Image preview - the first page of the document
>> Download Kyocera FS-1000 Plus Parts Manual documenatation <<
Text preview - extract from the document
FS-1000+
Ecosys Printer [12 ppm]
Parts Catalog
REV. 1.42, Feb. 6, 2001
Contents
Diagrams
ENCLOSURES > page 3
FRAME > page 4
DEVELOPER > page 5
DRIVE-UNIT > page 6
UPPER-FRAME > page 7
FUSER UNIT > page 8
PAPER CASSETTE > page 9
OPTION FEEDER, PAPER CASSETTE > page 10
OPTION FEEDER > page 11
Parts Catalog > pages 12 to 17
A latest version of this catalog is readily available at the Kyocera ftp site. Please contact Kyocera Mita in this
regard.
For additional information and downloads, please visit http://www.kyocera.com/w2k.
ENCLOSURES
G101
0003
0001
0022
0002
0007
0010 0011
G002
0012
G002 0004
0A01 0008
0016
0017
0006
G001 0005
0024
0013
0014
0021
0015 0023
FS-1000+ PARTS CATALOG -- 3
FRAME
1A01 1017 1023
1020 1073
G101
1052 1061 G111 1071 1070
G203 1063 1060 1072 1008
G202 1059
1077
2017 1078
G101 G105
2019
1046 G111
1079
1062 1080 1050
1018 1025
G101
G201 1065 1048
G105
2018 1064 1031
G101 1053 1063 G106
1007
1001
5034 1038
2016 2014
G102
1024
1006 1019
1067 G101 2015
1003 1049
1066
1037
1111 1036
1039 2013
1012 1035
1111 1068 1042 1034 PWBA/D
1069
1009 1032 1033
1014 1043
1011 1044 G101
1010
1075 2002
2003 1041 2010
1011 1013
1015
1002
2011
2012
G101 1005
G103 1040 2008
FS-1000+ PARTS CATALOG -- 4
DEVELOPER
5009
5A03
5019 G501 5039
5031
G501 5025
5030
5038 5040 5026
G602 5037
5013
6010 5036 5010
5018
5032
5044 5003
5016 5033 5004 5011
6011 5035 5014
6004 5002 5A01
5007
6015 5046
6039 6013 5024
6040 G501 5029
6036 5008
6038 6019 6007
6028
G602 6033 6037 6009 5027
G602 6008 5008
6002 G601
6043 5007 5021
6012 5005 5028
5022
6029 6035 5023
6005 5020
6037 5001
6016
G602 6007 6020 5003
5004
6030
6034
6001 6023
6014
6044 6043 6027
6017 6024
6025 6032
5030
6021
6042 6018 5017
6022 5044 5A02
6026
6045 6003 G501 6031
6042 5015
G501
G602
FS-1000+ PARTS CATALOG -- 5
DRIVE-UNIT
3005 G303 3004
G303
3009 3008
3003
G303
3006 G101
3007
G101 G103
3011
3010
G301 3013
G101
G301
3014
G101 3001
3002 G301
G301
2009
3012
G302
FS-1000+ PARTS CATALOG -- 6
UPPER-FRAME
G101 4002 G401
G101
1047 1081
G401
G102 4007
1054 4012
4014/4015
1029
1055 4005 1085
4013
1030 4003 G107
4009 1086
1088 G101
4001
1026
4006 1082
1090
1087 4017
1093 1094 1090
1091 1093 4016 4010
G109
1099 G402
1A02 1090
1098 1089
1095
1101 1090
1108 1092
1102
1106 1107
1112
G110
1110
1104 1109
1101 1074
1076
1096
1051
G101
1051
FS-1000+ PARTS CATALOG -- 7
FUSER UNIT
7018
7019
7016
G701
G706
G705
7029
7013
G702
7017 G701
7012
7027
G704
7015
7005 7021
7006 7030 7028
7023
7004 7008
G705
7005 G706 7026
7006 7025 7024
7009 7032
7031
7001 G705
7007
7010
7011
FS-1000+ PARTS CATALOG -- 8
PAPER CASSETTE
8014
8013
8003
8A02 8012
8A01
8002
8015
8005
8007 8011
8009
G801
8010
8004
8017
8018
8008
8006
8001
8016
8018
FS-1000+ PARTS CATALOG -- 9
OPTION FEEDER, PAPER CASSETTE
8014
8013
8003
8A02 8012
8A01
8002
8019
8015
8007 8005 G802
8009
8011
G801
8010
8004
8017 8020
8018
8008
8006
8001
8018
8016
FS-1000+ PARTS CATALOG -- 10
OPTION FEEDER
G002
0025 G002
G001 0004
0022
0003
0005
G001
0021
0014
0020 0009 G002
0011
G008
0008 0024
G008 0015
0006 0016
0013
G007 G009
0017 G002
0010
0007
0001
0002
FS-1000+ PARTS CATALOG -- 11
Parts Catalog: Ecosys Printer FS-1000+
Ref. Part Code Description ISP Used KMC KMA KMDE KMUK KMFR KMIT KMAUS KMSG KMHG TWN PHN CHP
5PLPXU2AEKX PU-40 PROCESS UNIT 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
5PLPXCDAKCN PU-41K PROCESS UNIT 1 1 No No No No No No No No No No No Yes
5PLPXU3AEKX FK-40 FUSER UNIT (E) 240V 1 1 No No No No No No No No No No No No
5PLPXU4AEKX FK-40 FUSER UNIT (U) 120V 1 1 No No No No No No No No No No No No
5PLPXCSAJKJ FK-40 FUSER UNIT (J) 100V 1 1 No No No No No No No No No No No No
5PLPXCWAPKX FK-41 FUSER UNIT (E) 240V 1 1 No No Yes Yes Yes Yes Yes Yes Yes Yes No Yes
5PLPXCXAAKM FK-41 FUSER UNIT (U) 120V 1 1 No Yes No No No No No No No No No No
5PLPXGCA0LE FK-41 FUSER UNIT (TWN) 110V 1 1 No No No No No No No No No No Yes No
5PLPXCYAJKJ FK-41 FUSER UNIT (J) 100V 1 1 Yes No No No No No No No No No No No
5PLPXT9AEKX LK-40 SCANNER UNIT 1 1 No No No No No No No No No No No No
5PLPXDAAPKX LK-41 SCANNER UNIT 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5PLPXU0AEKX DR-40 DRIVE UNIT 1 1 No No No No No No No No No No No No
5PLPXCZAPKX DR-41 DRIVE UNIT 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5PLPXU5AEKX MC-40 MCH ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5PLPXU6AEKX PC-40 CASSETTE ASSY A4 1 1 Yes No Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5PLPXU7AEKX PC-40 CASSETTE ASSY LTR 1 1 No Yes No No No No No No No No No No
0002 5MVB876CH013 LID TOP 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0002 5MVB876CH015 LID TOP 1 1 No No No No No No No No No No No Yes
0003 5MVB886CH009 COVER LEFT 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
0004 5AAY3010E+27 COVER RIGHT ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0004 5AAYA87CH+12 COVER RIGHT ASSY 1 1 No No No No No No No No No No No Yes
0005 5MVB773CH001 COVER DIMM 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
0006 5AAY3010E+28 COVER FRONT ASSY 1 1 No No No No No No No No No No No No
0006 5AAYA88E++11 COVER FRONT ASSY 1 1 No No Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0006 5AAYA88U++08 COVER FRONT ASSY 1 1 Yes Yes No No No No No No No No No No
0006 5AAYA87CH+11 COVER FRONT ASSY 1 1 No No No No No No No No No No No Yes
0007 5MVB851SH003 COVER REAR SIDE 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
0008 5MVB885CH004 COVER RIGHT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0010 5MVB875CH001 COVER FRONT 1 No No No No No No No No No No No No
0010 5MVB875CH003 COVER FRONT 1 Yes No Yes Yes Yes Yes Yes Yes Yes Yes No No
0010 5MVB875CH004 COVER FRONT 1 Yes Yes No No No No No No No No Yes No
0010 5MVB875CH008 COVER FRONT 1 No No No No No No No No No No No Yes
0011 5MVX422DN005 HINGE FRONT L 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
0012 5MVX422DN006 HINDE FRONT R 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
0013 5MVX444SH001 BUTTON A 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0014 5MVX444SH002 BUTTON B 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
5MVX631SH008 BUTTON 1 No No No No No No No No No No No Yes
0015 5MVX322SN002 LEVER BUTTON 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0017 5MVB764SH013 HOLDER PANEL 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0022 5AAY3010E+46 COVER TOP ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0023 5AAY3010E+47 COVER DIMM ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
0024 5MMT263SN012 SCREW OP 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
FS-1000+ PARTS CATALOG -- 12
Ref. Part Code Description ISP Used KMC KMA KMDE KMUK KMFR KMIT KMAUS KMSG KMHG TWN PHN CHP
0024 5MMT263SN012 SCREW OP 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
0026 5MMX761LD002 PLATE SHIELD 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
0A01 5AAY3010E+51 GUIDE LED KIT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
1001 5MVB888CB002 FRAME BASE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1002 5MVB874CH002 COVER PWB 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5MVB874CH004 COVER PWB PANEL 1 No No No No No No No No No No No Yes
1003 5MVX721DN001 LEVER INTERLOCK 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1006 5MMW351LD006 SPRING INTERLOCK 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1007 5MML622LD003 PLATE EARTH JOINT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1008 5AAY3010E+31 EARTH GUIDE ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1009 5AAVR0LL*044 ROLLER FEED ASSY 1 1 No No No No No No No No No No No No
1009 5AAVR0LL+056 ROLLER FEED J ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1010 5MMT766SN007 SHAFT FEED 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1011 5MVM176DN026 BUSH FEED 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1012 5MVT676DB002 PULLY FEED 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1013 5MVX432DB009 ACTUATOR REGIST 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1014 5MVX542DB003 ACTUATOR PE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1015 5MMW151LD005 SPRING ACTUATOR REG 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1017 5AAY3010E+17 ROLLER REGIST ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1018 5MVS822KF013 SHEET REGIST 1 No No No No No No No No No No No No
1118 5MVS722KF008 SHEET REGIST L 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1119 5MVS622KF010 SHEET REGIST R 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1120 5MVS441KF008 SHEET REGIST SW 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1019 5MMX532LD005 CONTACT EARTH REG 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1020 5MMT876SN074 ROLLER TRANSFER 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1023 5MVG127DB048 GEAR TC Z18 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1024 5MMX432LD005 CONTACT TRANSFER 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1025 5MMX331LD003 PLATE EARTH BRUSH 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1026 5AAY3010E+39 MPF ASSY E 1 1 No No No No No No No No No No No No
1026 5AAY3010U+10 MPF ASSY U 1 1 No No No No No No No No No No No No
1026 5AAY1000J+09 MPF ASSY J 1 1 No No No No No No No No No No No No
1026 5AAYA87CH+04 MPF ASSY CHU 1 1 No No No No No No No No No No No Yes
1029 5AAY3010E+18 TE SENSOR ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1030 5MMW261LD036 SPRING TE SENSOR 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1031 5MMS775SL001 PLATE CONTROLLER 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1032 5MVG148DN045 GEAR Z38H 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1033 5MVG148DN046 GEAR FREE Z40H 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1034 5MVG138DN041 GEAR FREE Z25S 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1035 5MVG148DN047 GEAR Z34S 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1036 5MVG148DN048 GEAR Z40S 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1037 5MVG148DN049 GEAR Z37S 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1038 5MMW271LD010 SPRING FREE 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1039 5MMT364SN003 PIN DRIVE 1 3 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1040 5MVB663SB048 COVER CORD 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1041 5AAVCLTCH015 CLUTCH FEED 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
FS-1000+ PARTS CATALOG -- 13
Ref. Part Code Description ISP Used KMC KMA KMDE KMUK KMFR KMIT KMAUS KMSG KMHG TWN PHN CHP
1042 5AAVCLTCH016 CLUTCH REGIST 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1043 5AAVCLTCH017 CLUTCH MPF 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1044 5MVX111DN003 RING STOPPER 1 5 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1045 5MMX332LD013 PLATE EARTH MPF 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1046 5MVX322SB020 ACTUATOR FUSER B 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1047 5AAY3010E+35 COVER REAR ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1048 5AAY3010E+36 ROLLER EXIT UP ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1049 5MVG137DN030 GEAR EXIT Z23 UP 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1050 5MVM176DW001 BUSH EXIT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1051 5MVS228RB019 FOOT 4 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1052 5EZNF2402403+01 FAN MOTOR 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1053 5AAXTR046VDA TRANS ASSY 1 1 No No No No No No No No No No No No
1053 5AAXTR049VDA TRANS ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1059 5MMT876SN073 ROLLER REGIST LOW 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1060 5MMT865SN010 ROLLER REGIST UP 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1061 5MVX221DB019 BUSH REGIST LEFT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1062 5MVX221DW006 BUSH REGIST RIGHT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1063 5MMW261LD023 SPRING REGIST R 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1064 5MVG127DB047 GEAR REGIST Z20 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1065 5MVG126DB025 GEAR REGIST Z13 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1066 5MVT653DW001 PIN CASSETTE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1067 5MMW341LD005 SPRING PIN CASSETTE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1068 5MMT365SN003 PIN CONTACT BIAS 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1069 5MMW361LD015 SPRING PIN BIAS 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1074 5MVX866SH012 GUIDE TURN 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1075 5AAY3010E+41 SEPARATOR MPF ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1076 5MMW261LD038 SPRING SEPA MPF 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1077 5MVX221DB023 BUSH TC L 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1078 5MMW251LD043 SPRING TC L 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1079 5MVX221DW008 BUSH TC R 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1080 5MMW261LD034 SPRING TC R 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1081 5MVB874SH018 COVER REAR 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1082 5MVB874SH019 TRAY EXIT FU 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1085 5MMX332LD021 BKT PULLEY FD 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1086 5MVM273DB005 PULLEY EXIT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1087 5AAVR0LL*045 ROLLER MPF ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1088 5MVX854SH002 HOLDER MP FEED 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1089 5MMT766SN008 SHAFT MPF 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1090 5MVX111DN003 RING STOPPER 3 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1091 5MVX432DB010 ACTUATOR MPF 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1092 5MVX221DN014 CAM MPF R 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1093 5MVM176DN026 BUSH FEED 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1094 5ENXGP1A73A**01 PT SENSOR 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1095 5AACCNRM0GEA CONN.CORD ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1096 5MVB872SH018 COVER MPF E 1 No No No No No No No No No No No No
FS-1000+ PARTS CATALOG -- 14
Ref. Part Code Description ISP Used KMC KMA KMDE KMUK KMFR KMIT KMAUS KMSG KMHG TWN PHN CHP
1096 5MVB872SH020 COVER MPF U 1 No No No No No No No No No No No No
1096 5MVB872SH029 COVER MPF IBM 1 No No No No No No No No No No No No
1096 5MVB872SH030 COVER MPF 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
1096 5MVB872SH031 COVER MPF CHU 1 No No No No No No No No No No No Yes
1098 5MVX861SH004 TRAY MPF A 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1099 5MVX751SH001 TRAY MPF B 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1111 5MVM161DW001 BUSH PULLEY FEED 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1A01 5AAY3010E+45 REGIST KIT 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
1A02 5AAY3010E+40 BOTTOM MPF ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2002 5AAPRCZC2007AH P.W.BOARD ASSY ENGINE KP-781 1 1 No No No No No No No No No No No No
2002 5AAPRCZC2007BH P.W.BOARD ASSY ENGINE KP-781 1 1 No No No No No No No No No No No No
2002 5AAPRCZC2007CH P.W.BOARD ASSY ENGINE KP-781 1 1 No No Yes Yes Yes Yes Yes Yes Yes Yes Yes No
2002 5AAPRCZC2007DH P.W.BOARD ASSY ENGINE KP-781 1 1 No Yes No No No No No No No No No No
2002 5AAPRCZC2007EH P.W.BOARD ASSY ENGINE KP-781 1 1 Yes No No No No No No No No No No No
2002 5AAPRCZC2007FH P.W.BOARD ASSY ENGINE KP-781 1 1 No No No No No No No No No No No Yes
2002 5AAPRCZC2007GH P.W.BOARD ASSY ENGINE KP-781 1 1 No No No No No No No No No No No No
2003 5AAPRCZC1008AH P.W.BOARD ASSY BIAS KP-783 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2008 5AACCNRL7GEA CONN.CORD ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2009 5AACCNRM1GEA CONN.CORD ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2010 5AACCNRM2GEA CONN.CORD ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2011 5AACCNRL0GEA CONN.CORD ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2012 5AACCNRL1GEA CONN.CORD ASSY 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2013 5MMB775SL013 BOX CONTROLLER 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2015 5MMS636SD009 PLATE OPTION 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2016 5AAPRLGC2021AH P.W.BOARD ASSY MAIN KP-780 1 1 No No No No No No No No No No No No
2016 5AAPRLGC2021CH P.W.BOARD ASSY MAIN KP-780 1 1 No No No No No No No No No No No No
2016 5AAPRLGC2021DH P.W.BOARD ASSY MAIN KP-780 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
2016 5AAPRLGC2022AH P.W.BOARD ASSY MAIN KP-881 1 1 No No No No No No No No No No No Yes
2017 5MMX773SL001 PLATE SW REG 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2018 5MVS765KF001 SHEET SW REG 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
2019 5AAEZ3010E+1 or SWITCHING REGULATOR(E) 240V 1 1 No No Yes Yes Yes Yes Yes Yes Yes Yes No No
5AAEZ3010E+2
2019 5AAEZ3010E+1 SWITCHING REGULATOR(E) 240V 1 1 No No No No No No No No No No No Yes
2019 5AAEZ3010U+1 SWITCHING REGULATOR(U) 120V 1 1 Yes Yes No No No No No No No No Yes No
3001 5AAXMT047GEA MOTOR MAIN 1 1 No No No No No No No No No No No No
3001 5AAXMT056GEA MOTOR MAIN 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3002 5MMX776SL005 PLATE DRIVE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3003 5MVG168DN017 GEAR Z68H-Z21H 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3004 5MVG159DN012 GEAR Z48H-Z21H 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3005 5MVG148DN044 GEAR Z40H 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3006 5MVG169DN032 GEAR Z95H-Z21H 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3007 5MVG169DN033 GEAR Z53H 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3008 5MVG138DN042 GEAR Z24H 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3009 5MVG137DN029 GEAR Z21H 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3010 5MVG148DN050 GEAR Z36H-Z21H 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
FS-1000+ PARTS CATALOG -- 15
Ref. Part Code Description ISP Used KMC KMA KMDE KMUK KMFR KMIT KMAUS KMSG KMHG TWN PHN CHP
3011 5MMX521LD005 PLATE EARTH DRUM 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3012 5EZSA2402410301 SOLENOID FEED 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3013 5EZSA2402410401 SOLENOID REGIST 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
3014 5EZSA2402410501 SOLENOID MPF 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4001 5MVB876CB003 FRAME MIDDLE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4002 5MMX875SL005 PLATE LSU 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4003 5MVQ711GX004 MIRROR EXIT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4005 5MVX721SB004 SHUTTER LSU 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4006 5AAY3010E+26 FULL SENSOR ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4007 5MMX221LD024 SPRING MIRROR 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4009 5MMW341LD006 SPRING SHUTTER LSU 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4010 5MMW261LD040 SPRING FULL SENSOR 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4011 5MVVL661WN34 LABEL LASER CAUTION 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4013 5AAPRELR1001AH P.W.BOARD ASSY ERASE KP-790 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
4021 5MVS319RF004 SEAL LSU D 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5019 5MVX331PH001 CAP MCH 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5034 5MMX632LD006 CONTACT MAIN 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5A01 5AAY3010E+52 BLADE KIT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5A02 5AAY3010E+53 COVER DRUM R2 KIT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5A03 5AAY3010E+54 COVER DRUM L2 KIT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7001 5MVX876KB004 FRAME FUSER LOW 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7004 5MMT876SN075 ROLLER PRESS 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7005 5MVX221XN003 BUSH PRESS 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7006 5MMW261LD037 SPRING PRESS 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7007 5MVG127DN070 GEAR IDLE Z18 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7008 5MVG137DN031 GEAR EXIT Z23 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7009 5MMX665LD004 PLATE EARTH FUSER 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7010 5MVX731CB002 ACTUATOR FUSER A 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7011 5MMW261LD017 SPRING ACTUATOR 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7012 5MMT774SN001 ROLLER EXIT LOW 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7013 5MVX211DB016 BUSH EXIT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7014 5MVVL731WN14 LABEL FUSER CAUTION 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7015 5MVB863KB003 FRAME FUSER UP 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7016 5MMT876AX001 ROLLER HEAT 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7017 5MVM188XN015 BUSH HEAT R 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7018 5MVM188XN016 BUSH HEAT L 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7019 5EZPB2411920201 HEATER LAMP (E) 240V 1 1 No No No No No No No No No No No No
7019 5EZPB1213820201 HEATER LAMP (U) 120V 1 1 No No No No No No No No No No No No
7019 5EZPB1014520201 HEATER LAMP (J) 100V 1 1 No No No No No No No No No No No No
or ISP1000J+001
7019 5EZPB2412120702 HEATER LAMP (E) 240V 1 1 No No Yes Yes Yes Yes Yes Yes Yes Yes No Yes
7019 5EZPB1214220701 HEATER LAMP (U) 120V 1 1 No Yes No No No No No No No No Yes No
7019 5EZPB1015020801 HEATER LAMP (J) 100V 1 1 Yes No No No No No No No No No No No
7021 5AACCNRL4GEA CONN.CORD ASSY E 1 No No Yes Yes Yes Yes Yes Yes Yes Yes No Yes
7021 5AACCNRL5GEA CONN.CORD ASSY U 1 Yes Yes No No No No No No No No Yes No
FS-1000+ PARTS CATALOG -- 16
Ref. Part Code Description ISP Used KMC KMA KMDE KMUK KMFR KMIT KMAUS KMSG KMHG TWN PHN CHP
7021 5AACCNSE1GEA CONN.CORD ASSY J 1 No No No No No No No No No No No No
7023 5AAXTM014GEA THERMISTOR ASSY 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7024 5EYFFQ16002Q+01 THERMO CUT OUT 1 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7025 5MVX222XN002 SEPARATOR 4 No No No No No No No No No No No No
7025 5AAVSEPRT015 SEPARATOR ASSY 4 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7026 5MMW261LD015 SPRING SEPARATOR 4 No No No No No No No No No No No No
7026 5MMW261LD055 SPRING SEPARATOR 4 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5MVS222KN006 SHEET REAR 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5MVS222KW001 SHEET REAR B 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7027 5MVG148XN008 GEAR HEAT Z33 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7028 5MVG148XN009 GEAR IDLE Z34 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7029 5MML531RD001 or HOLDER LAMP A 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
5MML531RD002
7030 5MML211RD002 HOLDER LAMP B 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7031 5MVM273DB005 PULLEY EXIT 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
7032 5MMW601LD011 SPRING PULLEY 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8001 5MVB886SH063 BASE CASSETTE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8004 5MMS856SL001 PLATE BOTTOM 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8005 5MMW552LD002 SPRING CASSETTE 2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8006 5MVX765SH002 GUIDE SIDE R 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8007 5MVX765SH003 GUIDE SIDE L 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8008 5MVX664SH003 STOPPER PAPER 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8009 5MVX541DG003 LEVER SIDE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8010 5MVX541DG002 LEVER REAR 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8011 5MVG127DN071 GEAR CASSETTE 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
8015 5MMW251LD047 SPRING SEPARATOR C 1 Yes Yes Yes Yes Yes Yes Yes Yes ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
