Image preview - the first page of the document



>> Download SB-2K3-0008-B084 documenatation <<

Text preview - extract from the document

                                                                                                                            (Page.1/1)

           Service Bulletin                                                               Ref. No.   2K3-0008 (B084)
                                                                                                          March 23, 2011
                  Firmware Upgrade (Upgrade Pack Ver. V1.03) (KTST Support)
  Subject
                  FS-6025MFP_FS-6030MFP_v01.00.0040_(2011-02-07)
  Model           FS-6030MFP, FS-6025MFP, FS-6025MFP/B

Topic
The firmware was upgraded as follows.


Content of Changes

 No. Item                    Details                                                                                     CTL No.   Ver.
  1 KTST support             -----                                                                                        523082   MAIN
                                                                                                                                   MMI
                                                                                                                                   LAN
   2 Change for               -----                                                                                       524213    DP
     production tools




   Type                          Program No.                 Ver.                      Remarks
   Upgrade Pack Ver.             2K3_V1.03E                  1.03
   MAIN                      2K3_2F00.001.504              001.504                                                   New upgrade
   MMI                        2K3_7000.001.500             001.500                                                   New upgrade
   ENGINE                     2K3_1000.004.002             004.002
   LANGUAGE BR               2K3_81BR.001.004              001.004
   LANGUAGE KR               2K3_81KR.001.002              001.002        For KMKR *1
   LANGUAGE CN               2K3_81CN_001.003              001.003        For KTST *1                                New firmware
   IO                        2K3_1E00.001.010              001.010
   DP                        3M8_9500.003.001              003.001                                                   New upgrade
                                                                          BOOT (B01.019),
   FAX BOOT/APL              5JR_5500.B01.019              B01.019
                                                                          APL(B01.019)
   ESPECIAL                      ES_SKIP.ON                ----------

For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade each kind of the firmware (MAIN, ENGINE and MMI) to
the latest version at the same time.

*1: The firmware above is not included in the upgrade pack. Please individually download it from the download center on the
ESDC.net.




 KMC's Classification                   Entire Stock Rework                             In-Field modification at next visit
                                        In-Field modification by case                   No modification necessary
  Field Measure:          No particular problem is expected.

  Serial Nos. of the Affected Machines: Planned from the March 2011* production
                                 * The above is the plan at the present moment. Please note that this information is subject to change.




                                                KYOCERA MITA Europa B.V.
                                       European Service & Development Center (ESDC)
