Image preview - the first page of the document



>> Download SB-2K3-0032-C091 documenatation <<

Text preview - extract from the document

                                                                                                                  (Page.1/1)

          Service Bulletin                                                            Ref. No.2K3-0032 (C091)
                                                                                                  April 9, 2012
          Measures against the Cover Abrasion When Opening and
  Subject
          Closing the DP
          FS-C8020MFP, FS-C8025MFP, FS-6025MFP, FS-6025MFP/B,
  Model
          FS-6030MFP
Topic
The texture density of the cover (No.1 to No.3) was changed from 100% to 20% in order to reduce the cover
abrasion when opening/closing the DP.




                       No.1                                                                     No.2, 3




   Texture density reduced
                                                                                               Texture density reduced




                                                                                         Com pati-
          Old Part       New Part                                          Q'ty            bi lity
  No.       No.            No.                  Description                                                 Remarks
                                                                       Old New           Old New
        302K304130      302K304131
   1                                   COVER ISU LEFT                  1          1       O     O
         2K304130        2K304131
        302K304120      302K304121
   2                                   COVER ISU FRONT                 1          1       O     O      *1
         2K304120        2K304121
        302K004120      302K004121
   3                                   COVER ISU FRONT                 1          1       O     O      *2
         2K004120        2K004121
*1: FS-6025MFP, FS-6025MFP/B, FS-6030MFP
*2: FS-C8020MFP, FS-C8025MFP

*Please use the new parts for the new models.




 KDC's Classification                  Entire Stock Rework                        In-Field modification at next visit
                                       In-Field modification by case               No modification necessary
  Field Measure:
  Please replace the cover with the new type one (No.1 to 3) when it is abraded.

  Serial Nos. of the Affected Machines: After using up the old stock



                                        KYOCERA Document Solutions Europe
                                      Technical Customer Service Division (TCSD)
