         Service Bulletin                                                  Ref. No.2K3-0030 (C073)
             [Service information]                                                       March 26, 2012
  Subject Abnormal Noise from the Drum Unit
  Model   FS-6025MFP, FS-6025MFP/B, FS-6030MFP

Topic
Some abnormal noise (squeaking sound) may be recognized from the shaft of the ROLLER, MC CLN* and its
bushing.


Handling
Please apply the conductive grease to the point below when the abnormal noise is generated around the main
charger and the drum unit.

                                             *Component of 302K39414_MC-475 and 302K39K14_MC-475(KR)

[Where to apply]
Apply a rice grain size of the conductive grease (GE-334C: P/N A0199040) to the area marked in yellow.




                                                                       *
                                                         ROLLER, MC




                                                         ROLLER, MC CLN*




                                                   Apply a rice grain size of grease here.
                                                   *Make sure not to put it on surroundings!




                                          KYOCERA MITA Europe B.V.
                                 European Service & Development Center (ESDC)
