Image preview - the first page of the document
>> Download SB-2MW-0003-C164 documenatation <<
Text preview - extract from the document
(Page.1/1)
Service Bulletin Ref. No. 2MW-0003 (C164)
June 21, 2012
Firmware Upgrade (Upgrade Pack Ver. V2.00)
Subject
FS-6525MFP_FS-6530MFP_v.02.00.0010_(2012-05-21)
Model FS-6530MFP, FS-6525MFP
Topic
The firmware was upgraded as follows.
Content of Changes
No. Item Details CTL
1 Support for the Cloud connect ----------------- MAIN
MMI
LAN
Type Program No. Ver. Remarks
Upgrade Pack Ver. 2MW_V2.00E
MAIN 2MW_2F00.002.006 002.006 New Upgrade
MMI 2MY_7000.001.113 001.113 New Upgrade
ENGINE 2K3_1000.008.012 008.012
LANGUAGE BR 2MY_81BR.001.009 001.009 New Upgrade
LANGUAGE CN 2MY_81CN.001.002 001.002 For KDCN *1
LANGUAGE KR 2MY_81KR.001.001 001.001 For KDKR *1
LANGUAGE TW 2MY_81TW.001.001 001.001 For KDTW *1
BROWSER 2M8_F000.001.002 001.002
IO 2K3_1E00.001.010 001.010
DP 3M8_9500.005.001 005.001
ESPECIAL ES_SKIP.ON ----------
For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware (MAIN, ENGINE, MMI) to the latest
version at the same time.
*1: This firmware is not included in the upgrade pack. Please individually download it at the download center.
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure:
Please upgrade the firmware when the phenomenon described above occurs.
Serial Nos. of the Affected Machines: Planned from the available timing in the June 2012* production
* The above is the plan at the present moment. Please note that this information is subject to change.
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
