Image preview - the first page of the document
>> Download SB-2K3-0024-B432 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2K3-0024 (B432)
December 15, 2011
Subject Measures against the Standard Cassette Withdrawing Failure
FS-6030MFP, FS-6025MFP, FS-6025MFP/B, FS-C8020MFP,
Model
FS-C8025MFP
Topic
If the conditions 1 to 3 below are met, the boss of the paper width cursor supporting point on the backside of the
cassette contacts the machine base edge protection material, which might make difficult to withdraw the cassette.
Therefore, the following was made.
Conditions
1. A3/11x17 size paper is fully loaded in the standard cassette. (No problem occurs with other cassette.)
2. A3/11x17 size paper load is applied for a prolonged time due to low copy volume.
3. The cassette heater is ON.
Content of Changes
A GUIDE was added to the backside of the cassette so that the boss will not contact the base edge protection
material and the cassette can be smoothly withdrawn.
Boss at the cassette backside and Contact with the base
base edge protection material edge protection material
Cassette
withdrawing
direction
Cassette
withdrawing
direction
Boss at the cassette backside
(Paper width cursor support point)
Q'ty Com pati-
Old Part New Part bi lity
No. No. No. Description Remarks
Old New Old New
302K393170 302K393171
1 CT-475 1 1 X O *1
2K393170 2K393171
302K39K170 302K39K171
2 CT-475(KR) 1 1 X O *1
2K39K170 2K39K171
303NN93010 303NN93011
3 CT-476 1 1 X O *2
3NN93010 3NN93011
303NN9K010 303NN9K011
4 CT-476(KR) 1 1 X O *2
3NN9K010 3NN9K011
Set of the
302K394900 + PARTS GUIDE BOTTOM
5 -------- - 1 - O GUIDE/Screw/leaflet
2K394900 CASSETTE ASSY SP
*3
*1: Machine's standard cassette and the first cassette of PF
*2: Second cassette of PF (The cassette other than standard cassette and first PF cassette was also added for common use.)
*3: Please note that the final order for this part may be requested in three years after issue of this service bulletin.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/2)
Service Bulletin Ref. No. 2K3-0024 (B432)
December 15, 2011
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please install the part No.5 to the cassette when the phenomenon described above arises.
Serial Nos. of the Affected Machines: From the November 2011 production
A: GUIDE B: Screw
Cassette backside
- Clean the area where to affix the GUIDE on the cassette
backside with alcohol.
- Peel off the release paper from the double-sided tape on the
GUIDE (marked A above) and affix the GUIDE aligning
to the boss and the screw hole, and fix it with the screw.
(For more details, please refer to the bundled leaflet.)
GUIDE attached on the GUIDE attached and the
cassette backside cassette installed in the
main unit
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
