Image preview - the first page of the document
>> Download Kyocera Stacker HS-3e Parts Manual documenatation <<
Text preview - extract from the document
PRINTER OPTION
HS-3E
PARTS CATALOGUE
PRINTER OPTION - Parts Catalogue KYOCERA HS-3E Page 1
HS-3E Parts Catalogue
Table of Contents
HS-3E Handler Stacker (Fig.1) 3
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
PRINTER OPTION - Parts Catalogue KYOCERA HS-3E Page 2
03-013 01-013
01-002 01-012
03-009 01-008
03-032 01-009
PRINTER OPTION - Parts Catalogue
01-016
01-011
01-007
03-033
03-022
01-015
03-020
03-021
01-014
01-010
03-034 01-003
01-024
03-012 03-001
01-023
03-011
02-013
03-009
Fig.1 - HS-3E Handler Stacker
02-030
03-009
03-008
KYOCERA HS-3E
03-013
02-004
03-010 01-004
03-002
02-012
03-034
03-005 01-005
02-010 03-019 01-001
03-017
KP396B 01-006
02-023
02-029 03-006 03-004
02-006
02-005 02-011 03-016
03-003 03-018
02-025
02-017 02-016
02-009 03-024
02-024 02-007
02-027 03-007 03-009
02-026
03-029
02-001
02-015 03-026
KP398B
KP395B 03-030
02-019
02-003 03-014
03-031
03-008
Page 3
03-028
02-018 02-020 03-025 03-015
02-002 01-017
03-027
02-031 02-021 02-022
02-033
02-032
Ref No. Part Code Description Quantity
01-000 HS-3E HANDLER STACKER 1
01-001 5MVB885SW008 COVER RIGHT 1
01-002 5MVB885SW009 COVER LEFT 1
01-003 5MVX874SW002 LID TOP 1
01-004 5MMT733SN001 SHAFT EXIT 2
01-005 5MMW251LD005 SPRING PULLEY 4
01-006 5MVM174DB002 PULLEY EXIT 4
01-007 5MVX863SW005 COVER TOP 1
01-008 5AAYHS3***03 PUSH SWITCH ASSY 1
01-009 5MVB872SW030 TRAY BACK 1
01-010 5MVB876SW008 BKT HS 2
01-011 5MVS432SW001 COVER JOINT 1
01-012 5MVX332SB016 COVER GEAR 1
01-013 5MMW162LJ012 SPRING COVER 1
01-014 5MVM150RB009 BELT MXL109-32 1
01-015 5MVG048DB007 GEAR FUX Z32-P19 1
01-016 5MVG138DB020 GEAR FD Z30 1
01-017 5MVVSHS3E**1 LABEL SERIAL 1
01-023 5MMS522SL001 PLATE IDLE 1
01-024 5MVM177DB004 BELT IDLE PULLEY 1
01-025 5MVX333DN001 GUIDE PAPER EXIT 1
02-001 5MMZ866SL002 FRAME LOW 1
02-002 5MVB764SW005 BOX PWB 1
02-003 5AACCNNB3GEA CONN. CORD S00844 1
02-004 5MMS866SL017 GUIDE PAPER F 1
02-005 5MMT875SN005 ROLLER TRANS A 1
02-006 5MMT875SN006 ROLLER EXIT 1
02-007 5MVG127DB029 GEAR Z14 2
02-009 5MMM176CJ005 BUSHING SBK 2
02-010 5MVM176DB006 BUSHING POM 2
02-011 5MVL866SW002 GUIDE PAPER R 1
02-012 5MVG326DB001 PULLEY MXL14 2
02-013 5MVS862KN002 SHEET TRANSFER 1
02-015 5MVX431NN001 SPACING CLIP 2
02-016 5MMX777SL001 FRAME RIGHT 1
02-017 5AAYHS3***02 TRANS MOTOR ASSY 1
02-018 5MVG368DB001 GEAR Z28-P56 1
02-019 5MVG127DB030 GEAR FEED Z14 2
02-020 5MVG148DB018 GEAR Z14-Z36 1
02-021 5MVM150RB007 BELT MOTOR Z70 1
02-022 5MVM196DB003 PLATE ENCODER 1
02-023 5MMX777SL002 FRAME LEFT 1
02-024 5ESM010234***01 MICRO SWITCH 1
02-025 5AACCNNB4GEA CONN CORD S00845 1
02-026 5MVS421KN002 SHEET A 2
PRINTER OPTION - Parts Catalogue KYOCERA HS-3E Page 4
Ref No. Part Code Description Quantity
02-027 5MVS217SF001 SPACER BOX 1
02-029 5MMX332SL006 ADAPTER FRAME R 1
02-030 5MMX332SL007 ADAPTER FRAME L 1
02-031 5MMS227SL003 PLATE MAGNET 2
02-032 5MMK224FJ001 MAGNET 1
02-033 5MVM110DN001 ROLLER BELT 1
03-001 5MMX876SL020 FRAME ELEVATOR R 1
03-002 5MMX876SL021 FRAME ELEVATOR L 1
03-003 5MMS886SL007 FRAME STACK 1
03-004 5MMT865SN005 SHAFT FOOT 1
03-005 5MVX643SW003 FOOT 2
03-006 5MMT866SN018 SHAFT ELEVATOR 1
03-007 5MMM176CJ003 METAL BUSH KD 1
03-008 5MVM122DB003 BUSH POM 2
03-009 5MVG318DN001 PULLEY XL14 4
03-010 5MVB882SW004 TRAY ELEVATOR 1
03-011 5MVX665DN001 GUIDE ELEVATOR R 1
03-012 5MVX665DN002 GUIDE ELEVATOR L 1
03-013 5MVM190RB016 BELT XL280-9.6 2
03-014 5MVG138DN018 GEAR WHEEL H30 1
03-015 5MVG127DN031 GEAR MOTOR 1
03-016 5MVX532DN001 BKT SENSOR BOTTLE 1
03-017 5MBRP3045QNB PAN HEAD RIVET 1
03-018 5ESM010235***01 MICRO SWITCH 1
03-019 5MVX211NN019 LOCKING CARD SPACER 2
03-020 5MMT865SN004 SHAFT STAY 1
03-021 5AAYHS3***14 PAPER SIZE R ASSY 1
03-022 5AAYHS3***15 PAPER SIZE L ASSY 1
03-024 5ENXOS840133*01 PT. SENSOR 1
03-025 5MMU654SL001 BKT WORM 1
03-026 5MMS336SL008 PLATE WORM 1
03-027 5MVG117DN001 GEAR WORM 1
03-028 5MVM122DB003 BUSH POM 2
03-029 5MVG137DB024 GEAR CLUTCH Z22 1
03-030 5AAYHS3E***01 ELEV MOTOR ASSY 1
03-031 5MML654SL002 BKT DC MOTOR 1
03-032 5MVX832CB007 GUIDE CHANGE 1
03-033 5MMW162LJ011 SPRING GUIDE 1
03-034 5MMT263SZ016 PIN STUD 2
KP395B 5AAPRIFC2004AH P.W. BOARD ASSY 1
KP396B 5AAPRDVC2004AH P.W. BOARD ASSY 1
KP398B 5AAPRSSC2002AH P.W. BOARD ASSY 1
PRINTER OPTION - Parts Catalogue KYOCERA HS-3E Page 5
