Image preview - the first page of the document
>> Download Kyocera Paper Feeder PF-2 Parts Manual documenatation <<
Text preview - extract from the document
PRINTER OPTIONS
PF-2
PARTS CATALOGUE
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 1
PF-2 Parts Catalogue
Table of Contents
Covers (Fig.1) 3
Internal Parts of Main Unit (Fig.2) 5
Trays (Fig.3) 8
Harness (Fig.4) 11
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 2
01-003
01-015
PRINTER OPTIONS - Parts Catalogue
01-002
01-018
01-013 01-020
01-004
01-001
01-014
01-019
01-006
01-005
01-016
KYOCERA PF-2
Fig.1 - Covers
01-008
01-007
01-017
01-009
01-011
01-010
Page 3
01-012
Ref No. Part Code Description Quantity
01-001 5SNSP0006304 TOP COVER 1
01-002 5SNSP0006306 FOOT SPACER 1
01-003 5SNSP0006309 SET SCREW 1
01-004 5SNSP0006306 REAR COVER 1
01-005 5SNSP0008342 SOARD BRACKET 1
01-006 5SNSP0006341 P.W. BOARD ASSY (MAIN) 1
01-007 5SNSP0008335 UPJOINTCORDASSY 1
01-008 5SNSP0006336 LOW JOINT CORD ASSY 1
01-009 5SNSP0008320 FEED COVER ASSY 1
01-010 5SNSP0006310 FEED COVERPINA 1
01-011 5SNSP0006311 FEED COVER PIN B 1
01-012 5SNSP0006316 RIGHT COVER 1
01-013 5SNSP0006303 LEFTCOVER 1
01-014 5SNSP0006305 BUSHING PLATE 1
01-015 5SNSP0006345 CONN CORD ASSY(I/F) 1
01-016 5SNSP0006436 FERRITE CDRE 1
01-017 5SNSP0008307 SPACERPIN 2
01-016 5SNSP0008436 FERRITE CORE 1
01-018 5SNSP0008378 EARTH PLATE 1
01-019 5SNSP0008379 SPACER COLLAR 4
01-020 5SNSP0006347 BUSHING 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 4
02-017
PRINTER OPTIONS - Parts Catalogue
02-021
02-018 02-016
02-019
02-034
02-001 02-020
02-023 02-033
02-022
02-047
02-002 02-040
02-032
02-004 02-037
02-041
02-039
02-038 02-042 02-015
02-006
02-013
Fig.2 - Internal Parts of Main Unit
02-030 02-046
02-036
02-005
02-025
02-003
KYOCERA PF-2
02-038 02-012
02-039 02-031
02-008
02-014
02-009
02-028
02-035
02-010
02-004
02-023 02-029
02-024
02-007 02-021
02-037
02-010
02-040
02-048 02-027
02-041
02-026
02-042
02-011
02-010
02-044
Page 5
02-045
02-045
02-043
Ref No. Part Code Description Quantity
02-001 5SNSP0008319 UPPER CHANNEL R 1
02-002 5SNSP0008318 UPPER CHANNEL F 1
02-003 5SNSP0008334 FRAME U FT 1
02-004 5SNSP0008317 GUIDE RAIL 2
02-005 5SNSP0008329 LOWER CHANNEL F 1
02-006 5SNSP0008330 LOWER CHANNEL R 1
02-007 5SNSP0008271 GUIDE FRAME F 1
02-008 5SNSP0008272 GUIDE FRAME R 1
02-009 5SNSP0008273 CHANNEL FRAME 2
02-010 5SNSP0008292 SUDE RAIL 4
02-011 5SNSP0008312 BASE FRAME 1
02-012 5SNSP0008297 CARRIER MOTOR ASSY 1
02-013 5SNSP0008298 CARRIER MOTOR BKT 1
02-014 5SNSP0008289 RUBBER PLATE 1
02-015 5SNSP0008300 TIMING PULLEY B 1
02-016 5SNSP0008301 TIMING BELT 1
02-017 5SNSP0008293 FEEDMOTORASSY 2
02-018 5SNSP0008294 FEED MOTOR BRACKET 2
02-019 5SNSP0008295 MOTOR PLATE 2
02-020 5SNSP0008286 MOTOR GEAR Z20B 2
02-021 5SNSP0008302 MICRO SWITCH 3
02-022 5SNSP0008331 SWITCH BRACKET 2
02-023 5SNSP0008332 SCREW PLATE 3
02-024 5SNSP0008333 COVER SW BRACKET 1
02-025 5SNSP0008274 GUIDE PLATE BRACKET 1
02-026 5SNSP0008275 GUIDE PLATE LOWER 1
02-027 5SNSP0008276 GUIDE PLATE MIDDLE 1
02-028 5SNSP0008277 PHOTO SENSOR 1
02-029 5SNSP0008278 SEN80R BRACKET B 1
02-030 5SNSF0008279 GUIDE PLATE UPPER 1
02-031 5SNSP0008280 MAGNET PLATE 1
02-032 5SNSP0008281 CARRIER ROLL LOW 1
02-033 5SNSP0006282 ROLLEUSH 1
02-034 5SNSP0008283 TIMING PULLEY ASSY** 1
02-035 5SNSP0008192 BUSH METAL 1
02-036 5SNSP0008265 CARRIER ROLL UP 1
02-037 5SNSP0006286 PRESSURE LEVER 2
02-038 5SNSP0006267 BEARING 2
02-039 5SNSP0006288 STOPPER PIN 2
02-040 5SNSP0006288 LEVER PIN 2
02-041 5SNSP0006290 PRESSURE SPRING 2
02-042 5SNSP0006291 SPRING PLATE 2
02-043 5SNSP0008313 FRONT CASTER 2
02-044 5SNSP0008314 REARCASTER 2
02-045 5SNSP0008315 FOOT 4
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 6
Ref No. Part Code Description Quantity
02-046 5SNSP0006360 OPEN CLOSED BUSHING 1
02-047 5SNSP0008361 CABLE HOLDER A 4
02-048 5SNSP0006382 CABLE HOLDER B 3
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 7
03-055
03-046
PRINTER OPTIONS - Parts Catalogue
03-054 03-045
03-039
03-001 03-038
03-074 03-028
03-047
03-002
03-041
03-056 03-048
03-043
03-042 03-040
03-003 03-008 03-036
03-010 03-035
03-044 03-041 03-037
03-013
03-006 03-007
03-012
03-007
03-060 03-057
03-017 03-052
03-053
03-004 03-011
03-014
03-007 03-061
KYOCERA PF-2
Fig.3 - Trays
03-015 03-062 03-031
03-073
03-016 03-058
03-005
03-057
03-029
03-059
03-072 03-063
03-064
03-049
03-033
03-050
03-065
03-034
03-032 03-051
03-020
03-075
03-030
03-027
03-071
03-022
03-026
03-021
03-019 03-024 03-023
Page 8
03-025
03-018
Ref No. Part Code Description Quantity
03-001 5SNSP0008197 LABEL PAPER SIZE 2
03-002 5SNSP0008201 PAPER STOPPER 2
03-003 5SNSP0008196 FEED BASE 2
03-004 5SNSP0008196 PW BOARD ASSY (SENSOR) 2
03-005 5SNSP0008270 BASE SUPPORT 2
03-006 5SNSP0008196 SLIDE BRACKET 2
03-007 5SNBP0008199 SLIDE BASE 6
03-008 5SNSP0008200 FLAT SPRING 2
03-010 5SNSP0008203 ROLL STOPPER 2
03-011 5SNSF0008204 JOINT LINK 2
03-012 5SNSP0008205 ADJUST PLATE 2
03-013 5SNSP0008206 PIVOT SPACER 2
03-014 5SNSP0008207 PIVOT PIN 2
03-015 5SNSP0008206 SLIDE BRACKET PIN 2
03-016 5SNSP0008208 SLIDE COLLAR 2
03-017 5SNSP0008210 SENSOR PLATE 2
03-018 5SNSP0003336 FRONTCOVER 2
03-019 5SNSP0006339 PANEL 2
03-020 5SNSF0008340 P.W. BOARD ASSY (LED) 2
03-021 5SNSF0008191 FRAME FRONT 2
03-022 5SNSP0003259 LEVER BRACKET R 2
03-023 5SNSP0008260 HOOK PLATE 2
03-024 5SNSP0008261 HOOK PIN 2
03-025 5SNSP0008262 HOOK SPRING 2
03-026 5SNSP0003263 OPEN LEVER 2
03-027 5SNSP0003264 LEVER BRACKET L 2
03-028 5SNSP0008202 STOPPER PLATE 2
03-029 5SNSP0008195 STAY LEFT 2
03-030 5SNSP0008194 STAY RIGHT 2
03-031 5SNSP0003193 FRAME REAR 2
03-032 5SNSP0003192 BUSH METAL 4
03-033 5SNSF0008236 HINGE ROD 2
03-034 5SNSF0008237 HINGE BRACKET 2
03-035 5SNSF0008236 HINGE BUSH 2
03-036 5SNSF0003239 HINGE LEVER 2
03-037 5SNSP0003240 GUIDE ROLL 2
03-038 5SNSP0008241 SPRING PLATE 2
03-039 5SNSF0008242 SPRING PLATE PIN 2
03-040 5SNSP0006243 TENSION SPRING A 2
03-041 5SNSP0008244 ANGLE PLATE 4
03-042 5SNSP0006245 PULUEY 2
03-043 5SNSP0008246 PULUEY PIN 2
03-044 5SNSP0008247 COU AR 2
03-045 5SNSP0008248 TENSION SPRING B 2
03-046 5SNSP0008249 TENSION WIRE 2
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 9
Ref No. Part Code Description Quantity
03-047 5SNSP0008250 WIRE PIN 2
03-048 5SNSP0008251 TENSION SPRING C 2
03-049 5SNSP0008252 FEED ROLLSHAFT 2
03-050 5SNSP0008253 FEED ROLL 6
03-051 5SNSP0008254 WHEEL ROLL 6
03-052 5SNSP0008255 FEED BUSH 2
03-053 5SNSP0008256 FEED GEAR ASSY 2
03-054 5SNSP0008230 GUIDE PLATE F 2
03-055 5SNSP0008231 GUIDE PLATE R ASSY 2
03-056 5SNSP0008219 BOTTOM PLATE ASSY 2
03-057 5SNSP0008224 RACK 4
03-058 5SNSP0008225 GEAR Z145 2
03-059 5SNSP0008226 RACK GUIDE PLATE 2
03-060 5SNSP0008227 SENSOR BRACKET A 2
03-061 5SNSP0008226 FEED ACTUATOR 2
03-062 5SNSP0008229 PHOTO SENSOR 2
03-063 5SNSP0008211 PAPER FEED PLATE 2
03-064 5SNSP0008212 GUIDE LIB 4
03-065 5SNSP0008213 SEPARATOR ASSY 2
03-071 5SNSP0008268 BASE PLATE 2
03-072 5SNSP0008363 CHANNEL 1
03-073 5SNSP0008364 CABLE CLAMP 1
03-074 5SNSP0008385 CORD KEEP 1
03-075 5SNSP0008349 OPEN CLOSED BUSHING 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 10
04-003
04-003
04-001
04-002
04-005
04-006
04-007
04-004
Fig.4 - Harness
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 11
Ref No. Part Code Description Quantity
04-001 5SNSP0008266 CONN CORD ASSY(CONNECT) 2
04-002 5SNSP0008267 CONN CORD ASBY(SENSOR) 2
04-003 5SNSP0008266 CONN CORD ASSY(DISPLAY) 2
04-004 5SNSP0008343 CONN CORD ASSY(MAIN) 1
04-005 5SNSP0008344 CONN CORD ASSY(MOTOR) 2
04-006 5SNSP0008327 UPPER CORD ASSY 1
04-007 5SNSP0008328 LOWER CORD ASSY 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-2 Page 12
