Image preview - the first page of the document
>> Download SB-5JV-0003-D103 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 5JV-0003 (D103)
June 5, 2013
Firmware Upgrade (Ver.2.1.0)
Subject ib50_v210f_c2.zip
ib51_v210f_c2.zip
Model IB-50, IB-51 l:
Affected models:
IB-50: FS-C8025MFP, FS-C8020MFP, TASKalfa 2550ci, FS-C8650DN, FS-C8600DN, FS-6030MFP, FS-6025MFP, FS-
6025MFP/B, FS-C8525MFP, FS-C8520MFP, FS-6530MFP, FS-6525MFP, FS-C2526MFP/C2626MFP, TASKalfa
5550ci/4550ci/3550ci/3050ci/7550ci/6550ci/8000i/6500i/5500i/4500i/3500i
IB-51: FS-4100DN, FS-4200DN, FS-4300DN, FS-2100D, FS-2100DN, FS-C8650DN, FS-C8600DN,
TASKalfa 5550ci/4550ci/3550ci/3050ci//5500i/4500i/3500i
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please see below.
Serial Nos. of the Affected Machines:
Please distinguish the new item from the old one by checking the label since no serial number is applied.
Topic
The firmware was upgraded to support the Step2 functions and the new model.
Firmware version: 2.1.0
Content of Changes
1. Support of the Step2 functions (main changes)[IB-50]
- Scan to function (Scanner) - COMMAND CENTER support (CCRX link)
- Network authentication - Panel set, etc. (Please refer to the next page.)
2. New model support[IB-50*/IB-51]
- TASKalfa 5550ci/4550ci/3550ci/3050ci/5500i/4500i/3500i
(The main firmware should be also upgraded. Please refer to the service bulletin SB-2LC-0116-D089. FW
PackV5.00) * Only printer function is supported on TASKalfa 7550ci/6550ci/8000i/6500i.
- Next generation models of the above
VER 2.1.0 marked Distinction label added
Master box distinction
Distinction label added Marked VER 2.1.0 Individual box
distinction
*The same label is applied to the B-51 for distinction.
Version Remarks
1 IB50 firmware V2.1.0 New Upgrade
2 IB51 firmware V2.1.0 New Upgrade
IB Version-up
3 IBVERUP v302
Tool
For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
KYOCERA Document Solutions Europe
Customer Services & Support Division (CSSD)
(Page.2/2)
Service Bulletin Ref. No. 5JV-0003 (D103)
June 5, 2013
Supported Functions
Alphard2 Venus1 Gaia1 Venus Printer 6th Printer
TASKalfa TASKalfa TASKalfa FS-C8650DN FS-4100DN
5501i/4501i/3501i 5550ci/4550ci 5500i/4500i/3500i FS-C8600DN FS-4200DN
8001i/6501i 3550ci/3050ci FS-4300DN
5551ci/4551ci FS-2100D
3551ci/3051ci FS-2100DN
7551ci/6551ci
IB-50 Printer YES YES YES YES YES
VER 2.1.0 CCRX link YES YES YES YES YES
Scanner YES YES YES - -
NW authen. YES YES YES YES YES
Panel set YES YES YES YES YES
IB-51 Printer YES YES YES YES YES
VER 2.1.0 CCRX link YES YES YES YES YES
Scanner YES YES YES - -
NW authen. YES YES YES YES YES
Panel set YES YES YES YES YES
Gemini-HyPAS Matsuri-HyPAS Hanabi-HyPAS Jupiter
FS-C2526MFP FS-6530MFP FS-C8525MFP TASKalfa2550ci
FS-C2626MFP FS-6525MFP FS-C8520MFP
IB-50 Printer YES YES YES YES YES: Supported
VER 2.1.0 CCRX link - - - - - : Not supported
Scanner - - - -
NW authen. - - - - Main functions
Panel set - - - - implemented in
IB-51 Printer - - - - Ver.2.1.0:
VER 2.1.0 CCRX link - - - - -CCRX link
Scanner - - - - -Scanner
NW authen. - - - - -NW Authen.
Panel set - - - - -Panel set
Zeus1 Mercury1 Matsuri Hanabi
TASKalfa TASKalfa FS-6030MFP FS-C8025MFP
8000i/6500i 7500ci/6500ci FS-6025MFP FS-C8020MFP
IB-50 Printer YES YES YES YES
VER 2.1.0 CCRX link - - - -
Scanner - - - -
NW authen, - - - -
Panel set - - - -
IB-51 Printer - - - -
VER 2.1.0 CCRX link - - - -
Scanner - - - -
NW authen, - - - -
Panel set - - - -
KYOCERA Document Solutions Europe
Customer Services & Support Division (CSSD)
