Image preview - the first page of the document
>> Download Kyocera FS-850 Parts Manual documenatation <<
Text preview - extract from the document
LASERBEAM PRINTER
FS-850
PARTS CATALOGUE
09-11-1998
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 1
FS-850 Parts Catalogue
Table of Contents
Covers (Fig.1) 3
Upper Unit (Fig.2) 5
Lower Unit (Fig.3) 7
Controller Unit (Fig.4) 10
Drive Unit (Fig.5) 12
Fuser Unit (Fig.6) 14
Connection Cords (Fig.7) 16
Lower Paper Feeder (Option) (Fig.8) 18
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
Consumables and Maintanence Kits
TK-6 Toner Kit
DK-5 Drum (12K pages)
DV-10 Developer (20K pages)
FK-9 Fuser (100K pages)
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 2
01-021
01-003
01-007
01-006
01-001
01-008
01-007
01-009
01-002
Fig.1 - Covers
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 3
Ref No. Part Code Description Quantity
01-001 5AAYF820**58 COVER TOP SUB 1
01-002 5MVB753SH002 COVER SIDE 1
01-003 5AAVCLEAN028 CLEANING STICK 1
01-005 5AAFZFS850*1 KEYBOARD ASSY FS-850 1
01-005 5AAFZFS850A1 KEYBOARD ASSY FS-850A 1
01-006 5MVM374DB001 FD PULLEY 2
01-007 5MML443LD001 ROLLER SUPPORT SP 2
01-008 5MVS827AQ001 ELEC OUT BRUSH 1
01-009 5MML833RJ001 ELEC PLATE 2 1
01-021 5MMW904LJ002 PAPER STOPPER 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 4
02-00F
LASERBEAM PRINTER - Parts Catalogue
02-025
02-035
02-00A 02-00E
02-033
02-034
02-036
02-025
02-014
02-014
02-013
02-042
KYOCERA FS-850
Fig.2 - Upper Unit
02-045
02-022
02-036
02-032
02-019
02-018
02-020
02-020
02-014
02-016
02-015
02-043
Page 5
02-044
02-00D
02-041
02-017
Ref No. Part Code Description Quantity
02-00A 5AAYFS850*23 SCANNER UNIT 240V 1
02-00A 5AAYFS850A08 SCANNER UNIT 120V 1
02-00B 5AAYFS850*11 DEVE DRIVE ASSY 1
02-00D 5AAYFS850*22 ERASER ASSY 1
02-00E 5AYF820**18 PAPER SENSOR ASSY 1
02-00F 5AAYF820**19 BKT SWITCH ASSY 1
02-013 5MMZ321SL003 EJECT STOPPER 1
02-014 5MVX833SG001-01 DEVE GUIDE A 1
02-015 5MMX522LD003 GUIDE SPRING 1
02-016 5MMX831SL001 DEVE GUIDE B 1
02-017 5MVL821SB002 DRUM RAIL 1
02-018 5MMW361LJ019 DRUM SPRING F 1
02-019 5MMW361LJ020 DRUM SPRING R 1
02-020 5MVF166SB002 SPRING FOOT 2
02-022 5MVX622DG001 SAFETY LEVER 1
02-025 5MMX332SM001 CORD KEEP 2
02-032 5MML363SL002 B-S ANGLE (FU) 1
02-033 5MMS531SL003 B-S ANGLE (RU) 1
02-034 5MML532SL002 SCN ANGLE (F) 1
02-035 5MML532SL003 SCN ANGLE (R) 1
02-036 5MMT476LD003 SCN SHAFT 2
02-041 5MVX664SD001 LEVER EJECT F 1
02-042 5MVX321SJ001 EJECT LEVER R 1
02-043 5MMT865SD001 EJECT STAY 1
02-044 5MMW262LJ004 EJECT SPRING 1
02-045 5MMW267LJ001 EJECT SPRING 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 6
03-026 03-00M
03-004
03-020
03-027
LASERBEAM PRINTER - Parts Catalogue
03-043
03-042
03-00J
03-003
03-006
03-00C
03-025
03-008
03-066
03-018
03-005
03-042 03-00H
03-019
03-068
03-065 03-00A
03-012
03-011
03-061
03-063
03-094
03-062
03-064 03-067
03-038
03-00B 03-040
KYOCERA FS-850
Fig.3 - Lower Unit
03-00E
03-007
03-090
03-055
03-023
03-065
03-056
03-053
03-017 03-021
03-013
03-037 03-039
03-009
03-002
03-006
03-00G
03-054 03-005
03-032
03-052
03-072
03-024
03-071 03-045
03-072 03-034
03-00D 03-073
Page 7
03-000
03-00L 03-00F
03-016 03-001
Ref No. Part Code Description Quantity
03-00A 5AAYF800**93 FEED ASSY (SHAFT+TYRE) 1
03-00B 5AAYF800**94 REGIST ASSY 1
03-00C 5AAYF800**D6 PAPER CHUTE T ASSY 1
03-00D 5AAYF820**56 PAPER CHUTE B ASSY 1
03-00E 5AAYF820**41 FAN ASSY 1
03-00F 5AAYFS850*25 COUNTER GEAR ASSY 1
03-00G 5AAYF800**37 B-S BKT ASSY (F) 1
03-00H 5AAYF800**38 B-S BKTASSY (R) 1
03-00J 5AAPRCZG2010AH Engine PWB ASSY 1
03-00L 5AAYF820**63 SVC TC ASSY 1
03-00M 5AAPRZG2005AH Connect PWB ASSY 1
03-001 5AAVBASE*010 BASE ASSY 1
03-002 5MMX552RD002 PLATE CLUTCH EARTH 1
03-003 5MVX864SH003-01 GUIDE ENTRANCE 1
03-004 5MVX744SB001 ACTUATOR FEED 1
03-005 5MVS613KJ001 GUIDE FILM A 2
03-006 5MVS713KJ001 GUIDE FILM B 2
03-007 5MMW167W005 SPRING REGIST F 1
03-008 5MMW167LJ006 SPRING REGIST R 1
03-009 5AAYF820**65 REGIST. ROLLER B SUB* 1
03-011 5AAVSEPRT006 SEPARATOR ASSY 1
03-012 5MMW365W001 PAPER SEPARATOR SP 2
03-013 5MM1222RD002 EARTH CONTACT 1
03-016 5AAYF820**62 TC ASS'Y 1
03-017 5AAVPLATE020 DISCHARGER ASSY 1
03-018 5MVX773XH001 TC RECEPTACLE 1
03-019 5MVX853XH001 MCH CONNECT 1
03-020 5AAYL580**34 TRANS ASSY 1
03-021 5MMS663RD001 FRONT EARTH PLATE 1
03-023 5MML665RD001 PLATE DRUM EARTH 1
03-024 5MML422RN001 DRIVE EARTH 1
03-025 5MVB877SB001 INNER COVER 1
03-026 5MVN331SX001 DENS CONT KNOB 1
03-027 5MVX662SB013 OZONE FILTER 1
03-029 5MML632RD001 B-S EARTH 1 1
03-032 5MVS321KJ004 P SIDE SEAL R 1
03-034 5MVS617RJ001 P SPONGE L 2
03-037 5MVB874SH007 BASE SEPARATOR 1
03-038 5MVB861SH001 BOTTOM PAN 1
03-039 5MMM122SD001 SPACER BC 1
03-040 5MMZ253RD001 EARTH KEY 1
03-042 5MVX422DX001 FEED BEARING 2
03-043 5AAYF800**E0 FEED CLUTCH ASSY (W/FILM) 1
03-044 5MVQ553RB001 SPONGE FRONT 1
03-045 5MVS321KJ004 P SIDE SEAL 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 8
Ref No. Part Code Description Quantity
03-052 5MVG137DBOO9 COUNT GEAR Z28 1
03-053 5MVX421DX002 REGIST. BEARING R 1
03-054 5MVX421DX001 REGIST. BEARING F 1
03-055 5AAYF800**D9 REGIST. CLUTCH ASSY (W/FILM) 1
03-056 5MVG127DB014 REGIST. GEAR 1
03-061 5MMT876SN023 REGIST. ROLLER 1
03-062 5MVX511DB001 REGIST. ARM F 1
03-063 5MVX511DB002 REGIST. ARM R 1
03-064 5MML831LD002 PAPER CHUTE T 1
03-065 5MVX211DX001 REGIST. BEARING 2
03-066 5MVG127DB013 REGIST. GEAR T 1
03-067 5MMW176LJ004 ARM SPRING F 1
03-068 5MMW176W005 ARM SPRING R 1
03-071 5MMT863LD001 PAPER ROLLER 1
03-072 5MMF154CJ001 ROLLER BUSHING 2
03-073 5MMC183LD001 REGIST. P. CHUTE B 1
03-090 5MVS632KJ001 BASE SEPA. FILM A 2
03-091 5MVS732KJ001 BASE SEPA. FILM B 2
03-094 5MML264RD001 B-S EARTH J 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 9
04-002
LASERBEAM PRINTER - Parts Catalogue
03-046
04-051
03-00I
04-050 04-029
04-041
04-048
04-00A
Fig.4 - Controller Unit
04-003
KYOCERA FS-850
04-047 04-003
04-010
04-009
04-004
04-021 04-005
04-030
04-001
Page 10
04-006
04-049
04-004
04-028
04-011
Ref No. Part Code Description Quantity
03-00I 5AAPRZZG2007AH Keyboard Conn PWB ASSY 1
03-046 5AACCNHK7GEA CONN CORD S00467 1
04-00A 5AAYFS850*26 INLET ASSY 240V 1
04-00A 5AAYFS850A09 INLET ASSY 120V 1
04-001 5AVCHASS016 CONTROLLER BOX ASSY 1
04-002 5MMN882SL004 COVER CONT BOX 1
04-003 5MVL722SL002 GUIDE MAIN PWB 2
04-004 5MVL722SL001 GUIDE RAM PWB 2
04-005 5MVK361SH001 GUIDE J CARD 1
04-006 5MVS875VN002 INSULATOR PWB 1
04-008 5MMS646SL004 PLATE CONNECT 8
04-009 5MVS645VH001 SHEET INLET 1
04-010 5MMX431RD005 SPRING PWB 1
04-011 5MVS663VB003 COVER CONNECTOR 1
04-021 5AAEZF820**1 SWITCHING REGULATOR 240V 1
04-021 5AAEZF820A*1 SWITCHING REGULATOR 120V 1
04-026 5ESC020106***02 SEE-SAW SW UL VDE S 1
04-027 5AACCNHE7GEA CONN CORD S00455 1
04-028 5AACCNHK8GEA CONN CORD ASSY 1
04-029 5AACCNHE6GEA CONN CORD ASSY 1
04-030 5AACCNHD6GEA CONN CORD ASSY 1
04-041 5AAPRLGG4011AH PWB ASSY KP-166 240V 1
04-041 5AAPRLGG4011BH PWB ASSY KP-166 120V 1
04-047 5AAPRZC1027AH INLET PWB ASSY 240V 1
04-047 5AAPRZC1028BH INLET PWB ASSY 120V 1
04-048 5AAPRIFG2007AH Interface PWB ASSY 1
04-049 5AAPRMEG4015BH PWB ASSY OPT RAM 1
04-050 5MML851SL001 PANEL REAR 1
04-051 5MMS646SL004 PANEL REAR 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 11
05-003
05-00B
Fig.5 - Drive Unit
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 12
Ref No. Part Code Description Quantity
05-00A 5AAYF820**64 DRIVE GEAR SUB 1
05-00B 5AAYF820**66 MAIN MOTOR SUB 1
05-003 5MMG038SV001 MOTOR GEAR Z30 H24 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 13
06-020
06-052 06-055
06-051
LASERBEAM PRINTER - Parts Catalogue
06-022
06-048
06-019
06-056 06-049
06-051
06-062
06-018 06-016 06-022 06-061 06-054
06-017 06-020
06-046
06-057 06-047
06-013
06-032
06-020
KYOCERA FS-850
Fig.6 - Fuser Unit
06-012
06-021
06-011
06-031
06-020
06-014
06-045
06-043
06-044
03-035
03-031
03-010
Page 14
03-009
03-022
Ref No. Part Code Description Quantity
03-000 5AAYF820**01 FACE DOWN ASSY 1
03-009 5AAYF820**24 SOLENOID ASSY 1
03-010 5AAYF820**23 GATE EXIT ASSY 1
03-022 5MMZ153RD001 EARTH U-D 1
03-031 5MVQ211RB019 RUBBER CORD 2
03-035 5AAXSW027GEA SWITCH JAM 1
06-011 5AAYF820**60 FUSER COVER SUB 1
06-012 5MVX332XN002 SEPARATOR 4
06-013 5MMW163W003 SEPARATOR SPRING 4
06-014 5MMP232LD001 CLEANER SPRING 2
06-016 5MVG307DB001 EXIT ROLL PULLEY 1
06-017 5MVG038DB001 EXIT ROLL GEAR Z23 1
06-018 5MVS668RB003 EXIT BELT 1
06-019 5MVT877CB001 EXIT ROLLER 1
06-020 5MVM176DB003 EXIT ROLL BUSHING 4
06-021 5AAVROLER018 ROLLER EXIT ASSY 1
06-022 5MVM272RB002 EXIT TYRE B 2
06-031 5MVB665XB001 COVER FUSER F 1
06-032 5MVB666XB001 FUSER COVER R 1
06-043 5MVX843XB001 GUIDE EXIT PAPER 1
06-044 5AAYF820**52 PULLEY EXIT ASSY 2
06-045 5MMM332LD001 BKT EXIT PULLEY 2
06-046 5MVX842CB002 INLET UPPER GUIDE 1
06-047 5MMS623RD001 CORD PLATE F 1
06-048 5MMS713RD001 CORD PLATE R 1
06-049 5MVX622XB001 THERMISTOR SUPPORT 1
06-051 5MBSP%4007NZ STUD SCREW(+) 7
06-052 5MMP333LD001 HEATER SUPPORT 1
06-054 5MVX221XB001 CORD STOPPER 1
06-055 5AACCNFROGEA CON N CORD ASSY 1
06-056 5AAXTM001GEA THERMISTOR ASSY 1
06-057 5EYFFQ21001**01 THERMOSTAT 210 C 1
06-058 5EZPB2412520101 HEATER LAMP 240V 1
06-058 5EZPB1215020101 HEATER LAMP 120V 1
06-061 5AAPRHCC1004AH Fuser PWB ASSY 1
06-062 5AAPRZC1020AH Connect PWB ASSY 1
06-063 5AAVCLEAN036 CLEANING PAD
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 15
02-00F
03-048
03-045
03-047
03-046
04-029
Fig.7 - Connection Cords
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 16
Ref No. Part Code Description Quantity
03-045 5AACCNHZ8GEA CONN CORD S00482 1
03-047 5AACCNHF5GEA CONN CORD S00459 1
03-048 5AACCNHF6GEA CONN CORD S00460 1
04-027 5AACCNHE7GEA CONN CORD ASSY 1
04-029 5AACCNHE6GEA CONN CORD ASSY 1
08-018 5AACCNHK9GEA CONN CORD ASSY 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 17
08-003
LASERBEAM PRINTER - Parts Catalogue
08-013
08-026 08-006
08-022
08-028
08-029
Fig.8 - Lower Paper Feeder (Option)
08-024
08-012
KYOCERA FS-850
08-034
08-032
08-011
08-004
08-031
08-027
08-009
08-001
08-014
Page 18
08-018
Ref No. Part Code Description Quantity
08-001 5AAYF820**54 LOWER FEEDER (PF-3) 1
08-003 5MVS838SH001 COVER REAR 1
08-004 5MVX764DD001 COVER EMPTY 1
08-006 5AAVCASET164 PAPER CASSETTE A4 1
08-006 5MVCASET165 PAPER CASSETTE LETTER/LEGAL 1
08-008 5MVQ211RB019 RUBBER CORD 2
08-009 5AAVCOVER167 COVER GUIDE ASSY 1
08-011 5AAYF820**30 LEVER EMPTY ASSY 1
08-012 5AAYF8Z0**32 PLATE GEAR B ASSY 1
08-013 5AAYF820**31 LOWER FEED ASSY 1
08-014 5AAYF820**34 COVER FEEDER ASSY 1
08-018 5AACCNHK9GEA CONN. CORD ASSY 1
08-022 5AAPRZC1024AH PWB ASSY KP-189 1
08-024 5AAPRSWC1002AH PWB ASSY KP-140 1
08-026 5AAPRZZC1025AH PWB ASSY KP-198 1
08-027 5MML163LD001 ROLLER EARTH F 1
08-028 5MML683SD001 STAY RIGHT 1
08-029 5MVBRCKT051 STAY LEFT ASSY 1
08-031 5MMU771LD001 CASSETTE EARTH B 1
08-032 5MMZ663LD001 FEEDER EARTH R 1
08-034 5MMX321SM001 CORD KEEP 1
LASERBEAM PRINTER - Parts Catalogue KYOCERA FS-850 Page 19
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
