Image preview - the first page of the document



>> Download 2H9-017 documenatation <<

Text preview - extract from the document

                                      Service Bulletin
 SB Number: SB 2H9-017                                                               Creation Date: 08/06/2011
 Subject:            Firmware upgrade (Scanner v004.001/Fax Boot APL v006.001)
 Model:              FS-1028MFP/1128MFP



    Item                            Contents
1   Solenoid motion failure         The DP reverse solenoid may not be released after completing the duplex scanning
2   Added country code              The Russian country code has been added.




Firmware
Type                        Program No.                Check SUM Version              Status Date   Applicable model(s)
ENGINE                      2H9_1000.005.001           3eaf                005.001    29/11/2010    FS-1028MFP/1128MFP
MAIN                        2H9_2F00.023.001           ----                023.001    ----------    FS-1028MFP
MAIN                        2JN_2F00.023.001           ----                023.001    ----------    FS-1128MFP
SCANNER                     2H9_1200.004.001           ----                004.001    ----------    FS-1028MFP/1128MFP
FAX BOOT/APL (*)            2H9_5500.006.001           ----                006.001    ----------    FS-1128MFP
Note: Combined Boot and APL firmware




Classification      Entire stock rework                       X In-field modification by case No modification necessary
                                             In-field modification at next visit
Field measure     When the above mentioned phenomenon occurs, please upgrade the firmware to the latest
                  version.




Serial numbers of affected machines
Type                                                                Serial number
 FS-1028MFP/1128MFP                                   April 2011 production
The above mentioned changes have been applied to machines produced after the above mentioned production date.




KMIS Service Department, Kyocera Mita Europe                        Page 1 of 1                             B142 / SB 2H9-017
