Image preview - the first page of the document
>> Download SB-2H9-0028-B142 documenatation <<
Text preview - extract from the document
(Page.1/1)
Service Bulletin Ref. No. 2H9-0028 (B142)
May 31, 2011
Firmware Upgrade (Scanner : Ver.004.001)
Subject (FAX : Ver.006.001 --- Except KTST)
FS-1x28MFP_02.00.0070_(2011-04-11)
Model FS-1028MFP, FS-1128MFP
Topic
The firmware was upgraded as follows.
Contents of Changes
Item Details CTL. No. FW
1 Measures against the The DP reverse solenoid might not be released after duplex 538810 SCN
solenoid motion failure scanning was completed. Therefore, this was corrected.
2 Support for Russia Russian country code was added. 541200 FAX
Program No. Check Ver. Status Current Remark
SUM Date Ver.
ENGINE 2H9_1000.005.001 3eaf 005.001 2010/11/29 - -
MAIN 2H9_2F00.023.001 - 023.001 - 022.009 FS-1028MFP
MAIN 2JN_2F00.023.001 - 023.001 - 022.009 FS-1128MFP
<--New
SCANNER 2H9_1200.004.001 - 004.001 2011/2/22 003.001 upgrade
Optional 2H9_81KR.001.00
- 001.004 - - Korean (For KMKR)
language 4
Optional 2H9_81CN.001.00 Simplified Chinese
- 001.005 - -
language 5 (For KTST)
Optional 2H9_81BR.001.00 Brazilian Portuguese
- 001.008 - -
language 8 (For KMBR)
Except
Combined firmware KTST
FAX BOOT/APL 2H9_5500.006.001 - 006.001 - 003.003
of BOOT and APL <--New
upgrade
2H9_5700.N05.00 Combined firmware
FAX BOOT/APL - N05.001 - N04.002
3 of BOOT and APL
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade each kind of the firmware to the latest version at the same
time.
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the phenomenon described above occurs.
In case that characters are garbled, please use the optional language supporting the
firmware.
Serial Nos. of the Affected Machines: SCANNER: Planned from April 2011* production
FAX: Planned from May 2011* production
*The above is the plan at present and this is subject to change.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
