Image preview - the first page of the document
>> Download SB-PCI-0302-B329_ESDC documenatation <<
Text preview - extract from the document
(Page.1/3)
Service Bulletin Ref. No. PCI-0302 (B329)
[Parts Change Information] October 17, 2011
Subject Part Change Information
TASKalfa 5550ci, TASKalfa 4550ci, TASKalfa 3550ci,
TASKalfa 3050ci, TASKalfa 5500i, TASKalfa 4500i,
TASKalfa 3500i TASKalfa 8000i, TASKalfa 6500i,
Model
TASKalfa 7550ci, TASKalfa 6550ci, FS-6025MFP,
FS-6025MFP/B, FS-6030MFP, FS-C8020MFP, FS-8025MFP,
DF-790
Affected models:
DF-790 TASKalfa 5550ci/4550ci/3550ci/3050ci, TASKalfa 5500i/4500i/3500i, TASKlafa 8000i/6500i and TASKalfa 7550ci/6550ci
Topic
The following parts were changed.
P1
TASKalfa 5550ci, TASKalfa 4550ci, TASKalfa 3550ci, TASKalfa 3050ci, TASKalfa 8000i,
TASKalfa 6500i, TASKalfa 7550ci, TASKalfa 6550ci, FS-C8020MFP, FS-8025MFP
P2 <(DP section) Part number information>
FS-6025MFP, FS-6025MFP/B, FS-6030MFP,
FS-C8020MFP, FS-C8025MFP
P3
DF-790
TASKalfa 5550ci, TASKalfa 4550ci, TASKalfa 3550ci, TASKalfa 3050ci, TASKalfa 8000i,
TASKalfa 6500i, TASKalfa 7550ci, TASKalfa 6550ci, FS-C8020MFP, FS-8025MFP
The part names listed in the Parts Lists were corrected as follows.
[Wrong] [Correct]
Model Fig. Ref. Part No. Part name Part name
TASKalfa 7550ci/6550ci 20 302K993140
2 FK-8708 FK-8708 IH
TASKalfa 8000i/6500i 18 2K993140
TASKalfa 7550ci/6550ci 20 302K993150
2 FK-8709 FK-8709 IH
TASKalfa 8000i/6500i 18 2K993150
302K99K150
TASKalfa 8000i/6500i 18 2 FK-8709(KR) FK-8709 IH(KR)
2K99K150
TASKalfa255c/FS-C8025MFP
13 1
TAKSalfa205c/FS-C8020MFP 302LC93080
FK-8506 FK-8506 IH
TASKalfa 5550ci/4550ci/3550ci 2LC93080
16 2
/3050ci
