Image preview - the first page of the document

>> Download SB-2MW-0004-C227 documenatation <<

Text preview - extract from the document

(Page.1/2)

Service Bulletin Ref. No. 2MW-0004 (C227)
August 23, 2012

Subject Firmware Upgrade (Upgrade Pack Ver.V3.00)
FS-6525MFP_FS-6530MFP_v.03.00.0010_(2012-08-01)
Model FS-6530MFP, FS-6525MFP l:

Topic
The firmware was upgraded as follows.

Content of Changes

1. Measures against the unavailable port specified with the HyPAS application

2. Change of the initial setting in the U285 [Setting service status page] for TA/UTAX only
3. New route certificate for Cloud Connect
4. Correction to German translation
5. Handling of the setting [Send and Forward]
6. Measures against the print failure when continuously printing using the KX Driver
7. Measures against the F245 system error when receiving a certain mail
8. Measures against the output failure of the file for which the number of copies was specified with AS400
9. Measures against the indication failure of the cassettes (500x2) on the status page
[In case if Korea/Taiwan/China are set as the destination and language]
(For more details, please refer to next page.)

Type Program No. Ver. Remarks
Upgrade Pack Ver. 2MW_V3.00E
2MW_2F00.002.007
MAIN -> 003.007 003.007 *2 New Upgrade
MMI 2MY_7000.003.005 003.005 New Upgrade
ENGINE 2K3_1000.008.012 008.012
LANGUAGE BR 2MY_81BR.001.012 001.012 New Upgrade
LANGUAGE CN 2MY_81CN.001.006 001.006 For KDCN *1 *2 New Upgrade
LANGUAGE KR 2MY_81KR.001.005 001.005 For KDKR *1 *2 New Upgrade
LANGUAGE TW 2MY_81TW.001.005 001.005 For KDTW *1 *2 New Upgrade
BROWSER 2M8_F000.001.002 001.002
IO 2K3_1E00.001.010 001.010
DP 3M8_9500.005.001 005.001
ESPECIAL ES_SKIP.ON ----------

For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware (MAIN, ENGINE, MMI) to the latest
version at the same time.

*1: This firmware is not included in the upgrade pack. Please individually download it from the download center.
*2: Under the following NG firmware combination, the F245 system error appears if outputting the status page with affected
language set. Please use each firmware with the combination of the latest firmware after this version.
NG combination: New MAIN firmware (003.007 or later) <-> Old LANGUAGE firmware (BR: Older than Ver.001.012; CN: Older
than Ver.001.006; KR/TW: Older than Ver.001.005)

(*) The upgrade pack for the enhancement unit has been informed by the service bulletin SB-2K3-0035-C199. (The latest
ENHANCE Pack Version is V1.1 as of August 22, 2012.) However, please check the latest service bulletin because the
upgrade pack version may be upgraded afterwards. (It will be informed by service bulletin with SB-2K3-****.)

KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.2/2)

Service Bulletin Ref. No. 2MW-0004 (C227)
August 23, 2012

KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the phenomenon described above occurs.

Serial Nos. of the Affected Machines: Planned from the August 2012* production
* The above is the plan at the present moment. Please note that this information is subject to change.

Content of Changes

No. Item Details CTL

MAIN: 2MW_2F00.002.007
1 Measures against the unavailable The port number usable with HyPAS application was 1-32767. Therefore, 645160
TO-12-090
port specified with the HyPAS this was corrected to 1-49150.
application
Firmware upgrade this time
2 Change of the initial setting in the The initial setting in the U285 was changed from OFF to ON for TA/UTAX 662209

U285 [Setting service status page] only. Due to this change, the print coverage data will be indicated on the
for TA/UTAX only service status page.
3 New route certificate for Cloud ---------- 662556

Connect
4 Correction to German translation The following strings in German were corrected. 629784
TO-12-046,
- (Wrong) "Install" --> (Correct) "Installiert" TA-S12-018
- (Wrong) "Keine Anwort" --> (Correct) "Keine Antwort"
- (Wrong) "Universalzuf
