Image preview - the first page of the document



>> Download 2K3-003 documenatation <<

Text preview - extract from the document

                                       Service Bulletin
 SB Number: SB 2K3-003                                                               Creation Date: 04/03/2011
 Subject:             Firmware upgrade (Firmware pack 1.02)
 Model:               FS-6025MFP/6025MFP(B)/6030MFP



     Item                            Contents
 1   Added support for BAM.          The recovery timing from the power saving priority mode has been shortened and
                                     stabilized.
 2   Improvement of the Fax          When the Fax is set to the one touch screen, and you press the reset key to cancel
     one touch screen timing.        a selected address, the time to reset the screen has been shortened.
 3   Incorrect barcode print-out.    The barcode may not be printed or may be printed incorrectly.
 4   Error code CF248                Error code CF248 may occur.




Firmware
Type                                       Program No.                                       Version
Upgrade Pack Ver.                          2K3_V1.02E                                        1.02
MAIN                                       2K3_2F00.001.403                                  001.403
MMI                                        2K3_7000.001.404                                  001.404
ENGINE                                     2K3_1000.004.002                                  004.002
IO                                         2K3_1E00.001.010                                  001.010
DP                                         3M8_9500.002.001                                  002.001
FAX BOOT/APL *                             5JR_5500.B01.019                                  B01.019
Firmware notes *: BOOT: B01.019 / APL: B01.019




Classification       Entire stock rework     In-field modification at next visit        X No modification necessary
                                                                                   In-field modification by case
Field measure      When the above mentioned phenomena occur, please upgrade the firmware to the latest
                   version.




Serial numbers of affected machines
Type                                                                Serial number
 FS-6025MFP/6025MFP/B/6030MFP                         February 2011 production.
The above mentioned changes have been applied to machines produced after the above mentioned production date.




KMIS Service Department, Kyocera Mita Europe                        Page  of                                       B053 / SB 2K3-003
