Image preview - the first page of the document



>> Download SB-2J5-0022-C329 documenatation <<

Text preview - extract from the document

                                                                                                                    (Page.1/1)

            Service Bulletin                                                          Ref. No.   2J5-0022 (C329)
                                                                                                 December 10, 2012
                   Firmware Upgrade (Main Firmware Ver. 006.006)
  Subject
                   FS-6970DN_06.00.0020_(2012-10-02)
  Model            FS-6970DN                                                                                            l:

 KDC's Classification                Entire Stock Rework                      In-Field modification at next visit
                                     In-Field modification by case            No modification necessary
  Field Measure:
  Please upgrade the firmware to the latest version when the phenomenon described below occurs.


Topic
The main firmware was upgraded as follows.


Content of Changes
   No.                Item                                              Details                                 CTL     FW
   1   Measures against the notice           The maintenance kit replacement request might not be notified     668910   MAIN

       failure of the maintenance kit        via KYOCERA NetViewer. Therefore, this was corrected.
       replacement on KYOCERA
       NetViewer




                                        Check                    Status       Current
     Type         Program No.                        Ver.                                    Remark
                                         SUM                      Date          Ver.
  MAIN          2J5_3000006006            -        006.006      2012/10/2     006.004                         New Upgrade
  ENGINE        2J5_1000008001          05C3       008.001          -            -

For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.




Serial Nos. of the Affected Machines
                    Item Code           Serial Number
  KDE               1102J53EU0          From XAA2X13738
  KDAO              1102J53AS0          From XMU2X00625
  KDID              1102J53ND0          From the next production
  KDHG/KDTH         1102J53TH0          From XDC2X00294
  KDTW              1102J5TTW0          From the next production
  KDCN              1102J53KS0          From the next production




                                           KYOCERA Document Solutions Europe
                                         Techncial Customer Service Division (TCSD)
