Image preview - the first page of the document
>> Download SB-2K3-0012-B137 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2K3-0012 (B137)
[Service Information] May 20, 2011
Notes on the Replacement of the Main Board (Handling of
Subject
C0180 Error)
FS-6030MFP, FS-6025MFP, FS-6025MFP/B, FS-C8020MFP,
Model
FS-C8025MFP
Topic
Since no HDD is equipped on the models listed above, some data is saved on the main board instead.
Therefore, the following operations are required when the main board was replaced.
1. Execute the maintenance mode U004 to resolve machine number mismatch which appears after main board was
replaced.
2. Adjust the scanner image.
1) Input the value in the auto scanner adjustment chart in the maintenance mode U425.
2) Execute the maintenance mode U411 by applying the auto scanner adjustment chart.
3) Execute [Halftone adjustment] from the system menu.
3. Reactivate the license for the optional product(s) if any installed.
1) Reactivate the ID CARD AUTHENTICATION KIT B).
2) Register the ID card again in the maintenance mode U222.
4. Import data in the maintenance mode U917 if any was exported from the machine before the main board was
replaced. (The export and import can be also performed via KM-Net Viewer.)
5. Register the initial user settings and FAX settings from the system menu or the Command Center.
6. Execute the maintenance mode as follows if necessary.
No. Main unit related maintenance modes No. Fax related maintenance modes
Checking/clearing the maintenance U603 Setting user data 1
U250
cycle U604 Setting user data 2
Checking/clearing the maintenance U610 Setting system 1
U251
counter U611 Setting system 2
Switching between double and single U612 Setting system 3
U253
counts U615 Setting system 6
U260 Selecting the timing for copy counting U625 Setting the transmission system 1
U326 Setting the black line cleaning indication U695 FAX function customize
Specific paper feed location setting for
U341
printing function
Switching between duplex/simplex copy
U343
mode
Setting the value for maintenance due
U345
indication
U402 Adjusting margins of image printing
Adjusting margins for scanning an
U403
original on the contact glass
Adjusting margins for scanning an
U404
original from the DP
Adjusting the leading edge registration
U407
for memory image printing
U425 Setting the target
U429 Setting the offset for the color balance
U432 Setting the center offset for the exposure
U470 Setting the JPEG compression ratio
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/2)
Service Bulletin Ref. No. 2K3-0012 (B137)
[Service Information] May 20, 2011
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please perform the operations described above when the main board was replaced.
Serial Nos. of the Affected Machines: This is only service information and will not affect the production.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
