Image preview - the first page of the document
>> Download SB-PCI-0295-B204_ESDC documenatation <<
Text preview - extract from the document
(Page.1/6)
Service Bulletin Ref. No. PCI-0295 (B204)
[Parts Change Information June 22, 2011
Subject Part Change information
TASKalfa5550ci, TASKalfa4550ci, TASKalfa3550ci,
TASKalfa3050ci, TASKalfa5500i, TASKalfa4500i,
TASKalfa3500i, TASKalfa8000i, TASKalfa6500i,
FS-6025MFP, FS-6025MFP/B, FS-6030MFP, FS-C8025MFP,
Model FS-C8020MFP, TASKalfa550c, TASKalfa650c, TASKalfa750c,
TASKalfa180, TASKalfa220, TASKalfa181, TASKalfa221,
KM-1620, KM-2020, KM-1650, KM-2050, KM-2550, KM-1635,
KM-2035, KM-2530, KM-3530, KM-4030, FS-9100DN,
FS-9500DN, PF-410, PF-420
Affected models:
PF-410 KM-1620/2020/1650/2050/2550/1635/2035/1635CHN/2035CHN/1648
PF-420 TASKalfa180/220/181/221
Topic
The following parts were changed.
P2
TASKalfa5550ci, TASKalfa4550ci, TASKalfa3550ci, TASKalfa3050ci
P2
TASKalfa5550ci, TASKalfa4550ci, TASKalfa3550ci, TASKalfa3050ci
P3
TASKalfa5550ci, TASKalfa4550ci, TASKalfa3550ci, TASKalfa3050ci
P3
TASKalfa5500i, TASKalfa4500i, TASKalfa3500i
P4
TASKalfa5500i, TASKalfa4500i, TASKalfa3500i
P4
TASKalfa5500i, TASKalfa4500i, TASKalfa3500i, TASKalfa8000i, TASKalfa6500i
P4
TASKalfa8000i, TASKalfa6500i
P5
TASKalfa8000i, TASKalfa6500i
P5
FS-6030MFP, FS-6025MFP, FS-6025MFP/B,
FS-C8025MFP, FS-C8020MFP
P6
TASKalfa550c, TASKalfa650c, TASKalfa750c
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/6)
Service Bulletin Ref. No. PCI-0295 (B204)
[Parts Change Information June 22, 2011
P6
TASKalfa180, TASKalfa220, TASKalfa181, TASKalfa221, KM-1620, KM-2020, KM-1650,
KM-2050, KM-2550, KM-1635, KM-2035,
KM-2530, KM-3530, KM-4030, FS-9100DN, FS-9500DN, PF-410, PF-420
TASKalfa5550ci, TASKalfa4550ci, TASKalfa3550ci, TASKalfa3050ci
The following part (No.1) was changed for common use with other models.
Duct added for cooling air
No.1
Com pati-
Q'ty
No. Old Part New Part Description bility Remarks
No. No.
Old New Old New
302LC04220 302LF04071
1 COVER REAR UPPER 1 1 O O
2LC04220 2LF04071
TASKalfa5550ci, TASKalfa4550ci, TASKalfa3550ci, TASKalfa3050ci, TASKalfa7550ci,
TASKalfa6550ci
1) Names of the LK unit were changed as follows.
Affected Models Fig. Ref. Part No. Old Part New Part Remarks
Name Name
302LC93061
TASKalfa5550ci/4550ci/3550ci (Colro/BK) 11 6 2LC93061 LK-8505 LK-8705 Changed
302LK93050
TASKalfa3050ci (Color/BK) 11 6 LK-8305 LK-8305
2LK93050
302LC93061
TASKalfa7550ci (Color) /6550ci (Color/BK) 16 6 LK-8505 LK-8705 Changed
2LC93061
302K993190
TASKlafa7550ci (BK) 16 7 LK-8705 LK-8706 Changed
2K993190
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.3/6)
Service Bulletin Ref. No. PCI-0295 (B204)
[Parts Change Information June 22, 2011
2) The following part number was changed for common use between TASKalfa7550ci and 6550ci.
Com pati-
Q'ty
No. Old Part New Part Description bility Remarks
No. No.
Old New Old New
*1
302LC93060 302LC93061
1 LK-8705 4 4 O O Old name:
2LC93060 2LC93061
LK-8505
302LC9K060 302LC9K061 *1
2 LK-8705(KR) 4 4 O O
2LC9K060 2LC9K061 (For KMKR)
*1: Affected models: TASKalfa5550ci/4550ci/3550ci, TASKalfa7550ci(Color LK)/6550ci(Color/Bk LK)
Please use the new parts for the TASKalfa7550ci/6550ci.
TASKalfa5550ci, TASKalfa4550ci, TASKalfa3550ci, TASKalfa3050ci
The following part (No.1) was changed for common use with other models.
Com pati-
Old Part New Part Q'ty bility
No. Description Remarks
No. No.
Old New Old New
302LC93170 302K993060
1 MC-8705 4 4 O O
2LC93170 2K993060
TASKalfa5500i, TASKalfa4500i, TASKalfa3500i
The following parts were changed since the first mass production.
FIG. 17 Exit Section
No.2 No.1
Com pati-
Q'ty
No. Old Part New Part Description bility Remarks
No. No.
Old New Old New
302LH94290
1 ---------- PARTS ROLLER EXIT SP - 1 - O
2LH94290
1 of 2 was
302LC94350 302LC94350
2 PARTS ROLLER EXIT SP 2 1 X - changed to
2LC94350 2LC94350
No.1
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.4/6)
Service Bulletin Ref. No. PCI-0295 (B204)
[Parts Change Information June 22, 2011
TASKalfa5500i, TASKalfa4500i, TASKalfa3500i
The following parts were changed since the first mass production.
Com pati-
Old Part New Part Q'ty bility
No. Description Remarks
No. No.
Old New Old New
302LK93070 302LH93070
1 PARTS STORAGE DEVICE SP 1 1 X O
2LK93070 2LH93070
302LK9K070 302LH9K070
2 PARTS STORAGE DEVICE SP(KR) 1 1 X O KMKR spec
2LK9K070 2LH9K070
TASKalfa5500i, TASKalfa4500i, TASKalfa3500i, TASKalfa8000i, TASKalfa6500i
A part number was set up for the filter attached to the inner unit.
The part is supplied with the cover attached.
No2 Inner unit No1
Com pati-
Old Part New Part Q'ty bility
No. Description Remarks
No. No.
Old New Old New
302LF94310
1 ------- PARTS FILTER DRUM SP - 1 - O
2LF94310
302LF94320
2 ------- PARTS FILTER DLP SP - 1 - O
2LF94320
TASKalfa8000i, TASKalfa6500i
The following parts were changed since the first mass production.
Com pati-
Old Part New Part Q'ty bility
No. Description Remarks
No. No.
Old New Old New
1 2BC06510 28107310 BUSH 8 6 6 X O
302K324450
2 3CY07080 BUSH 6 * * X O
2K324450
*All Qty. to be used
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.5/6)
Service Bulletin Ref. No. PCI-0295 (B204)
[Parts Change Information June 22, 2011
TASKalfa8000i, TASKalfa6500i
The exit roller was changed for common use with other models.
FIG. 22 Exit Section
No.2 No.1
Com pati-
Old Part New Part Q'ty bility
No. Description Remarks
No. No.
Old New Old New
302K994A40
1 ---------- PARTS ROLLER EXIT B SP - 1 - O
2K994A40
1 of 2 was
302K994910 302K994910
2 PARTS ROLLER EXIT SP 2 1 O - changed to
2K994910 2K994910
No.1
FS-6030MFP, FS-6025MFP, FS-6025MFP/B,
FS-C8025MFP, FS-C8020MFP
The following part was registered as a service part.
No.1
PART ISU
Com pati-
Old Part New Part Q'ty bility
No. Description Remarks
No. No.
Old New Old New
302H044110
1 ---------- SENSOR ORIGINAL - 1 - O
2H044110
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.6/6)
Service Bulletin Ref. No. PCI-0295 (B204)
[Parts Change Information June 22, 2011
TASKalfa550c, TASKalfa650c, TASKalfa750c
The part number was set up for the following part.
FIG. 77 RADF-FEED-6-ASM
No.1
No.1
Com pati-
Old Part New Part Q'tybility
No. Description Remarks
No. No.
Old New Old New
305JN72R90
1 ---------- LEVER:LEV-READ-IN - 2 - O
5JN72R90
TASKalfa180, TASKalfa220, TASKalfa181, TASKalfa221, KM-1620, KM-2020, KM-1650,
KM-2050,KM-2550, KM-1635, KM-2035, KM-1635CHN, KM-2035CHN, KM-1648, KM-2530/2531,
KM-3530/3531, KM-4030/4031, FS-9100DN, FS-9500DN, PF-410, PF-420
The pick-up roller (No.1) was changed as follows due to the difficulty with material procurement.
Material: (Old) MUPS-2 (New) EPDM
Com pati-
Old Part New Part Q'tybility
No. Description Remarks
No. No.
Old New Old New
1 2AR07240 2BJ06010 PULLEY FEED A * * O O
*All qty. to be used for each model
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
