Image preview - the first page of the document

>> Download SB-2K3-0025-B440 documenatation <<

Text preview - extract from the document

(Page.1/4)

Service Bulletin Ref. No.2K3-0025 (B440)
December 17, 2011
Subject Notes on Replacement of the ISU
FS-6030MFP, FS-6025MFP, FS-6025MFP/B, FS-C8025MFP,
Model
FS-C8020MFP

Topic
Abnormal images such as the samples below and an error at the U411 adjustment might appear when installing the
service parts ISU. In this case, please install the spacer to adjust the height after checking the image. The spacer
and the leaflet are now bundled in the service parts ISU.

Causes
Since the height and/or the warpage of the base to install the ISU slightly vary depending on the machine, the
optical axis might be shifted or interrupted by the reflector. If it is shifted to the optical guide plate, the LED light
might directly enter.

Whitish image partially from Background image Vertical streaks from leading Horizontal white streaks in
the leading edge in the midstream edge of image the midstream of image

Com pati-
Old Part New Part Q'ty bi lity
No. No. No. Description Remarks
Old New Old New
302K393150 302K393152
1 PARTS ISU 1 1 X O B/W machine *1
2K393150 2K393152
302K39K150 302K39K152
2 PARTS ISU (KR) 1 1 X O B/W machine *2
2K39K150 2K39K152
302K093160 302K093162
3 PARTS ISU 1 1 X O Color machine *1
2K093160 2K093162
302K09K160 302K09K162
4 PARTS ISU (KR) 1 1 X O Color machine *2
2K09K160 2K09K162
*1: Except KMKR; *2: For KMKR
The new parts above are including the following additional parts:
POLY SLIDER WASHER 5.1x12x0.2T 2 pcs.
POLY SLIDER WASHER 5.2x16x0.5T 2 pcs.
The leaflet describing how to check the image and how to attach the spacer (LEAFLET1) and the caution leaflet when
connecting the flat cable (LEAFLET2)
1 as the last digit of the part number is for the part with the spacer and the leaflet.
2 as the last digit of the part number is for the part with the caution leaflet when connecting the flat cable (LEAFLET2)
(The part with 1 as the last digit can be converted to the one with 2 as the last digit.)

KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure:
When replacing the ISU, please note the content of this service bulletin and install the bundled spacer if
necessary
Also, please note that the U411 image adjustment is necessary.
Please take care not to apply any load to the board when connecting the wire to the board on the unit.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/4)

Service Bulletin Ref. No.2K3-0025 (B440)
December 17, 2011
*Two leaflets (LEAFLET1, LEAFLET2) were added as informed in this bulletin. Please replace the ISU by
referring to the leaflet.
Serial Nos. of the Affected Machines: As this is a service part, no serial No. information will be
available.

[Notes when connecting the flat cable to replace the ISU]
The caution leaflet (LEAFLET2) is now bundled with the service part ISU describing the contents below
when connecting the flat cable.

*Please apply an earth band as the board will be touched.

1. Hold the flat cable at the point marked (A) to insert it.
2. Tighten the screw after inserting the flat cable.
* Connect the flat cable by following the procedures above so that no load will be applied to the CCD unit.

Flat cable
CCD unit

[Image adjustment after replacing the ISU]
Execute [Table (Chart1)] in the U411 "Adjusting the scanner automatically".

To automatically input target value:
1. Set the test chart (part number: 7505000005) on the scanner table.
2. Enter the maintenance mode U411.
3. Select [Target].
4. Select [Auto] and press the [Start] key.
5. Select [Table].
6. Select [ALL] for item to execute.
7. Press the [Start] key to start the automatic adjustment.
(For more details, please refer to the Service Manual.)

[When executing the above and after]
If an error appears when executing [Table] in the U411 Adjusting the scanner automatically or abnormal images
appear, please adjust it by installing the spacer for the ISU height adjustment after checking the image.
(Please see below.)

KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.3/4)

Service Bulletin Ref. No. 2K3-0025 (B440)
December 17, 2011

Image check 1The caution leaflet (LEAFLET1) is now bundled with the service part ISU for the image
checks 1 and 2 below.

A A
A: Whitish image
partially from the
leading edge

B: Background image in
the midstream

Where to attach the spacers (Against the image A or B above)
Attach the spacer in the ISU screw part on the machine right side.

Shim

Right side Right side

Shim

Attachment of the spacer
1. Against the image like A or B above, install the spacer large (Diameter of 16 mm; thickness of 0.5 mm).
If abnormal image did not disappear, proceed to the next step.
2. Lay the spacer large (Diameter of 16 mm; thickness of 0.5 mm) and the spacer small (Diamenter of 12 mm;
thickness of 0.2 mm) together and insert.
3. Against the image like C or D on the next page, install the spacer small (Diameter of 12 mm; thickness of 0.2
mm).

1 2 3

Image A or B Image A or B Image C or D

KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.4/4)

Service Bulletin Ref. No.2K3-0025 (B440)
December 17, 2011
Image check 2

C C
C: Vertical streaks from
the leading edge of image

D: Horizontal white streaks
in the midstream of image

Attachment of the spacer (Against the image C or D above)
Attach the spacer in the ISU screw part on the machine left side.

Left side

Shim
Attachment of the spacer
1. Against the image like C or D above, install the spacer large (Diameter of 16 mm; thickness of 0.5 mm).
If the abnormal image did not disappear, proceed to the next step.
2. Lay the spacer large (Diameter of 16 mm; thickness of 0.5 mm) and the spacer small (Diamenter of 12 mm;
thickness of 0.2 mm) together and insert.
3. Against the image like A or B on the previous page, attach the spacer small (Diameter of 12 mm; thickness of
0.2 mm).

1 2 3

Image C or D Image C or D Image A or B

KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
