Kyocera Paper Feeder PF-60 Service Manual


>> Download Kyocera Paper Feeder PF-60 Service Manual documenatation <<

Text preview - extract from the document
Paper feeder   PF-60
Conventions

Throughout this manual, the following conventions are used:

  Italic letters refer related chapters or sections or documentations.


            This symbol followed by WARNING denotes that the following paragraph(s) includes
            precautions which, if ignored, could result in personal injury, and/or irrevocable
            damage to the paper feeder.
            When followed by CAUTION this symbol denotes that the following paragraph(s)
            include the precautions which, if ignored, could result in damage to the paper feeder.




PF-60
About the chapters


The manual is comprised of the following chapters:


  Chapter 1:     Product Information

  Chapter 2:     Installation

  Chapter 3:     Maintenance

  Chapter 4:     Operation Overview

  Chapter 5:     Disassembly
                                                     Contents
  Chapter 6:     Troubleshooting

  Chapter 7:     Paper Specifications

  Appendix A: Diagrams




                                                     Contents




                                                     Contents




                                                                PF-60
REVISION HISTORY

  Version        Date          Replaced Pages             Remarks
    1.00      2-Apr-2001              -




TO OBTAIN THE LATEST PRINTER DRIVERS AND UTILITIES, VISIT US AT OUR INTERNET HOME
PAGE: http://www.kyocera.com/w2k




PF-60
Chapter 1   Product Information
                                                Chapter 1 Contents
1-1 Specifications ................................................................................................................................... 1-3
1-2 Names of parts ................................................................................................................................. 1-4
1-1 Specifications



                              Table 1-1-1 Specifications

        Item                                       Description
 Compatible printer         Kyocera Mita Page Printers
                            FS-1800/1800N and FS-3800/3800N
 Number of paper cassettes  1
 Paper sizes                Legal size and A5 to A4/letter universal cassette
                            14.8 to 21.0 cm
