Image preview - the first page of the document
Kyocera Sorter SO30 Parts Manual


>> Download Kyocera Sorter SO30 Parts Manual documenatation <<

Text preview - extract from the document
                              PRINTER OPTIONS


                                    SO-30




     PARTS CATALOGUE
                                     14-12-1998


PRINTER OPTIONS - Parts Catalogue    KYOCERA SO-30   Page 1
SO-30 Parts Catalogue
Table of Contents

External Covers (Fig.1)                                                           3
Paper Conveying Assembly (Fig.2)                                                  5
Frame Assembly (Fig.3)                                                            8
Mail Tray Assembly 1-8 (Fig.4)                                                   10
Mail Tray Assembly 9 (Fig.5)                                                     12
Drive Assembly (Fig.6)                                                           14
Multi Tray, Door Assembly (Fig.7)                                                17
Base Assembly (Fig.8)                                                            19

Introduction

The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:

'Ref No.'          Reference number which corresponds to the parts in the figure
'Part code'                                   Part code which identifies the part
'Part description'                                 A brief description of the part
'Quantity'                      Quantity of the part used in the printer or option

Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30                            Page 2
                                                    01-012




                                        01-003




                                                                           01-005




                                                       01-009

                                    01-004




                                                                01-006

                                           01-010

                                                       01-008




                                                 01-007




                                                    01-011
                                                                                             01-002




01-001




                                                 Fig.1 - External Covers



    PRINTER OPTIONS - Parts Catalogue                  KYOCERA SO-30                Page 3
Ref No.      Part Code              Description           Quantity

01-00A       5SNSASO30E32           COVER TOP ASSEMBLY           1
01-001       5SNSP0012739           COVER FRONT                  1
01-002       5SNSP0012740           COVER REAR                   1
01-003       5SNSP0012698           COVER TOP                    1
01-004       5SNSP0012703           BRUSH EXIT                   1
01-005       5SNSP0012704           PLATE EARTH EXIT             1
01-006       5SNSP0012702           LEVER SENSOR TOP             1
01-007       5SNSASO30E19           PWB SENSOR TOP               1
01-008       5SNSP0012699           PLATE SPRING ROLLER          1
01-009       5SNSP0012700           ROLLER TOP                   1
01-010       5SNSP0012701           SHAFT ROLLER TOP             1
01-011       5SNSASO30E20           CONN.ASM-CK2                 1
01-012       5SNSP0012750           CLAMP WIRE                   1




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30             Page 4
                                                                                                                                          02-054
                                                                                                                                02-053

            02-052                                               02-011                                           02-016
                                                                                                                                                          02-055


            02-051

                                 02-050



                                                                                                                                                                                                02-049




02-016



                                                                                                                           02-015
                                       02-019


                                                                                                        02-009

                                                                                           02-014



                     02-008

                                                           02-041          02-013                                  02-040
                                                                                                                                        02-002



                                              02-010                                                         02-001                    02-044


                                                                                                        02-005


                                                                                           02-042
                                                                                                                                       02-044

                                                         02-044                   02-005

                                                                                                                                         02-004

   02-049                                                                                                                                02-033
                                                       02-045                                                    02-037


                                          02-002


                                                       02-017                               02-005                                            02-044
                                                                02-036
                                                     02-003
                              02-044
                                                            02-018                                                                   02-006


                                                                                                                 02-035
                                          02-004
                                                                                                           02-001
                                       02-028

                                                                                              02-005                                          02-034
                                                        02-038
                                       02-047                                                                              02-029

                                                                                                                                                         02-031
                                           02-044
                                                                                               02-007
                                                                                                                                                                             02-033


                                                                                                                                                                    02-032
                                                                                  02-023
                                                                    02-043
                                          02-006                                                                 02-022
                                                                                                                                02-028
                                                                         02-021



                                                                                                                                                             02-030
                                            02-020                                                      02-027                                  02-046
                                                                                            02-024
                                                                                                                                                                    02-048


                                              02-024

                                                                02-022
                                                                                                         02-025


                                                                   02-026
                                                                                                                                                           06-069


                                                                                                                              02-012
                                                                                                                                                                                       02-039
                                                                                                                                                              06-074

                                                                                                                            02-056




                                                                                                                                                           02-039




                                                                     Fig.2 - Paper Conveying Assembly



  PRINTER OPTIONS - Parts Catalogue                                                  KYOCERA SO-30                                                                                    Page 5
Ref No.      Part Code              Description              Quantity

02-00B       5SNSASO30E33           INDEXER ASSEMBLY                1
02-00F       5SNSASO30E37           REEL FILM ASSEMBLY              1
02-001       5SNSP0012705           SHAFT GUIDE 2                   1
02-002       5SNSP0012710           GUIDE PAPER                     1
02-003       5SNSP0012708           SHAFT GUIDE 1                   1
02-004       5SNSP0012709           GUIDE CENTER                    1
02-005       5SNSP0012706           ROLLER GUIDE                    1
02-006       5SNSP0012707           GUIDE LOWER                     1
02-007       5SNSP0012656           ROLLER INDEXER                  1
02-008       5SNSP0012633           FLAPPER                         1
02-009       5SNSP0012634           GUIDE FLAPPER                   1
02-010       5SNSP0012636           SPRING FLAPPER                  1
02-011       5SNSP0012637           GUIDE PAPER EXIT                1
02-012       5SNSASO30E07           PWB LR43                        1
02-013       5SNSP0012749           SENSOR TLP1241                  1
02-014       5SNSASO30E04           CONN.CORD ASSEMBLY PES          1
02-015       5SNSP0012609           GUIDE PAPER ENTRANCE            1
02-016       5SNSP0012608           BUSHING 6                       1
02-017       5SNSP0012657           FRAME INDEXER UPPER             1
02-018       5SNSP0012667           BRUSH INDEXER LOWER             1
02-019       5SNSP0012638           ROLLER EXIT                     1
02-020       5SNSP0012658           PLATE INDEXER                   1
02-021       5SNSP0012662           GUIDE INDEXER                   1
02-022       5SNSP0012660           ROLLER INDEXER W                1
02-023       5SNSP0012659           ROLLER INDEXER A                1
02-024       5SNSP0012661           SPRING INDEXER A                1
02-025       5SNSP0012629           FILM PAPER GUIDE                1
02-026       5SNSP0012631           GUIDE FILM 2                    1
02-027       5SNSP0012630           GUIDE FILM 1                    1
02-028       5SNSP0012649           HOLDER INDEXER                  1
02-029       5SNSP0012652           ROLLER INDEXER BELT             1
02-030       5SNSASO30E10           BKT INDEXER                     1
02-031       5SNSP0012664           PULLEY GEAR Z31                 1
02-032       5SNSP0012665           FLANGE PULLEY                   1
02-033       5SNSP0012666           GEZR Z20                        1
02-034       5SNSP0012663           PLATE EARTH INDEXER 1           1
02-035       5SNSP0012653           FRAME INDEXER LOWER             1
02-036       5SNSP0012654           RIB FRONT INDEXER               1
02-037       5SNSP0012655           RIB REAR INDEXER                1
02-038       5SNSP0012755           BUSHING 4                       1
02-039       5SNSP0012744           WIRE CLAMP                      1
02-040       5SNSP0012750           WIRE CLAMP                      1
02-041       5SNSP0012610           CUSHION SENSOR                  1
02-042       5SNSP0012585           SHEET                           1
02-043       5SNSP0012670           PLATE EARTH INDEXER 2           1


PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30                Page 6
Ref No.      Part Code              Description            Quantity

02-044       5SNSP0012800           CUSHION GUIDE ROLLER          1
02-045       5SNSP0012669           BRUSH INDEXER UPPER           1
02-046       5SNSP0012650           PLATE EARTH HOLDER 1          1
02-047       5SNSP0012651           PLATE EARTH HOLDER 2          1
02-048       5SNSP0012611           GUIDE PAPER ENTRANCE          1
02-049       5SNSP0012635           BUSHING 4                     1
02-050       5SNSP0012639           BKT SENSOR                    1
02-051       5SNSASO30E05           PWB SENSOR                    1
02-052       5SNSP0012640           HOLDER SENSOR                 1
02-053       5SNSP0012675           PULLEY S2M-20                 1
02-054       5SNSP0012674           FLANGE PULLEY                 1
02-055       5SNSP0012648           CLIP 5                        1
02-056       5SNSP0012592           COVER SENSOR                  1




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30              Page 7
                                                                                                                                                 03-017




                                                                                                                                                          03-004

                    03-016
                                                                                                                                        03-020


                                                                                            03-003



                                               03-015


                03-020

                                                                                                                                            03-020         03-005

                                                                                                              03-002




               03-020




                                                                                                                                            03-020
 03-004                                                                               03-014

03-005
                                                                            03-018
                                                                                                     03-007
                                                                                                                03-006


               03-020


                                                                          03-010
                                                            03-011
                                                                                   03-019
                                                                                                       03-008




                                      03-002
                                                        03-009                                                           03-022


                                                                                                                          03-001
                                                                 03-019




                             03-001


                                                        03-012                                                                     03-021




                                                                                        03-017




                                                           Fig.3 - Frame Assembly



          PRINTER OPTIONS - Parts Catalogue                      KYOCERA SO-30                                                               Page 8
Ref No.      Part Code              Description            Quantity

03-001       5SNSP0012599           RAIL INDEXER                  1
03-002       5SNSP0012711           GUIDE A RAIL                  1
03-003       5SNSP0012605           GUIDE RAIL                    1
03-004       5SNSP0012536           PIN ROCK                      1
03-005       5SNSP0012597           ACTUATOR K                    1
03-006       5SNSP0012584           BKT SENSOR                    1
03-007       5SNSP0012585           SHEET SENSOR                  1
03-008       5SNSP0012743           SENSOR GP1S74P                1
03-009       5SNSP0012592           COVER SENSOR                  1
03-010       5SNSP0012593           FILM SENSOR                   1
03-011       5SNSP0012589           PLATE B STOPPER F             1
03-012       5SNSASO30E01           PWB PT43                      1
03-013       5SNSP0012586           LEVER SENSOR                  1
03-014       5SNSP0012591           PLATE B STOPPER R             1
03-015       5SNSP0012600           GUIDE C RAIL                  1
03-016       5SNSP0012594           FRAME FRONT                   1
03-017       5SNSP0012602           FRAME REAR                    1
03-018       5SNSASO30E02           CONN.CORD ASSMBLY PT          1
03-019       5SNSP0012744           CLAMP WIRE                    1
03-020       5SNSP0012595           MAT CUSHION                   1
03-021       5SNSP0012587           SPRING LEVER                  1
03-022       5SNSP0012808           COVER CASTER                  1




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30              Page 9
                                                                      04-004
                                                             04-005




                                                                                           04-003
                                                                               04-002
04-001




                                                                                        04-006
                                             Fig.4 - Mail Tray Assembly 1-8
         PRINTER OPTIONS - Parts Catalogue         KYOCERA SO-30                                    Page 10
Ref No.      Part Code              Description            Quantity

04-001       5SNSP0012731           TRAY MAIL                     1
04-002       5SNSP0012732           LEVER EMPTY                   1
04-003       5SNSP0012734           LEVER FULL 1                  1
04-004       5SNSP0012735           LEVER FULL 2                  1
04-005       5SNSP0012801           SPRING LEVER EMPTY            1
04-006       5SNSP0012802           AADITIONAL MAIL TRAY          1




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30             Page 11
                                                                   05-003
              05-001




                                                                                     05-002
                                                                            05-004
                                    Fig.5 - Mail Tray Assembly 9
PRINTER OPTIONS - Parts Catalogue        KYOCERA SO-30                                        Page 12
Ref No.      Part Code              Description            Quantity

05-001       5SNSP0012731           TRAY MAIL                     1
05-002       5SNSP0012732           LEVER EMPTY                   1
05-003       5SNSP0012801           SPRING LEVER EMPTY            1
05-004       5SNSP0012802           ADDITIONAL MAIL TRAY          1




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30             Page 13
                                                                                                                                       06-057



                      06-063                                                                                                                                           06-058                                         06-070



                                    06-061                                    06-060
                                                                                                            06-055


                                                                                                                                                                                             06-050
                                                                                                                                            06-056
                                                                                                                                                              06-046
                                             06-062                                                06-009
                                                                                                                                                                                                    06-049

                                                                                                                                                                                                                                         06-069
                                                                                                                06-016                   06-047
                                                                                                                                                                  06-048
                                             06-059                 06-005                                                                                                   06-021                                                     06-072


                                                                                 06-008
                                                                                                                         06-022
                                                           06-008                                                                        06-073
                        06-001
                                    06-005            06-009                                                         06-018
                                                                                                                                                                                        06-052
                                                                                                                                                                           06-043                06-051

                                                                                               06-006

                          06-004                                                                                                          06-017

                                                                                                                                                 06-075
                                                                                                                                                                                    06-074                                              06-068
                                                                                                                                                         06-042
                                                                                                                                                                             06-071
                      06-003                                            06-013                                                                                        06-007
   06-053                                                           06-012
                                                            06-013                                                                                                                                           06-027
                                                                                                                                                              06-040
                         06-002                   06-014
                                         06-008                                                                                                                              06-026

                                                                     06-021
                           06-015                                             06-024                                                                                                                 06-026

         06-018                                                                                                                                                                 06-030
                                                                                                                                         06-041
                                                                                                                                                                     06-066                                                    06-025
                                                                                                                                   06-075
         06-016                                                                                                                                                                06-038



                                                                 06-064
             06-017

                                                                                                                                                                                06-031



                                                                 06-056                                                                                                                                          06-029
                                                                                                                                                           06-035
                                                                 06-010                                                                06-028                                                                   06-032

                                                                         06-013
                                                                06-011
                                                                                                                                                                                                             06-033
                                                                                                                                                06-056

                                                               06-021                                                              06-017


                                                                        06-012
                                        06-013                                                                                                                        06-035

                                                                                                                                                                                                                               06-065
                                                      06-020                                                                                             06-036
                                                                         06-019
06-054                                                                                                                                           06-037
                                                               06-023
                                                                                                                                         06-017

                                                                                                       06-024                                                                   06-034
                                                                              06-017                                                                                  06-044


                                                                                                                                                 06-073

                                                                                                                                06-039



                                                                                                                              06-021

                                                                                                                      06-020


                                                                                                            06-021


                                                                                          07-019
                               06-017




                                                                                           Fig.6 - Drive Assembly



                  PRINTER OPTIONS - Parts Catalogue                                            KYOCERA SO-30                                                                                          Page 14
Ref No.      Part Code              Description           Quantity

06-001       5SNSASO30E25           PWB SENSOR A                 1
06-002       5SNSP0012607           ROLLER ENTRANCE              1
06-003       5SNSP0012632           SHAFT HANGER FILM            1
06-004       5SNSP0012621           SHAFT REEL FILM              1
06-005       5SNSP0012624           ARBOR REEL FILM              1
06-006       5SNSO0012622           PULLEY REEL FILM             1
06-007       5SNSP0012746           SPACER KGLS-18S              1
06-008       5SNSP0012623           SPRING REEL FILM             1
06-009       5SNSP0012626           SPRING REEL FILM R           1
06-010       5SNSP0012617           BELT S3M 442 60              1
06-011       5SNSP0012615           BELT S3M 430 60              1
06-012       5SNSP0012613           PULLEY S3M 18 A              1
06-013       5SNSP0012619           PULLEY S3M 18 B              1
06-014       5SNSP0012627           REEL ADJUST ARBOR            1
06-015       5SNSP0012628           SPRING REEL ADJUST           1
06-016       5SNSP0012752           BUSHING MF                   1
06-017       5SNSP0012608           BUSHING 6                    1
06-018       5SNSP0012641           SPRING REEL SHAFT            1
06-019       5SNSP0012612           SHAFT DRIVE LOWER            1
06-020       5SNSP0012614           PULLEY S3M 23                1
06-021       5SNSP0012648           CLIP 5                       1
06-022       5SNSP0012756           WIRE CLAMP                   1
06-023       5SNSP0012616           BELT S3M 5760                1
06-024       5SNSP0012743           SENSOR GP1S74P               1
06-025       5SNSP0012713           BKT CONN. INTER              1
06-026       5SNSASO30E23           CONT SUB PWB                 1
06-027       5SNSASO30E24           EPROM                        1
06-028       5SNSP0012712           SWITCHING REG                1
06-029       5SNSP0012676           MOTOR INDEXER                1
06-030       5SNSP0012680           PLATE ENCODER 40             1
06-031       5SNSP0012679           COLLAR MOTOR                 1
06-032       5SNSP0012678           GEAR WORM                    1
06-033       5SNSP0012677           BKT MOTOR INDEXER            1
06-034       5SNSP0012681           BKT SENSOR INDEXER           1
06-035       5SNSP0012748           SENSOR TLP1225               1
06-036       5SNSP0012671           PLATE ENCODER 4              1
06-037       5SNSP0012620           GEAR Z30                     1
06-038       5SNSP0012747           SPACER KGLS-16S              1
06-039       5SNSP0012618           SHAFT DRIVE INDEXER          1
06-040       5SNSP0012604           PLATE CONT. PWB              1
06-041       5SNSP0012745           SW INDEXER POSITION          1
06-042       5SNSP0012603           SENSOR BKT PWB               1
06-043       5SNSP0012675           GEAR LIMIT                   1
06-044       5SNSP0012750           WIRE CLAMP SKB-1M            1
06-045       5SNSASO30E09           BKT MOTOR CONVEYING          1


PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30            Page 15
Ref No.      Part Code              Description           Quantity

06-046       5SNSP0012646           SHAFT DRIVE UPPER            1
06-047       5SNSP0012647           GEAR Z23                     1
06-048       5SNSP0012754           BEARING MF106ZZ              1
06-049       5SNSP0012753           BELT S2M 60                  1
06-050       5SNSP0012643           PULLEY IDLER GEAR            1
06-051       5SNSP0012644           MOTOR CONVEYING              1
06-052       5SNSP0012645           PULLEY S2M 16                1
06-053       5SNSASO30E26           CONN. CORD BIN 2             1
06-054       5SNSASO30E28           SENSOR B PWB                 1
06-055       5SNSP0012672           MOTOR REVERSE BKT            1
06-056       5SNSP0012744           WIRE CLAMP                   1
06-057       5SNSP0012803           BELT S2M 56-40               1
06-058       5SNSP0012804           MOTOR REVERSE                1
06-059       5SNSP0012805           REAR COVER BKT               1
06-060       5SNSASO30E16           SOLENOID BKT                 1
06-061       5SNSP0012682           LEVER FLIPPER                1
06-062       5SNSP0012683           SOLENOID NS38                1
06-063       5SNSP0012684           SOLENOID SPRING              1
06-064       5SNSP0012606           SENSOR COVER BKT             1
06-065       5SNSASO30E13           CONN. CORD SENSOR 2          1
06-066       5SNSASO30E22           CONN. CORD REG               1
06-067       5SNSASO30E03           CONN. CORD SW                1
06-068       5SNSASO30E14           CONN. CORD MOTOR             1
06-069       5SNSASO30E06           CONN. CORD INDEXER           1
06-070       5SNSASO30E27           CONN. CORD BIN               1
06-071       5SNSASO30E15           CONN. CORD MOTOR             1
06-072       5SNSASO30E12           CONN. CORD TOP               1
06-073       5SNSP0012585           SENCOR SHEET                 1
06-074       5SNSASO30E08           CONN. CORD REVERSE           1
06-075       5SNSP0012757           SPACER KGLS-6S               1




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30            Page 16
                                                                                                 07-006

  07-022




                                                                        07-004
                                       07-021




                                                                                                                            07-008
                                                                                                                   07-009
                                                                                                           07-007


                                                                                     07-005      07-008


                                                                                        07-007


                                                                               07-008




                                                                                                                            07-012




                                                                                                               07-017




                                                                                                                               07-013

                                                                    07-003




                                                                                                                             07-016

                                                          07-002     07-013



                                                          07-017
                                                                                                                                     07-001
                                                   07-016


                                                                                                                                 07-011


                                                                                                                                07-014



                                                                    07-010                                                       07-015




                                                 07-012




                                        07-014

                                                     07-015




                                                                            07-019
                                                                                                                                07-018




                                                                                                          07-018
                                                                   07-020




                                    Fig.7 - Multi Tray, Door Assembly



PRINTER OPTIONS - Parts Catalogue           KYOCERA SO-30                                                                     Page 17
Ref No.      Part Code              Description             Quantity

07-001       5SNSP0012691           FRAME DOOR                     1
07-002       5SNSP0012685           COVER DOOR                     1
07-003       5SNSP0012688           CONVEYING BELT                 1
07-004       5SNSP0012737           SENSOR COVER                   1
07-005       5SNSP0012734           LEVER FULL 1                   1
07-006       5SNSP0012735           LEVER FULL 2                   1
07-007       5SNSP0012690           ROLLER IDLER                   1
07-008       5SNSP0012608           BUSHING 6                      1
07-009       5SNSP0012689           SHAFT ROLLER IDLER             1
07-010       5SNSP0012693           JAM LEVER                      1
07-011       5SNSP0012694           JAM LEVER SEAL                 1
07-012       5SNSP0012686           JAM INTERLOCK BKT              1
07-013       5SNSP0012687           DOOR LOCK SUPPORT              1
07-014       5SNSP0012601           DOOR STOPPER                   1
07-015       5SNSP0012697           DOOR LOCKER PLATE              1
07-016       5SNSP0012696           DOOR LOCKER                    1
07-017       5SNSP0012695           JAM LEVER SPRING               1
07-018       5SNSP0012806           BEARING LF1360ZZ               1
07-019       5SNSP0012692           CONVEYING BELT ROLLER          1
07-020       5SNSASO30E18           CONN. CORD                     1
07-021       5SNSP0012738           MULTI TRAY                     1
07-022       5SNSP0012807           MULTI TRAY GUIDE               1




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30              Page 18
                                                                                08-006




            08-003




                                       08-005




                                                     08-005




                                                                                                                        08-002




                                                             08-004




                                           08-008

08-002                                                                                                         08-015
                                                                  08-001




  08-011                                                                                                                 08-014


                                                                                                             08-016



                                                                                         08-017
   08-015


                                                                                                  08-007


                         08-013
                                                         08-017
                              08-015

                     08-014



                                                           08-016

                                                                           08-009
                                                08-014




                                                                                                           08-010


                                                Fig.8 - Base Assembly



 PRINTER OPTIONS - Parts Catalogue                  KYOCERA SO-30                                                     Page 19
Ref No.      Part Code              Description          Quantity

08-000       5SNSASO30E39           DOOR ASSEMBLY               1
08-001       5SNSP0012714           HIGHT ADJUST BKT            1
08-002       5SNSP0012715           KC FRAME                    1
08-003       5SNSP0012729           COVER L PLATE               1
08-004       5SNSP0012730           COVER R PLATE               1
08-005       5SNSP0012716           SIDE REINFORCEMENT          1
08-006       5SNSP0012726           CASTER COVER                1
08-007       5SNSP0012725           RAIL                        1
08-008       5SNSP0012723           FRAME ADJUST                1
08-009       5SNSP0012724           JOINT PLATE                 1
08-010       5SNSP0012741           JOINT BKT                   1
08-011       5SNSP0012722           CASTER ADJUST BKT           1
08-012       5SNSP0012728           ADJUST SCREW                1
08-013       5SNSP0012719           PLATE                       1
08-014       5SNSP0012720           CASTER ROLLER               1
08-015       5SNSP0012721           CASTER SHAFT                1
08-016       5SNSP0012717           PLATE                       1
08-017       5SNSP0012718           CATCH MAGNET                1




PRINTER OPTIONS - Parts Catalogue   KYOCERA SO-30           Page 20



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
