Image preview - the first page of the document
>> Download 2K3-013 documenatation <<
Text preview - extract from the document
Service Bulletin
SB Number: SB 2K3-013 Creation Date: 06/12/2011
Subject: Full page solid image or error code C3200
Model: FS-6025MFP/6025MFP(B)/6030MFP, FS-C8020MFP/8025MFP
Phenomenon A full page solid image may appear on the print-out or error code C3200 (Exposure lamp
error) may occur.
Cause The digital transistor in the CCD power supply circuit at the main board may be damaged,
resulting in the CCD failure.
Solution The constant of the digital transistor has been changed.
Parts
No. Old Parts New Parts Description Q'TY Interchange- Applicable model(s)
No. No. ability
Old New Old New
1 302K394010 302K394011 PARTS PWB MAIN ASSY 1 1 X O FS-6025MFP/
2K394010 2K394011 SP 6025MFP(B)/6030MFP
2 302K394020 302K394021 PARTS PWB MAIN ASSY 1 1 X O FS-6025MFP/
2K394020 2K394021 SP EU 6025MFP(B)/6030MFP
3 302K094130 302K094131 PARTS PWB MAIN ASSY 1 1 X O FS-C8020MFP/
2K094130 2K094131 SP 8025MFP
4 302K094140 302K094141 PARTS PWB MAIN ASSY 1 1 X O FS-C8020MFP/
2K094140 2K094141 SP EU 8025MFP
Classification Entire stock rework X In-field modification by case No modification necessary
In-field modification at next visit
Field measure When the above mentioned phenomena occur, please replace the Main board with the latest type
(Parts PWB main assy).
Serial numbers of affected machines
Type Item number Serial number
FS-6025MFP 1102L33NL0 N691405534
FS-6025MFP/B 1102L33NL1 N771400544
FS-6030MFP 1102K33NL0 Q6R1401929
FS-C8020MFP 1102KZ3NL0 Q6Y1502412
FS-C8025MFP 1102K03NL0 Q731401741
The above mentioned changes have been applied to machines produced after the above mentioned serial number.
KMIS Service Department, Kyocera Mita Europe Page 1 of 1 B292 / SB 2K3-013
