Image preview - the first page of the document
Kyocera PB Units Parts Manual


>> Download Kyocera PB Units Parts Manual documenatation <<

Text preview - extract from the document
                              PRINTER OPTIONS


                             PB-UNITS




     PARTS CATALOGUE

PRINTER OPTIONS - Parts Catalogue   KYOCERA PB-UNITS   Page 1
PB-UNITS Parts Catalogue
Table of Contents

Printer Base (Fig.1)                                                             3

Introduction

The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:

'Ref No.'          Reference number which corresponds to the parts in the figure
'Part code'                                   Part code which identifies the part
'Part description'                                 A brief description of the part
'Quantity'                      Quantity of the part used in the printer or option

Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.




PRINTER OPTIONS - Parts Catalogue   KYOCERA PB-UNITS                         Page 2
PRINTER OPTIONS - Parts Catalogue




                                                                                                                                           01-004




                                                                                  03-005                                                     01-009



                                                                                                                         01-010
                                                                         03-003                                                                       01-008


                                                                                           03-006

                                                           03-004
KYOCERA PB-UNITS



                                    Fig.1 - Printer Base




                                                                                           03-001




                                                                03-002



                                                                                            01-007




                                                                                                                                                        01-002
                                                                                              01-005



                                                                                                                                  01-006




                                                                                                       01-003
Page 3




                                                                                                                01-012

                                                                                            01-011
Ref No.      Part Code                Description                      Quantity

01-000       PB-1                     Printer Base (FS-1500/1550/16/34/36)      1
01-000       PB-2                     Printer Base (FS-3500)                    1
01-000       PB-20                    Printer Base (FS-1700/3700)               1
01-002       5AAMPF7B**01             BASE ASSY B                               1
01-003       5MMP153LD001             STOPPER PF                                1
01-004       5MMX432LD001             SPRING SHAFT ED                           1
01-005       5AAZPF7A**01             ROLLER DL                                 4
01-006       5MVS778RB002             FOOT PR                                   6
01-006       5MVS779RB002             FOOT PR (PB-20)                           6
01-007       5MBWK65D0ASZ             FLAT S WASHER                             8
01-008       5MVS224XF001             DISCHARGER PB                             1
01-009       5MMX321SM001             CORD KEEP                                 1
01-010       5AACCNNB2GEA             CONN. CORD ASSY                           1
01-011       5MML322LD001             PLATE EMC                                 1
01-012       5MMU852SL016             STAY MAIN                                 1
03-001       5MMU832SL002             RAIL                                      2
03-002       5MMU833SL001             STAY RAIL                                 2
03-003       5MMS657SL012             GUIDE PF F                                2
03-003       5MMS657SL014             GUIDE PF F (PB-20)                        2
03-004       5MMS657SL013             GUIDE PF R                                2
03-004       5MMS657SL015             GUIDE PF R (PB-20)                        2
03-005       5MVVL111WN02             LAYER LABEL                               2
03-006       5MVQ843RB001             PAD RAIL                                  1
03-009       5MMX321SM001             CORD KEEP                                 1




PRINTER OPTIONS - Parts Catalogue   KYOCERA PB-UNITS                         Page 4
