          Service Bulletin                                                             Ref. No.   5H2-0002 (C141)
                                                                                                         May 29, 2012
  Subject Measure against Coming-off of the Motor Connector
  Model   PF-430
(Installation target models of PF-430: FS-6950DN and FS-6970DN)

Topic
The bundling clamp was added in order to prevent the motor connector from coming off and to improve the
assembly work proficiency.


Content of Changes
1. The bundling clamp was added.

                  (Before)                                         (After) Bundling clamp added









2. The hole to insert the bundling clamp into the bracket was added.




                                                                                Q'ty       Com pati-
         Old Part        New Part                                                            bi lity
  No.      No.             No.                     Description                                                Remarks
                                                                           Old New         Old New
                        305H280A40
   1     ------------                  RSG-100                              -          1     -      X
                          5H280A40
* The part No. of the bracket (305H2802_) remains unchanged.


 KMC's Classification                      Entire Stock Rework                     In-Field modification at next visit
                                           In-Field modification by case           No modification necessary
  Field Measure:             No particular problem is expected.

  Serial Nos. of the Affected Machines: All specs. except KDCN/KDKR: From GPT2420631
