053 08-037
08-030
08-054 08-049
08-060 08-045
08-023 08-022 08-004
KYOCERA FS-6500 / FS-6500+
08-061 08-012
08-028
08-056
Fig.7 - Feed Trans Unit
08-008
08-038
08-013
08-024
08-026
08-048
08-028
08-019 08-041 08-016
08-058
08-003
08-005
08-020
08-014
08-006
Page 16
08-011
08-007
08-027
08-025 08-050 08-002 08-062
08-010
08-066 08-055
08-066
08-065
08-064
Ref No. Part Code Description Quantity
08-000 5AAY6500J*44 FEED TRANS UNIT(FS-6500) 1
08-000 5AAY6500D*02 FEED TRANS UNIT(FS-6500+) 1
08-001 5MMT876SN043 ROLLER REGIST UP 1
08-002 5MMT876SN044 ROLLER REGIST LOW 1
08-003 5MVG137DB059 GEAR REGIST Z24-Z26 1
08-004 5MVG127DB038 GEAR REGIST Z19 1
08-005 5MVG138DB029 GEAR IDLE Z26 2
08-006 5MVM121DB001 COLLER JOINT 2
08-007 5MVG138DB052 FEED WHEEL 1
08-008 5MVX875SH005 GUIDE PAPER A 1
08-009 5AAY6500J*78 SENSOR DOC 1
08-010 5MVX655SX001 LEVER LOCK 1
08-011 5MVX711DB002 LINK LOCK 1
08-012 5MMX643LD002 PLATE EARTH CONTACT 1
08-013 5MVB986SH022 LOWER CASE 1
08-014 5MVX431DB003 HINGE LOCK R 1
08-016 5MVX322DN002 GUIDE PAPER B 6
08-018 5MVS821KF018 SHEET REGIST B 1
08-019 5MMT866SN021 SHAFT GUIDE 1
08-020 5MVM687DB001 ROLLER GUIDE 4
08-022 5MVM460DB001 ROLLER IDLE 4
08-023 5MMW255LD003 SPRING MANUAL 2
08-024 5MMT866SN020 SHAFT RELEASE 1
08-025 5MVX745CB001 ACTUATOR CASSETTE A 1
08-026 5MVX321SB012 ACTUATOR CASSETTE B 1
08-027 5AAVROLL*027 FEED ROLL ASSY 1
08-028 5MVM122DB003 BUSH POM 2
08-029 5MVX322DB012 BUSH TRANSFER L 1
08-030 5MVX321DB009 BUSH TRANSFER R 1
08-035 5MMU862SD002 PLATE EARTH 1
08-036 5MMT886SN008 ROLLER TRANSFER 1
08-037 5MVG137DB061 GEAR Z29H TC 1
08-038 5MVS421DB007 HINGE LOCK L 1
08-040 5MVX828CB001 GUIDE CHUTE 1
08-041 5MVM410DB001 HOLDER ROLLER FEED 1
08-042 5MMW163LD004 SPRING SENSOR 1
08-045 5MVM176DB009 BUSH TRANSFER 1
08-046 5MVM276DB007 COUPLING JOINT 1
08-048 5MMW166LD006 SPRING BRACKET 1
08-049 5MMU222SD002 BRACKET JOINT GEAR 1
08-050 5MVM177DB008 BUSH FEED 2
08-053 5AAY6500J*74 BRUSH DC ASSY 1
08-054 5MMW354LD003 SPRING TC ROLL 2
08-055 5MBWK54E08SZ FLAT S WASHER 1
08-056 5MMT243SZ005 PIN BRACKET A 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 17
Ref No. Part Code Description Quantity
08-057 5MMT733SN002 SHAFT MANUAL FEED 1
08-058 5MMW163LD003 SPRING HING R 1
08-059 5MMM276CJ001 METAL BUSH REGIST 2
08-060 5MMW172SX005 SPRING REGIST R 1
08-061 5MMW167LD003 SPRING HING L 1
08-062 5MMW167LD004 SPRING LOCK 1
08-063 5MMW172LD008 SPRING REGIST L 1
08-064 5MVX621SB006 GUIDE PAPER CR 1
08-065 5MVX621SB007 GUIDE PAPER CL 1
08-066 5MMW231LD002 SP GUIDE PAPER C 2
08-067 5MVS811KF017 SHEET DC BRUSH 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-6500 / FS-6500+ Page 18
PAGE PRINTER - Parts Catalogue
09-008
09-001
09-039
09-025
09-027
09-013 09-041
09-014
09-017
09-005
09-003
09-004
KYOCERA FS-6500 / FS-6500+
09-026 09-034 09-040
09-011
Fig.8 - Drive Unit
09-002 09-022
09-006
09-030 09-021
09-013 09-009
09-010 09-032
09-007
09-016 09-031 09-034
09-002
09-033 09-022
09-019
09-024
09-015
09-018
09-029
09-020
09-012
09-028
Page 19
09-023
Ref No. Part Code Description Quantity
09-000 5AAY6500E*19 DRIVE FRAME UNIT 1
09-000 5AAY6500E*25 DRIVE GEAR PACK (FS-6500) 1
09-000 5AAY6550J*17 DRIVE GEAR PACK (FS-6500+) 1
09-001 5MMT263SZ016 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
