Image preview - the first page of the document



>> Download SB-2K3-0023-B358 documenatation <<

Text preview - extract from the document

                                                                                                                  (Page.1/1)

           Service Bulletin                                                        Ref. No.   2K3-0023 (B358)
                                                                                               October 17, 2011
          Firmware Upgrade (Upgrade Pack Ver. V4.01)
  Subject (Main: Ver. 004.022, etc.)
                  FS-6025MFP_FS-6030MFP_v04.00.0020_(2011-09-22)
  Model           FS-6030MFP, FS-6025MFP, FS-6025MFP/B

Topic
The firmware was upgraded as follows.


Content of Changes

 No. Item                            Details                                                                         CTL.

  1 Measures against the image       Only approx. 5 mm from the leading edge of image was printed with a           572194
                                                                                                                  NP-Z11045
     dropout with a certain file     certain file when the GDI compatible mode was enabled in the KX driver.
                                     Therefore, this was corrected.
     and when GDI compatible
     mode is ON
  2 Measures against the             The FAX main message remains "Waiting" even if the direct transmission         573538
                                                                                                                    573537
     massage display failure         was cancelled. Therefore, this was corrected so that "Ready to directly
     when cancelling the direct      transmit FAX" will be displayed after cancellation.
     transmission



   Type                         Program No.              Ver.                    Remarks
   Upgrade Pack Ver.             2K3_V4.01E              4.01
   MAIN                      2K3_2F00.004.022          004.022                                            New upgrade
   MMI                       2K3_7000.004.023          004.023                                            New upgrade
   ENGINE                    2K3_1000.006.001          006.001
   LANGUAGE BR               2K3_81BR.001.009          001.009
   LANGUAGE KR               2K3_81KR.001.006          001.006      For KMKR *2
   LANGUAGE CN               2K3_81CN.001.008          001.008      For KTST *2
   LANGUAGE TW               2K3_81TW.001.005          001.005      For KMTW *2
   IO                        2K3_1E00.001.010          001.010
   DP                        3M8_9500.004.001          004.001
   FAX BOOT/APL              5JR_5500.B04.003          B04.003      Except KTST *1    (APL B04.003)
   FAX BOOT/APL              5JR_5700.Z04.002          Z04.002      For KTST *1*2      (APL Z04.002)
   ESPECIAL                     ES_SKIP.ON             ----------
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
*1: BOOT (B02.001)
*2: This firmware is not included in the upgrade pack. Please individually download it from the download center on the
ESDC.net.




 KMC's Classification             Entire Stock Rework                In-Field modification at next visit
                                  In-Field modification by case       No modification necessary
  Field Measure: Please upgrade the firmware when the problem described above arises.

  Serial Nos. of the Affected Machines: Planned from the October 2011* production


                                              KYOCERA MITA Europe B.V.
                                     European Service & Development Center (ESDC)
