Image preview - the first page of the document
>> Download 2H9-009 documenatation <<
Text preview - extract from the document
Service Bulletin
SB Number: SB 2H9-009 Creation Date: 30/09/2010
Subject: Vertical black streak on the left edge of the print-out
Model: FS-1028MFP/1128MFP
Phenomenon The vertical black streak may appear 1-2mm from the left edge of the print-out.
Cause Light from the laser scanner unit is reflected by the shutter spring at the drum unit.
Solution The shape of the seal drum frame on the left side of the frame drum has been changed to
seal drum frame B to prevent the light reflection from the shutter spring.
The seal drum frame B is a component part of the drum and is not available as a individual part.
Parts
No. Old Parts New Parts Description Q'TY Interchange- SP Applicable Models
No. No. ability
Old New Old New
1 302H493010 302H493011 DK-150 O O 1 1 O FS-1028MFP/1128MFP
2H493010 2H493011
Classification Entire stock rework X In-field modification by case No modification necessary
In-field modification at next visit
Field measure Please affix black insulation tape to the seal drum frame so that the width becomes 24.5mm.
Serial numbers of affected machines Serial numbers of affected units
Type Serial number Type Serial number
FS-1028MFP/1128MFP August 2010 production. DK-150 WJD0838728
Machines produced after the above mentioned Units produced after the above mentioned serial
production date, should not have the above mentioned numbers, should not have the above mentioned
phenomena. phenomena.
KMIS Service Department, Kyocera Mita Europe Page 1 of 2 A311 / SB 2H9-009
Service Bulletin
Frame drum (DK-130)
Seal drum frame
Old condition: Seal New condition: Seal Field measure: Seal drum
drum frame drum frame frame
Old Seal drum frame
16mm
Black insulation tape
16mm 24.5mm 24.5mm
Affix black insulation tape
to the old seal drum frame
so that the width is 24.5mm
KMIS Service Department, Kyocera Mita Europe Page 2 of 2 A311 / SB 2H9-009
