Image preview - the first page of the document
>> Download SB-2MW-0003-C164_1 documenatation <<
Text preview - extract from the document
(Revised Issue 1) (Page.1/2)
Service Bulletin Ref. No. 2MW-0003 (C164)
October 17, 2012
Subject Firmware Upgrade (Upgrade Pack Ver. V2.00)
FS-6525MFP_FS-6530MFP_v.02.00.0010_(2012-05-21)
Model FS-6530MFP, FS-6525MFP l:
This time, the description with (-->) was revised from the previous information.
The accurate serial numbers were added.
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measures:
Please upgrade the firmware when the phenomenon described below occurs.
Topic
The firmware was upgraded as follows.
Content of Changes
No. Item Details CTL
1 Support for the Cloud connect ----------------- MAIN
MMI
LAN
Type Program No. Ver. Remarks
Upgrade Pack Ver. 2MW_V2.00E
MAIN 2MW_2F00.002.006 002.006 New Upgrade
MMI 2MY_7000.001.113 001.113 New Upgrade
ENGINE 2K3_1000.008.012 008.012
LANGUAGE BR 2MY_81BR.001.009 001.009 New Upgrade
LANGUAGE CN 2MY_81CN.001.002 001.002 For KDCN *1
LANGUAGE KR 2MY_81KR.001.001 001.001 For KDKR *1
LANGUAGE TW 2MY_81TW.001.001 001.001 For KDTW *1
BROWSER 2M8_F000.001.002 001.002
IO 2K3_1E00.001.010 001.010
DP 3M8_9500.005.001 005.001
ESPECIAL ES_SKIP.ON ----------
For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware (MAIN, ENGINE, MMI) to the latest
version at the same time.
*1: This firmware is not included in the upgrade pack. Please individually download it at the download center.
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Revised Issue 1) (Page.2/2)
Service Bulletin Ref. No. 2MW-0003 (C164)
October 17, 2012
(-->) Serial Nos. of the Affected Machines
FS-6530MFP
KDA KDA (GSA) KDA 220V KDBR KDE Olivetti RYAD
1102MW2US0 1102MW2US1 1102MW4US0 1102MW2BR0 1102MW3NL0 1102MW3LV0 1102MW3RY0
NWV2600090 L4S2800001 NXG2700001 NXL2600001 NWX2600377 L442900001 L7A2700001
UTAX KDAU KDID KDSG KDTH KDCN KDTW
1102MW3UT0 1102MW3AS0 1102MW3ND0 1102MW3SG0 1102MW3TH0 1102MW3KS0 1102MWTTW0
L2F2600081 NWW2600023 L2R2700016 L2S2600001 L2T2900029 L2Q2800001 L2U2900001
FS-6525MFP
KDA KDA 220V KDBR KDE Olivetti RYAD UTAX
1102MX2US0 1102MX4US0 1102MX2BR0 1102MX3NL0 1102MX3LV0 1102MX3RY0 1102MX3UT0
NWZ2600768 NXH2500001 NXM2700001 NX42601588 L452500001 L6Y2700001 L2G2500355
KDAU KDSG KDTH KDID KDCN KDTW KDKR
1102MX3AS0 1102MX3SG0 1102MX3TH0 1102MX3ND0 1102MX3KS0 1102MXTTW0 1102MX3KR0
NX22500038 L282600001 L2Y2500001 L2X2600063 L2W2800001 L2Z2900001 L2V2800001
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
