                                     Service Bulletin
 SB Number: SB 2K3-012                                                    Creation Date: 18/11/2011
 Subject:              Parts list correction
 Model:                FS-6025MFP/6025MFP(B)/6030MFP, FS-C8020MFP/8025MFP


The following parts mentioned in the parts list have been corrected.


Incorrect (Description)                                                                        Correct (Description)
Fig.     Ref.    Part No.           Part description   Applicable model(s)                      Part description
13       1       302LC93080         FK-8506            FS-C8020MFP/8025MFP                      FK-8506 IH
                 2LC93080




The following parts at the DP side hook and loop fasteners have been registered, which hold the Original mat
(Plate original 303JC04200).



                                                                  Hoop and loop fastener/sponge position
                                     X


             Y                                  X
                            X
                                                                                     Hook and loop
                                         X                                           fastener

                                                                                     Sponge



                                                                                     DP cover side

                                                                  X: Fastener             Cushion original mat B
                                                                  X: Sponge               Sponge original mat
                                                                  Y: Fastener             Cushion original mat
                                   DP cover                       Y: Sponge               Sponge original mat A



Parts
No. Old Parts          New Parts         Description                      Q'TY        Interchange- Applicable
    No.                No.                                                            ability      model(s)
                                                                          Old    New Old       New
1       ----------     303MX02031        CUSHION ORIGINAL MAT B           -      4    -        O      FS-6025MFP/
                       3MX02031                                                                       6025MFP/B
2       ----------     303K502080        SPONGE ORIGINAL MAT              -      4    -        O      /6030MFP,
                       3K502080                                                                       FS-C8020MFP/
                                                                                                      8025MFP
3       ----------     303J902370        CUSHION ORIGINAL MAT             -      1    -        O
                       3J902370
4       ----------     303M802320        SPONGE ORIGINAL MAT A            -      1    -        O
                       3M802320



KMIS Service Department, Kyocera Mita Europe                Page 1 of 1                               B329 / SB 2K3-012
