Image preview - the first page of the document
>> Download Kyocera FS-800 Parts Manual documenatation <<
Text preview - extract from the document
PAGE PRINTER
FS-800
PARTS CATALOGUE
08-12-1998
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 1
FS-800 Parts Catalogue
Table of Contents
Enclosure (Fig.1) 3
Frame (Fig.2) 5
Drive Assy (Fig.3) 8
Controller (Fig.4) 10
Fuser (Fig.6) 12
Processor Unit (Fig.8) 14
Scanner Unit (Fig.9) 16
Developer Unit (Fig.10) 18
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
Consumables and Maintanence Kits
TK-16 Toner Kit
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 2
01-006
01-003
01-017
01-002
PAGE PRINTER - Parts Catalogue
01-015
01-010
01-009
01-019
01-007 01-021
01-018
01-008
01-005
KYOCERA FS-800
01-020
Fig.1 - Enclosure
01-004
01-012
01-013
01-011
01-016
01-001
Page 3
Ref No. Part Code Description Quantity
01-000 PU-18 Process Unit 5PLPZ5CAEKE 1
01-000 LK-18 Scanner Unit 5PLPZ6CAEKE 1
01-001 5MVB886CH006 Cover Right 1
01-002 5MVB885CH001 Cover Left 1
01-003 5MVB886CH007 Cover Top 1
01-004 5MVB876CH004 Lid Top TM (Europe) 1
01-004 5MVB876CH005 Lid Top S (USA) 1
01-005 5MVX661SH003 Tray Exit FD 1
01-006 5MVX762SH014 Panel Top English 1
01-006 5MVX762SH015 Panel Top French 1
01-006 5MVX762SH018 Panel Top Spanish 1
01-006 5MVX762SH019 Panel Top Italian 1
01-006 5MVX762SH020 Panel Top German 1
01-007 5MVX621SC002 Lens LED 1
01-008 5MVX662SB020 Button 1
01-009 5MVM273DB003 Roller Pinch 1
01-010 5MMX322LD018 BKT Pulley FD 1
01-011 5MVVL771WN16 Label Diagram 1
01-012 Ser No Plate (U) 1
01-013 5MVX322SH002 Lever Shutter 1
01-015 Label Ser Caution 1
01-016 5MVVL771WN17 Label Diagram B 1
01-017 5MVX322DW006 RID Stocker 1
01-018 5MVX441SN002 Holder LCD 1
01-019 5MVS756CN004 Cover Panel 1
01-020 5AAPRCZC2005AH Panel PWB Assy KP-655 1
01-021 5AAPRLCC1001AH LCD PWB Assy KP-657 1
5AAVCOVER197 Cover Rear Assy 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 4
PAGE PRINTER - Parts Catalogue
02-012
02-011
02-008 02-019
02-048 02-053 02-017
02-013
02-003
02-027
02-020
02-026
02-015
02-009
02-021 02-014 02-027
02-016 02-018
02-010
02-026
02-052
02-038
02-006
02-005
02-051
02-035 02-002
02-037
02-028
KYOCERA FS-800
02-040
Fig.2 - Frame
02-004
02-029
02-036
02-049
02-041
02-042
02-046
02-001
02-039
02-040 02-053
02-044 02-043
02-047
02-025
02-045
02-022 02-023
02-024
Page 5
Ref No. Part Code Description Quantity
02-001 5MVB887CB001 Frame Base 1
02-002 5MMX421LD014 Contact Bias 1
02-003 5MMX431LD008 Contact Main 1
02-004 5MMX433LD006 Contact Earth Regist 1
02-005 5MMX522LD011 Contact Transfer 1
02-006 5MML543SL002 Plate Connector DLP 1
02-007 5MVS531KN001 Sheet B Insulator 1
02-008 5MVQ622SB001 Rod Interlock 1
02-009 5MMW261LD024 Spring Interlock A 1
02-010 5MMW261LD029 Spring Interlock B 1
02-011 5MMT876SN063 Roller Transfer 1
02-012 5MVG127DB035 Gear TC Z18 1
02-013 5MVX221DB010 Bush Transfer R 1
02-014 5MVX221DW004 Bush Transfer L 1
02-015 5MMW211LD004 Spring Transfer L 1
02-016 5MMW251SX002 Spring Transfer R 1
02-017 5MMC862SD004 Plate Earth Guide 1
02-018 5MMW261LD025 Spring Earth 1
02-019 5MVS825XF005 Brush Discharger 1
02-020 5MVS722KN001 Sheet Regist 1
02-021 5MVS722KN003 Sheet Regist B 1
02-022 5MMT766SN006 Shaft Feed 1
02-023 5AAVCLTCH011 Clutch Feed 1
02-024 5AAVROLL*029 Roller Feed Assy 1
02-025 5MVM122DB003 Bush Pom 1
02-026 5MMT874LD002 Roller Exit 1
02-027 5MVM176DW001 Bush Exit 1
02-028 5MVG137DB003 Gear Exit Z22 1
02-029 5MVG148DN035 Gear Z38 1
02-030 5MVX651SB006 Cover Cord 1
02-031 5AACCNQH0GEA Conn. Cord Assy HV to LSU 1
02-032 5AACCNQH5GEA Conn. Cord Assy LSU Gnd 1
02-033 5AACCNQP2GEA Conn. Cord Assy Panel 1
02-034 5AACCNQP4GEA Conn. Cord Assy 1
02-035 5AACCNQG3GEA Conn. Cord Assy Developer 1
02-036 5MMT876SB055 Roller Regist Low 1
02-037 5MMT865SN009 Roller Regist Up 1
02-038 5MVX221DB019 Bush Regist Left 1
02-039 5MVX221DW006 Bush Regist Right 1
02-040 5MMW261LD023 Spring Regist R 1
02-041 5MVG126DN013 Gear Regist Z16 1
02-042 5MVG148DN036 Gear Regist Z35 1
02-043 5AAVCLTCH012 Clutch Regist 1
02-044 5MVX766DB001 Holder Feed 1
02-045 5MVT763SB001 Pulley Feed 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 6
Ref No. Part Code Description Quantity
02-046 5MVX642SB010 Actuator Feed 1
02-047 5MVX442SB009 Actuator Empty 1
02-048 5AAXTR038VDA Trans Assy 1
02-049 5EZNF2401901*01 Fan Motor 1
02-051 5MVS329RN003 Seal Frame 1
02-052 5MVQ432RB003 Cord Press 1
02-053 5MVS825KN001 Sheet Discharger 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 7
03-008
03-007
03-014
03-003
PAGE PRINTER - Parts Catalogue
03-006
03-016
03-005
03-004
03-002
03-013
03-009
KYOCERA FS-800
Fig.3 - Drive Assy
03-012
03-011
03-017
03-010
03-001
Page 8
03-015
Ref No. Part Code Description Quantity
03-000 5AAY800E*09 Drive Assy 1
03-000 5AAYFS600E32 DRIVE GEAR PACK 1
03-001 5MMX776SD004 Plate Drive 1
03-002 5MVG168DN012 Gear Z64H-Z19H 1
03-003 5MVG159DN009 Gear Z49H-Z22H 1
03-004 5MVG158DN025 Gear Z42H-Z25H 1
03-005 5MVG148DN034 Gear Z31H 1
03-006 5MVG158DN026 Gear Z42H 1
03-007 5MVG148DN032 Gear Free Z32H 1
03-008 5MVG148DN033 Gear Free Z32S 1
03-009 5MVG168DN013 Gear Z66H-Z27H 1
03-010 5MVG158DN027 Gear Z45H-Z24H 1
03-011 5MVG148DN030 Gear Z39H 1
03-012 5MVG148DN031 Gear Z37H-Z36H 1
03-013 5MMX331LD002 Plate Earth Drum 1
03-014 5MMW211SZ001 Spring Free 1
03-015 5EZSA2402410201 Free Solenoid Assy 1
03-016 5EZSA2402410101 Regist Soleniod Assy 1
03-017 5AAXMT033GEA Main Motor 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 9
PAGE PRINTER - Parts Catalogue
04-001
04-002
04-015
04-014
04-013
04-010
KYOCERA FS-800
Fig.4 - Controller
04-003
04-005
04-006
Page 10
04-008 04-004
04-016
04-007
04-009
04-009
Ref No. Part Code Description Quantity
04-000 5AAPRMEG4019AH DIMM PWB Assy KP-610A 1
04-001 5AAEZFS800E1 Switching Regulator 230v 1
04-001 5AAEZFS800A1 Switching Regulator 120v 1
04-002 5AAPRCZC2004AH Engine PWB Assy KP-651 1
04-003 5AAPRLGC2018AH Main PWB Assy KP-650 1
04-004 5AAPRIFC2010AH Relay PWB Assy KP-653 1
04-005 5MVB845SB002 Guide Cassette Left 1
04-006 5MVB864SB012 Guide Cassette Right 1
04-007 5MML643SL004 Plate Connector PF 1
04-008 5AACCNQG3GEA Conn Cord Assy
04-009 5MVS228RB019 Foot 1
04-010 5AAVBOX**005 Box Controller Assy 1
04-013 5MMU841SD002 Panel Rear 1
04-014 5MMS636SD009 Plate Option 1
04-015 5MVS774CN001 Sheet PWB 1
04-016 5MVS522KN001 Sheet Connector 1
04-017 5MVQ611RX012 EMI Gasket 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 11
06-030
PAGE PRINTER - Parts Catalogue
06-021
06-029
06-030
06-024
06-027
06-022
06-020
06-028 06-019
06-016
06-014
06-026
06-002
KYOCERA FS-800
06-001
Fig.6 - Fuser
06-009
06-012 06-025
06-015
06-010
06-017
06-028
06-023
06-006
06-005
06-031
06-018
06-008
06-012
06-010
Page 12
06-003
06-007
06-004
06-011
Ref No. Part Code Description Quantity
06-000 FK-18 Fuser Unit (5PLPPZ3CAEKE) 1
06-001 5MVT876CX001 Roller Exit 1
06-002 5MVM176DN016 Bush A 1
06-003 5MVX833KB001 Paper Chute Fuser 1
06-004 5MVG127DN047 Gear Idle Z18 1
06-005 5MVM162DN005 Bush FD R 1
06-006 5MVX875KB001 Frame Fuser Low 1
06-007 5MMW261LD017 Spring Actuator 1
06-008 5MVX721CB002 Actuator Fuser 1
06-009 5MMT876SN040 Roller Press 1
06-010 5MMW261LD022 Spring Fuser 1
06-011 5MMX323LD001 Plate Earth Fuser 1
06-012 5MVX221XN002 Bush Press 1
06-013 5MVB864KB003 Frame Fuser Up 1
06-014 5AAXTM010GEA Thermistor Assy 1
06-015 5EYFFQ14001**01 Thermo Cut Out 1
06-016 5MMT877AX003 Roller Heat 1
06-017 5MVG138XN008 Gear Fuser Z30 1
06-018 5EZPB2411920101 Lamp Heater 230v 1
06-018 5EZPB1213820101 Lamp Heater 120v 1
06-018 5EZPB1014520101 Lamp Heater 100v 1
06-019 5MMW261LD015 Spring Separator 1
06-020 5MVX222XN001 Separator 1
06-021 5MMW603LD001 Spring Exit 1
06-022 5MMX222LD016 Holder Lamp L 1
06-023 5MMX531RD002 Holder Lamp R 1
06-024 5MVM188XN013 Bush Heat L 1
06-025 5MVM288XN001 Bush Heat R 1
06-026 5MVG138DN037 Gear Fuser 1
06-027 5MVM273DB003 Roller Pinch 1
06-028 5AACCNQH1GEA Conn Cord S02211 (240v) 1
06-028 5AACCNQH2GEA Conn Cord S02212 (120v) 1
06-029 5MVX322KB002 Support Lamp 1
06-030 5MMK116SZ001 Nut Fuser 1
06-031 5MVS821KF021 Sheet Exit 1
06-032 5MVVL731WN14 Label Fuser Caution 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 13
PAGE PRINTER - Parts Catalogue
08-B01
08-021
08-022
08-003
08-023
08-001
08-027 08-010
08-028 08-018
Fig.8 - Processor Unit
08-024
KYOCERA FS-800
08-014
08-002 08-006
08-A01
08-008
08-016
08-007
08-005
08-011 08-022
08-017 08-028
08-019
08-002 08-027
08-015
08-009
Page 14
08-004
08-005
08-020
Ref No. Part Code Description Quantity
08-000 PU-18 Processor Unit 1
08-001 Shaft Drum
08-002 Spacer Blade
08-003 Plate Bias Main
08-004 Roller Main
08-005 Spring MC
08-006 Frame Drum
08-007 Gear Idle Z24H-Z30H
08-008 Gear Screw Z17H
08-009 Gear Sweep Z15H
08-010 Bush Sweep Left
08-011 Bush Sweep Right
08-013 Sheet Drum
08-014 Seal Drum Left
08-015 Seal Drum Right
08-016 Seal Blade Long
08-017 Sheet Sweep
08-018 Roller Sweep
08-019 Bush Main Left
08-020 Bush Main Right
08-021 Spring Case Belt
08-022 Bush A
08-023 Cover Drum
08-024 Spring Cover Drum
08-027 Seal Blade Upper
08-028 Seal Blade Lower
08-029 Seal Cover Drum
08-A01 Blade Assy
08-B01 Case Belt Assy
08-B02 Case Feed Toner
08-B03 Roller Belt
08-B04 Belt Feed Toner
08-B05 Shutter Case Belt
08-B06 Spring Shutter
08-B07 Seal Case Belt
08-B08 Screw Cleaner
08-B09 Spring Stopper
08-B10 Stopper Case Belt
08-C01 Drum Assy
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 15
09-012
09-008
09-006
09-001
09-003
09-009
09-010
09-002
09-005
09-007
09-004
Fig.9 - Scanner Unit
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 16
Ref No. Part Code Description Quantity
09-001 LK-18 Scanner Unit 1
09-002 Mirror Exit
09-003 Glass Exit
09-004 Shutter Scan
09-005 spring Shutter
09-006 Frame Middle
09-007 Cover Scan
09-008 Label Caution
09-009 Lever Interlock
09-010 Spring Mirror E
09-011 Bind T.T. Screw (+)
09-012 Earth AC
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 17
10-020
10-048
PAGE PRINTER - Parts Catalogue
10-040
10-035
10-028
10-034
10-026 10-038
10-043
10-025
10-036
10-030
Fig.10 - Developer Unit
10-037
KYOCERA FS-800
10-041 10-042
10-045
10-046
10-044
10-029
10-027
10-031
10-033
Page 18
10-032
10-052
Ref No. Part Code Description Quantity
10-000 PU-18 Processor Unit 1
10-020 Seal Shutter Guide
10-025 Spring Lid DLP
10-026 Cap DLP
10-027 Pin Mixer
10-028 Seal Cover Mag
10-029 Bush Mixer
10-030 Bush Mag L
10-031 Bush Mag R
10-032 Guide Paper DLP
10-033 Toner Sensor
10-034 Blade DLP
10-035 Seal Blade
10-036 Seal Blade Side
10-037 Bracket Motor
10-038 DC Motor
10-039 Conn. Cord S02208
10-040 Lid DLP
10-041 Lever DLP
10-042 Spring Lever
10-043 Flange Tube L
10-044 Flange Tube R
10-045 Tube Mixer
10-046 Shaft Mixer
10-047 Scaper Sensor
10-048 P.W. Board Assy
10-052 Cover DLP
10-A01 DLP Mech Elec Assy
10-B01 P.W. Board Assy
PAGE PRINTER - Parts Catalogue KYOCERA FS-800 Page 19
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
