Image preview - the first page of the document
>> Download SB-2K3-0036-C210_1 documenatation <<
Text preview - extract from the document
(Revised Issue 1) (Page.1/3)
Service Bulletin Ref. No. 2K3-0036 (C210)
August 22, 2012
Firmware Upgrade (Upgrade Pack Ver. V6.00)
Subject FS-6025MFP_FS-6030MFP_v06.00.0010_(2012-07-04)
FS-C8020MFP_FS-C8025MFP_v06.00.0010_(2012-07-04)
Model FS-6030MFP, FS-6025MFP, FS-6025MFP/B l:
This time, the description with (-->) was revised from the previous information.
Translation was corrected.
Topic
The firmware was upgraded as follows.
Content of Changes
1. Measures against the F356 error
2. Handling of the setting [Send and Forward]
3. Measures against the F515 error
4. Measures against the margin operation failure
5. Measures against the F248 error when using the web driver
6. Correction to German translation
7. Measures against the F124 error when scanning
8. Change of the initial setting of U248 [Setting service status page] for UTAX/TA only
9. Change of the elapse time to enter the drum refresh mode
10. Display change of the black line cleaning guidance
11. Measures against the C1030 service call error [PF lift motor 2 error]
Type Program No. VER. Remarks
Upgrade Pack Ver. 2K3_V6.00E 6.00
2K3_2F00.005.020
MAIN 006.004 New upgrade
->2K3_2F00.006.004
MMI 2K3_7000.005.016 005.016
ENGINE 2K3_1000.008.012 008.012 New upgrade
LANGUAGE BR 2K3_81BR.001.012 001.012
LANGUAGE KR 2K3_81KR.001.010 001.010 For KDKR *1
LANGUAGE CN 2K3_81CN.001.011 001.011 For KDCN *1
LANGUAGE TW 2K3_81TW.001.009 001.009 For KDTW *1
IO 2K3_1E00.001.010 001.010
DP 3M8_9500.005.001 005.001 New upgrade
Refer to the enhance pack. *2 New upgrade
Refer to the enhance pack. *2 New upgrade
ESPECIAL ES_SKIP.ON ----------
For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware (MAIN, ENGINE, MMI) to the
latest version at the same time.
*1: This firmware is not included in the upgrade pack. Please individually download it at the download center.
*2: The upgrade pack for the enhancement unit has been informed by the service bulletin SB-2K3-0035-C199 which is the
latest one as of August 8, 2012. However, please check the latest service bulletin since the upgrade pack version may be
upgraded again. (It will be informed per as 2K3-****.)
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Revised Issue 1) (Page.2/3)
Service Bulletin Ref. No. 2K3-0036 (C210)
August 22, 2012
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the phenomenon described above occurs.
Serial Nos. of the Affected Machines: From the July 2012 production
Content of Changes
No. Item Details CTL
MAIN firmware ver.005.020
Change at production line The command for checking the board was changed in order to improve the 639435
productivity.
MAIN firmware ver.006.004
1 Measures against the F356 The F356 system error might appear after completing transmission of network 634157
error fax with simultaneous print function from the network user. Therefore, this was
corrected.
2 Handling of the setting [Send The destination of [Send and Forward] might be indicated on the status of 624974
transmission job when [Send and Forward] was set. Therefore, this was 662105
and forward]
corrected so that they will not be indicated.
3 Measures against the F515 The F515 system error might appear if the start key was pressed 589400
error immediately after setting the A3 size original on the DP when the combine 4
in 1 and A5 size paper were selected. Therefore, this was corrected.
(This error appears when misalignment occurs depending on the detection
timing of original size.)
4 Measures against the "Margin" "Margin" in copy function did not function if "Auto Image Rotation" was set to TO-11-092
616408
operation failure "OFF". Therefore, this was corrected.
5 Measures against the F248 The F248 error might appear when performing a print job after setting the TP-11-040
machine not by the auto recognition of the installing model, but by inputting KMA-
error when using the web CID472368
the IP address using the web driver (UPD: Universal Printing Driver).
driver
Therefore, this was corrected.
6 Correction to German The following strings in German were corrected. TO-12-046
TA-S12-018
translation - (Wrong) "Install" --> (Correct) "Installiert"
- (Wrong) "Keine Anwort" --> (Correct) "Keine Antwort"
