Image preview - the first page of the document
>> Download Kyocera FS-1500 Parts Manual documenatation <<
Text preview - extract from the document
PAGE PRINTER
FS-1500
PARTS CATALOGUE
06-11-1998
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 1
FS-1500 Parts Catalogue
Table of Contents
Covers (Fig.1) 3
Frame Unit (Fig.2) 5
Drive Frame Unit (Fig.3) 7
Controller Unit (Fig.4) 9
Feed Unit (Fig.5) 11
Fuser Unit (Fig.6) 14
Face Down Unit (Fig.7) 17
Drum Unit (Fig.8) 19
LED Head Unit (Fig.9) 22
Developer Unit (Fig.10) 24
Harness (Fig.11) 27
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
Consumables and Maintanence Kits
TK-9 Toner Kit
G-1 Grid Cleaner
MK-1 Maintenance Kit (300K pages)
Drum
Developer
Fuser
Transfer Roller
Pick-up Roller
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 2
PAGE PRINTER - Parts Catalogue
01-007
02-030
01-005
01-001
KYOCERA FS-1500
Fig.1 - Covers
01-006
01-008
05-000
01-017
01-009
01-019
01-003
01-002
Page 3
03-041
01-018
Ref No. Part Code Description Quantity
01-001 5AAFZ1500E*1 Key Board Assy 1
01-002 5MVB875SH003 Cover Front FS-1500 1
01-002 5MVB875SH002 Cover Front FS-1500A 1
01-003 5MVX852SH003 Lid Cover Front 1
01-004 5MVB886SH021 Cover Right 1
01-005 5MVB886SH022 Cover Left 1
01-006 5MVX842SH002 Rod SW Power 1
01-007 5MVX642SH003 Cover PWB Ram 1
01-008 5MVM276SB002 Cap Press Cover 1
01-009 5MMW361LD005 Spring Press CVR 1
01-010 5MMWS1500E*1 Ser No Plate 1
01-011 5MVX876SH014 Tray Face Down 1
01-012 5MVX885SH003 Tray Face Up 1
01-013 5MVL664SH001 Stopper Paper FU 1
01-014 5MMS668SH001 Stopper Paper FD 1
01-015 5AAVTRAY*003 Manual Tray Assy 1
01-016 5AAVCLEAN027 Cleaner Assy 1
01-017 5AAPRZZG2010AH PW Board Assy (ENV) 1
01-018 PC-7 - A4 Cassette A4 Assy 1
01-019 5MMW361LD006 Spring Power 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 4
PAGE PRINTER - Parts Catalogue
02-008
02-024
02-033
02-023
02-006
02-005
02-004
02-025 02-003
02-017
KYOCERA FS-1500
Fig.2 - Frame Unit
02-032
02-013 02-003
02-035
02-012
02-007
02-016 02-026
02-014
02-011 02-010
02-009
02-015
02-021
02-031
02-018
Page 5
02-022
02-019
02-020
02-021
Ref No. Part Code Description Quantity
02-001 5MMT855SZ004 Shaft Frame 1
02-002 5MMU211SD007 Case Stopper 2
02-003 5MMF265SN001 Pin Hinge 2
02-004 5MMX875SL003 Frame Left 1
02-005 5MVX743CB001 Spacer Frame 1
02-006 5MMX661SL005 Plate Drum 1
02-007 5MMU411LD001 Plate Receptacle 1
02-008 5MML322SL004 Bracket Shaft 1
02-009 5MVM122DB002 Pully Case 2
02-010 5MMU311LD002 Plate Earth SPRG 1
02-011 5MVX211NN019 Lock Card Spacer 2
02-012 5ESM010234***01 Micro Switch 1
02-013 5MMX864SL008 Channel Front Up 1
02-014 5MVX843SB003 Latch Cover 1
02-015 5MMW261LD007 Spring Latch 1
02-016 5MMX626LD001 Press DLP 2
02-017 5MVX853SB001 Guide DLP 1
02-018 5MVX866SH004 Channel Front Low 1
02-019 5MMT876SN039 Roller Manual Up 1
02-020 5MVX322SB012 Actuator Manual 1
02-021 5MVM176SN009 Bearing 2
02-022 5EYYAFAAQ01**01 Clutch Feed 1
02-023 5MVX532DN001 Bkt Sensor Bottle 1
02-024 5ESM010235***01 Micro Switch 1
02-025 5AACCNHY3GEA Conn. Cord S00558 1
02-026 5AACCNHX2GEA Conn. Cord S00547 1
02-030 5AAPRPWC1001AH AC PWB (KP-238) 240V 1
02-030 5AAPRPWC1002AH AC PWB (KP-383) 120V 1
02-030A 5MVB774SH001 Cover PWB AC 1
02-030B 5MML541SL003 Bracket Inlet 1
02-030C 5MML431SL002 Bracket SW Power 1
02-031 5AAPRSSC1006CH Manual Feed PWB (KP-244) 1
02-032 5AAPRSSC1007CH Paper Sencor PWB (KP-245) 1
02-033 5AAXTR019VDA Trans. Assy 1
02-034 5AAPRSSC1009DH PWB KP-298 1
02-035 5MVX633CB001 PWB KP-298 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 6
PAGE PRINTER - Parts Catalogue
03-030
03-042
03-013
03-029
03-003 03-036
03-007 03-011
03-005
03-024 03-002
03-004
03-012
Fig.3 - Drive Frame Unit
03-006
KYOCERA FS-1500
03-021
03-038
03-008
03-028
03-004
03-009 03-037
03-022 03-035 03-010
03-033 03-014
03-039
03-032
03-016
03-040
03-034
03-023
03-031
03-027
03-043
03-019
03-018
03-015
Page 7
03-017
03-025
Ref No. Part Code Description Quantity
03-000 5AAY1500E*46 Drive Gear Assy 1
03-001 5MMX863SL003 Plate Drive A 1
03-002 5MMX873SL002 Plate Drive B 1
03-003 5MMX532SL007 Plate RE Joint 1
03-004 5MMW261LD006 Spring Joint 2
03-005 5MVG138DB021 Gear Joint Z28 2
03-006 5MVG137DB024 Gear Clutch Z22 1
03-007 5MVM190RN013 Belt Drive 1
03-008 5MVG068DB001 Gear Drv P60-H20 1
03-009 5MVG158DB009 Gear Drv Z45H-Z24H 1
03-010 5MVG169DB008 Gear Drv Z59-Z24H 1
03-011 5MVG138DB022 Gear Free Z27 1
03-012 5MMW361LD004 Spring Free 1
03-013 5MVG148DB019 Gear Drum Z34H 1
03-014 5MVG158DB010 Gear Reg. Z45H-Z45S 1
03-015 5MVG148DB009 Gear Idle Z40 1
03-016 5MVG138DB023 Gear DLP Z28 1
03-017 5MVG148DB010 Gear Feed Z34 1
03-018 5MVG148DH001 Gear Idle Z33 1
03-019 5MVG137DB025 Gear M Feed Z25 1
03-020 5MVG158DB011 Gear Idle Z45H 1
03-021 5MXX532SL008 Plate FE Joint 1
03-022 5MVG138DB024 Gear Clutch Z29 1
03-023 5MMX763SL014 Plate Drive C 1
03-024 5MVG138DB040 Gear Free Z27H 1
03-025 5MVX763CB001 Spacer Gear 1
03-026 5MVX632DB002 Holder Clutch 1
03-027 5MMX543SL002 Plate Drive D 1
03-028 5MVMl76DB008 Bushing Stop 2
03-029 5MVM122DB002 Pully Case 2
03-030 5MMT263SZ016 Pin Stud 2
03-031 5MVG158NN001 Gear CD Z31-Z42 2
03-032 5MVG158DB005 Gear CD Z1 4-Z42 3
03-033 5MVG138NN002 Gear CD Z20-Z25 1
03-034 5MVG111DB001 GP Motor Gear 1
03-035 5MMT565SN001 Shaft Clutch 2
03-036 5MVG148XN004 Gear Fuser Z34 1
03-037 5AAXMT017GEA Motor Main 1
03-038 5EYYAFAAK01**03 Clutch Regist 1
03-039 5EYYAFAAQ01**03 Clutch Feed 1
03-040 5AAY1500E*18 Toner Motor Assy 1
03-041 5AAPRIFC2002AH Interconnect PWB KP-237 1
03-042 5EZNF2403103*01 Fan Motor 1
03-043 5AAPRIFC1001AH Joint PWB KP-246 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 8
PAGE PRINTER - Parts Catalogue
04-023
04-021
04-002
04-016
04-009
04-011
Fig.4 - Controller Unit
04-006
KYOCERA FS-1500
04-007 04-022 04-013
04-015
04-011
04-003
04-017
04-019
Page 9
04-004
04-004
04-001
Ref No. Part Code Description Quantity
04-001 5MMB884SL003 Box Controller 1
04-002 5MVX742SL001 Rail PWB RAM 2
04-003 5MVX732SL001 Rail PWB Main 1
04-004 5MVM160RB025 Foot 4
04-006 5MMS846SL001 Panel Rear 1
04-007 5MVS772KF002 Sheet Power 1
04-009 5MVX311NN033 PWB Spacer 2
04-011 5MVM266SB003 Pull Knob 2
04-012 5MVB422SB003 Bracket Conn F 1
04-013 5MMS646SD007 Plate Connect 8N 1
04-015 5AACCNHW6GEA Conn Cord S00541 1
04-016 5AAEZ1500E*1 Power Supply 240V 1
04-016 5AAEZ1500A*1 Power Supply 120V 1
04-017 5MML633SD001 Lid Ram PWB 1
04-019 5AAPRLGG4012AH PWB KP-233 (MAIN LOGIC) 1
04-020 5AAPRLGG2003AH PWB KP-234 (ENGINE) 1
04-021 5AAPRIFC2003AH PWB KP-235 (INTERFACE) 1
04-022 5AAPRZZG2003AH PWB KP-268 (FUX) 1
04-023 5AAPRMEG4017AH PW Board Assy (MEM) 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 10
05-043
05-014
05-029 05-045
05-057
05-055
05-053
05-013
05-058
PAGE PRINTER - Parts Catalogue
05-054
05-037 05-009
05-044
05-036 05-003 05-056
05-001
05-027 05-045
05-028
05-023
05-032
05-004
05-025
05-012
05-038
02-002
05-040
KYOCERA FS-1500
05-046
Fig.5 - Feed Unit
02-002
05-020
05-026
05-042
05-030 05-034
05-002
05-016
05-024
05-015
05-041
05-015
05-016
05-019
Page 11
05-039
05-022
05-031 05-035
05-033
05-031
05-017 05-021
05-018
Ref No. Part Code Description Quantity
05-000 5AAY1500E*48 Feed Unit 1
05-001 5MMT876SN033 Roller Regist A 1
05-002 5MVG137DB029 Gear Reg Z24-Z32 1
05-003 5MMT821SN002 Roller Regist Up 1
05-004 5MVG137DB028 Gear Regist Z24 1
05-005 5MVM210DB001 Bush Regist 1
05-006 5MMS836SZ002 Paper Chute Low 1
05-007 5MVX322DB010 Holder Chute L 1
05-008 5MVX322DB011 Holder Chute R 1
05-009 5MMS836LD001 Paper Chute Up 1
05-010 5MMW172SX004 Spring Regist L 1
05-011 5MMW172SX003 Spring Regist R 1
05-012 5MMU443LDC01 Plate Earth CTCT 1
05-013 5MVX852SH002 Guide Paper A 1
05-014 5MVX722SH002 Sensor Doc 1
05-015 5MVG138DB029 Gear Idle Z26 2
05-016 5MVM121DBC01 Collar Joint 2
05-017 5MVG138DB028 Gear Feed 1
05-018 5MVX655SX001 Lever Lock 1
05-019 5MVX711DB001 Link Lock 1
05-020 5MVX886SH001 Lower Case 1
05-021 5MMS546SD001 Plate Lock 1
05-022 5MMW177LDO01 Spring Lock 1
05-023 5MVX421DB007 Hinge Lock L 1
05-024 5MVX431DB003 Hinge Lock R 1
05-025 5MMW166LD004 Spring Hinge L 1
05-026 5MMW166LD005 Spring Hinge R 1
05-027 5MVS722KF002 Sheet Regist L 1
05-028 5MVS622KF003 Sheet Regist R 1
05-029 5MVS822KF003 Sheet Regist A 1
05-030 5MVX843SH0C6 Cover Front B 1
05-031 5MVM687DB001 Roller Guide 4
05-032 5MMT860SZ001 Shaft Release l
05-033 5MVM122DB003 Bush Pom 2
05-034 5MVM410DB001 Holder Roller ED 1
05-035 5MMT660SN001 Shaft Feed 1
05-036 5MMW733SN002 Shaft Manual 1
05-037 5MVM460DB001 Roller Idle 4
05-038 5MMW255LD003 Spring Manual 2
05-039 5MVX641CB001 Actuator Caset A 1
05-040 5MVX321SB012 Actuator Caset B 1
05-041 5AAVROLL*027 Feed Roll Assy 1
05-041A 5MVM480RN001 Feed Tyre 2
05-041B 5MVM733SB002 Pully Feed Roll 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 12
Ref No. Part Code Description Quantity
05-042 5MMM176CJ003 Metal Bush KD 2
05-043 5MVX322DB012 Bush Transfer L 1
05-044 5MVX321DB009 Bush Transfer R 1
05-045 5MMW255LD002 Spring Bush 2
05-046 5MMT866SN014 Shaft Guide 1
05-047 5MVX332SB013 Cover Roll TR 1
05-051 5MVX832CB003 Bracket Roller 1
05-053 5AAY1500E*58 Roller Transfer 1
05-054 5MVS825XF003 Discharger 1
05-055 5MVS527RF009 Sheet Chute A 1
05-056 5MVS832KN002 Sheet Chute B 1
05-057 5MVS521KN002 Sheet Chute L 1
05-058 5MVS521KN003 Sheet Chute R 1
05-059 5MMM276CJ001 Metal Bush Regist 1
05-00X 5AAY1500*40 TRANS BRACKET ASSY 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 13
06-018
06-037
06-034
PAGE PRINTER - Parts Catalogue
06-025
06-040
06-018
06-017
06-006
06-029
06-042
06-015
06-014
06-032
06-010
06-005
06-012
06-039
KYOCERA FS-1500
Fig.6 - Fuser Unit
06-026
06-008
06-002
06-036
06-041
06-033
06-013 06-004
06-028
06-027
06-024
06-010
06-005
06-038
06-016
06-003
06-004
06-035 06-031
06-009 06-022
06-001
06-019
06-021
Page 14
06-011
06-020
06-007
06-030
06-009 06-023
06-035
Ref No. Part Code Description Quantity
06-000 FK-51 Fuser Kit (5PLPZCKAPKE)240V 1
06-000 FK-51A Fuser Kit 120V 1
06-001 5MMT888AX003 Roller Heat 1
06-002 5MMT886SN005 Roller Press 1
06-003 5MM8866SL012 Frame Fuser 1
06-004 5MMS627SL002 Plate Press 2
06-005 5MMW251LD004 Spring Press 2
06-006 5MVX842NB003 Guide Therm 1
06-007 5MVB653XBC01 Cover Fuser R l
06-008 5MVB663XB001 Cover Fuser L l
06-009 5MVM188XN006 Bushing Heat 2
06-010 5MVM166XN001 Bushing Press 2
06-011 5MVX833XBC02 Guide Entrance 1
06-012 5MVX865SH001 Guide FU 1
06-013 5MVM176DB006 Bushing Pom 1
06-014 5MVX332XN003 Separator 4
06-015 5MMW241LD003 Spring Separator 4
06-016 5MMT874SN003 Roller Exit 1
06-017 5MVM174DB002 Pully Exit 3
06-018 5MMW251LD016 Spring Pully 2
06-019 5MMX542SL004 Plate Release R 1
06-020 5MVG148NN002 Gear Heat Z35 1
06-021 5MVG138XN007 Gear Joint Z26 1
06-022 5MVG137DB026 Gear Idle Z21 1
06-023 5MVG127DB018 Gear Exit Z16 1
06-024 5MMX322RD001 Plate Earth 1
06-025 5MVX833XB001 Guide Exit Up 1
06-026 5MMX633RDC01 Holder Lamp R l
06-027 5MMX321RDC05 Holder Lamp L l
06-028 5MVX732CB001 Actuator Jam 1
06-029 5MMX732RD002 Plate Cord 1
06-030 5MMM176CJ005 Bushing SBK 1
06-031 5MVX832XB00l Guide Exit 1
06-032 5MMC852SL001 Stay Fuser 1
06-033 5MMX542SL003 Plate Release L l
06-034 5MMT733SN001 Shaft Exit 1
06-035 5MMW172SB001 Ring Stop 2
06-036 5MMT143SZ010 Stud Screw SL 2
06-037 5MVVL721WN25 Label Fuse Caution l
06-038 5EZPB2412120101 Lamp Heater 240V 1
06-038 5EZPB1214220101 Lamp Heater 120V 1
06-039 5EYFFQ16101**01 Thermostat 1
06-040 5AAXTM008GEA Thermistor Assy 1
06-041 5AAPRIFC1003CH Fuser PWB Assy 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 15
Ref No. Part Code Description Quantity
06-042 5AAVCLEAN026 Cleaner Roll 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 16
07-015
PAGE PRINTER - Parts Catalogue
07-017
07-008
07-022
07-014
07-023
Fig.7 - Face Down Unit
KYOCERA FS-1500
07-020
07-012 07-021
07-003
07-005
07-018
07-014 07-019
07-013
07-001
07-024
07-002
Page 17
07-011
07-007
07-009
07-006 07-004
07-010
Ref No. Part Code Description Quantity
07-000 5AAY1500E*04 Face Down Unit 1
07-001 5MVX853SH001 Guide FD 1
07-002 5MVX831CB001 Guide Change 1
07-003 5MVT873CB001 Shaft FD 1
07-004 5MMX653SL008 Plate Hinge R 1
07-005 5MMX663SL007 Plate Hinge L 1
07-006 5MVX311DB006 Actuator SOL 1
07-007 5MMW261LJ032 Spring SOL 1
07-008 5MVS825XF001 Brush Discharger 1
07-009 5MVG138DB020 Gear FD Z30 2
07-010 5MMX632SL006 Plate FD Joint 1
07-011 5MVG127DB018 Gear Exit Z16 1
07-012 5MVM176DN009 Bush 2
07-013 5MMW161LJ035 Spring Earth FD 1
07-014 5MVM320RB001 Exit Tyre 2
07-015 5MVB886SH020 Cover Top 1
07-016 5MVN260SH001 Knob Release 1
07-017 5MMW266LD002 Spring Knob 1
07-018 5MVS825XF002 Brush Discharge FD 1
07-019 5MMX821SL001 Plate Brush FD 1
07-020 5MMW271LD003 Spring Press CL 2
07-021 5MVM176SH002 Cap Press CL 2
07-022 5MVM273DB002 Pulley FD 2
07-023 5MMX322LD007 Bracket Pulley FD 2
07-024 5EZSA2401020306 Solenoid 1
5MVX876SH014 Face Down Output Tray 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 18
08-002
08-053
PAGE PRINTER - Parts Catalogue
08-006
08-001
08-009 08-011
08-007
08-047
08-012
08-004
08-046
08-033
08-010
KYOCERA FS-1500
Fig.8 - Drum Unit
08-032
08-058 08-029
08-051
08-045
08-017 08-034
08-018 08-008
08-049
08-005
08-028 08-054
08-024 08-052
08-016
08-057
08-043
08-058
08-014 08-034
08-052
08-026
08-044
08-013
08-022
08-021
Page 19
08-019 08-020
08-015
08-025
08-027 08-056
08-030
08-031
Ref No. Part Code Description Quantity
08-000 DK-51 Drum Unit (5PLPZCGAPKE) 1
08-001 5MVB864CB002 Frame Drum UP 1
08-002 5MVX643SB005 Cover M/C L 1
08-003 5MVX441SB004 Cover M/C R 1
08-004 5MVS222KB001 Sheet Ring Cover 1
08-005 5MMX222SL003 Plate Grid Adj 1
08-006 5MMZ211LDOCl Earth Zenner 1
08-007 5MMMX642LD001 Case Belt Holder 1
08-008 5MMX532LD002 Earth Lesd D 1
08-009 5MMX321LD016 Hook M/C 1
08-010 5AAVCASE*089 MCH Shield Assy 1
08-011 5MMW801XU005 Corona Wire 1
08-012 5MMW241LJ018 Spring CHG 1
08-013 5MVX864CB001 Frame Drum Low 1
08-014 5AAVBRUSH026 Contact Brush L Assy U 1
08-014 5AAVBRUSH028 Contact Brush L Assy E 1
08-015 5AAVBRUSH027 Contact Brush R Assy 1
08-016 5MMT864SN003 Roll CLN 1
08-017 5MVT864CB001 Screw 1
08-018 5MVQ321DN001 Brush Left 1
08-019 5MVQ321DN002 Brush Right 1
08-020 5MVQ211DN001 Brush CLN 1
08-021 5MVS822KN007 Sheet Scraper 1
08-022 5AAVBLADE013 Blade Assy 1
08-023 5MVS218RN009 Seal Blade 3
08-024 5MVS428LN001 Seal Drum Left 1
08-025 5MVS428LN002 Seal Drum Right 1
08-026 5MVG137DB030 Gear Screw Z24 1
08-027 5MVG126DB017 Gear Roll Z18 1
08-028 5MVG137DB031 Gear Z1830 1
08-029 5MVG137DB032 Gear Z24 1
08-030 5MVS811KNOC6 Sheet Roll 1
08-031 5MML821LD003 Bracket Sheet 1
08-032 5MMT343SN001 Pin Idler A 1
08-033 5MMT343SN002 Pin Idler B 1
08-034 5MMW241LD004 Spring Roll A 1
08-041 5MMVV241LD005 Spring Roll B 1
08-043 5AAY1500E*14 Drum Assy Euro 1
08-044 5MVS318LN001 Seal Ring Right 1
08-045 5MVS328LN001 Seal Ring Left 1
08-046 5AAXLD019GEA LED Assy 1
08-047 5AAY1500E*20 Case Belt Assy 1
08-048 5MVS812XN001 Tape Adhesive 1
08-049 5MVT860SB001 Roll Magic 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 20
Ref No. Part Code Description Quantity
08-051 5MVS222VB001 Sheet 1
08-052 5MVS218RN010 Seal Blade 2
08-053 5AAPRCZC1002AH PWB Assy 1
08-054 5AAPRlFCl002AH PWB Assy 1
08-056 5MVS721KN008 Sheet Drum Low 1
08-057 5MVS211KN001 Sheet Grip 1
08-058 5MVS211KN002 Sheet Cover Spring 2
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 21
09-002
09-001
09-008
09-003
09-007
09-006
09-009
09-010
Fig.9 - LED Head Unit
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 22
Ref No. Part Code Description Quantity
09-000 LK-51 LED Head (5PLPZCHAPKE) 1
09-001 5MVB863SB010 Frame LED 1
09-002 5MMT362SZ001 Stud Screw 2
09-003 5MMW271SZ001 Spring LED 2
09-004 5MVS641KB001 Sheet Frame 1
09-006 5MVX633SG001 Lever Frame LED 1
09-007 5MMW461SZ001 Spring LED Lever 1
09-008 5MVN221DG0001 Knob LED Volume 1
09-009 5AAXLH001GEA LED Head Assy 1
09-010 5AAPRLDG2001AH PWB Assy 1
PAGE PRINTER - Parts Catalogue KYOCERA FS-1500 Page 23
10-056
10-077
10-082
10-054
PAGE PRINTER - Parts Catalogue
10-021
10-082
10-003
10-048
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
