Image preview - the first page of the document
>> Download SB-2K3-0013-B149 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2K3-0013 (B149)
June 2, 2011
Firmware Upgrade (Upgrade Pack Ver. V3.00)
Subject
FS-6025MFP_FS-6030MFP_v03.00.0010_(2011-04-14)
Model FS-6030MFP, FS-6025MFP, FS-6025MFP/B
Topic
The firmware was upgraded as follows.
Content of Changes
No. Item Details CTL Ver.
1 Elimination of the A. Related menu is hidden to disable the encryption setting from the operation MAIN
MMI
encrypted FAX panel. LAN
function for China (It is also hidden or disabled on the Command Center and KMNV.)
MAIN firmware
FAX firmware B. Dialing is not processed after on-hook and it is recognized as the 552343 FAX
communications error U04300 [Encrypted transmission failed because the
destination unit had no encrypted communication capability] in case that
(KTST only) transmission was directed with the encryption related setting.
C. When an encrypted message was received, the sender receives the error
U04300/E04300 [Encrypted transmission failed because the destination
unit had no encrypted communication capability] since the receiver cannot
process the encrypted message.
2 Support of the The country code for Russia was added and the settings for Russia are now 541202 FAX
Russian country code supported.
- The default line setting is set to Dial Pulse.
- The line setting menu is displayed for users.
3 Support of the Certain default line setting values were changed to support the Argentina line 552323 FAX
Argentina line type type which was approved.
Type Program No. Ver. Remarks
Upgrade Pack Ver. 2K3_V3.00E 3.00
MAIN 2K3_2F00.003.002 003.002 New upgrade
MMI 2K3_7000.003.002 003.002 New upgrade
ENGINE 2K3_1000.005.002 005.002
LANGUAGE BR 2K3_81BR.001.006 001.006 For KMBR
LANGUAGE KR 2K3_81KR.001.005 001.005 For KMKR *2
LANGUAGE CN 2K3_81CN.001.007 001.007 For KTST *2 New upgrade
LANGUAGE TW 2K3_81TW.001.004 001.004 For KMTW *2
IO 2K3_1E00.001.010 001.010
DP 3M8_9500.003.001 003.001
Except KTST APL(B003.001)
FAX BOOT/APL 5JR_5500.B03.001 B03.001 New upgrade
*1
For KTST APL(Z03.001) *1
FAX BOOT/APL 5JR_5700.B03.001 B03.001 New upgrade
*2
ESPECIAL ES_SKIP.ON ----------
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade each kind of the firmware (MAIN, ENGINE and MMI) to
the latest version at the same time.
*1: BOOT (Z02.001)
*2: The firmware above is not included in the upgrade pack. Please individually download it from the ESDC.net.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/2)
Service Bulletin Ref. No. 2K3-0013 (B149)
June 2, 2011
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: No particular problem is expected.
Serial Nos. of the Affected Machines: Planned from May 2011 production
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
