Image preview - the first page of the document
>> Download Kyocera PA-Units Parts Manual documenatation <<
Text preview - extract from the document
PRINTER OPTIONS
PA-UNITS
PARTS CATALOGUE
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 1
PA-UNITS Parts Catalogue
Table of Contents
Paper Path Adapter (PA-1) (Fig.1) 3
Paper Path Adaptor (PA-2, for FS-3500/A) (Fig.2) 5
Paper Path Adaptor (PA-5, for FS-6500/+/A) (Fig.3) 7
Paper Path Adaptor (PA-20, for FS-1700/3700) (Fig.4) 9
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 2
01-004
01-002
04-001
01-003
04-002
03-002
03-003
03-001
02-002
03-003
02-004
03-002
02-003
02-006
02-006 02-001
02-007
Fig.1 - Paper Path Adapter (PA-1)
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 3
Ref No. Part Code Description Quantity
01-000 PA-1 Papar Path Adapter (Rear Stack) 1
01-000 PA-1D Papar Path Adapter (Under Printer) 1
01-001 5SNSP0008801 CHASSIS DRIVE ASSY 1
01-002 5SNSP0008796 CHASSIS PINCH ASSY 1
01-003 5SNSP0008799 SPRING CHASSIS L 1
01-004 5SNSP0008807 SPRING CHASSIS R 1
02-001 5SNSP0009605 CHASSIS DRIVE BN 1
02-002 5SNSP0008803 HOLDER SHAFT LOCK 1
02-003 5SNSP0008804 SPRING SHAFT LOCK 1
02-004 5SNSP0008805 SHAFT LOCK 1
02-005 5SNSP0008806 ROLLER DRIVE ASSY 1
02-006 5SNSP0008795 GEAR Z25 2
02-007 5SNSP0008811 COLLAR 1
03-001 5SNSP0008793 ROLLER DRIVE 1
03-002 5SNSP0008794 GEAR Z12 2
03-003 5SNSP0008719 BUSHING A 2
04-001 5SNSP0008797 CHASSIS PINCH 3
04-002 5SNSP0008798 ROLLER PINCH 3
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 4
121-03
121-02
22-001
121-04
22-002
21-009
21-010
21-005
23-001
23-003
23-002
21-002
21-004
21-003
21-006
21-001
21-008
21-007
21-007
121-01
Fig.2 - Paper Path Adaptor (PA-2, for FS-3500/A)
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 5
Ref No. Part Code Description Quantity
21-000 PA-2 PAPER PATH ADAPTER FS-3500 1
21-001 5SNSP0009606 CHASSIS DRIVE NN 1
21-002 5SNSP0008803 HOLDER SHAFT LOCK 1
21-003 5SNSP0008804 SPRING SHAFT LOCK 1
21-004 5SNSP0009208 SHAFT LOCK N 1
21-005 5SNSP0009199 ROLLER DRIVE ASSY D 1
21-006 5SNSP0008795 GEAR Z25 1
21-007 5SNSP0009201 GEAR Z20 2
21-008 5SNSP0008811 COLLAR 1
21-009 5SNSP0009218 BUSHING ON 1
21-010 5SNSP0009219 PLATE EARTH PA2 1
121-01 5SNSP0009197 CHASSIS DRIVE ASSY 1
121-02 5SNSP0009202 CHASSIS PINCH ASSY 1
121-03 5SNSP0009204 SPRING CHASSIS LD 1
121-04 5SNSP0009205 SPRING CHASSIS RD
22-001 5SNSP0009203 CHASSIS PINCH N 1
22-002 5SNSP0008798 ROLLER PINCH 2
23-001 5SNSP0008793 ROLLER DRIVE 1
23-002 5SNSP0008794 GEAR Z12 1
23-003 5SNSP0008719 BUSHING A 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 6
31-004
32-001 31-005
31-008
32-001
32-002
31-006
32-002
31-001
31-006
31-007
31-002
31-003
Fig.3 - Paper Path Adaptor (PA-5, for FS-6500/+/A)
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 7
Ref No. Part Code Description Quantity
30-000 PA-5 PAPER PATH ADAPTOR FS-6500/+/A 1
31-001 5SNSP0009820 FRAME 1
31-002 5SNSP0009753 GEAR IDLE Z15 2
31-003 5SNSP0009821 GEAR DRIVE Z25 1
31-004 5SNSP0009822 PLATE EARTH 1
31-005 5SNSP0009823 ROLL FEED 1
31-006 5SNSP0009824 COLLAR 1
31-007 5SNSP0009787 GEAR DRIVE Z15 1
31-008 5SNSP0009825 ROLL PINCH ASSY 2
32-001 5SNSP0009814 ROLL PINCH 2
32-002 5SNSP0009826 SPRING ROLL PINCH 2
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 8
Fig.4 - Paper Path Adaptor (PA-20, for FS-1700/3700)
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 9
Ref No. Part Code Description Quantity
40-000 PA-20 Paper Path Adaptor 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PA-UNITS Page 10
