Image preview - the first page of the document
>> Download SB-2H9-0029-B335 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2H9-0029 (B335)
October 27, 2011
Firmware Upgrade (Main: Ver.024.005, FAX: 007.002)
Subject
FS-1x28MFP_02.00.0090_(2011-08-20)
Model FS-1028MFP, FS-1128MFP
Topic
The firmware was upgraded as follows.
Content of Changes
No. Item Details Ctl No. FW
Measures against the PDF direct 569714 MAIN
1 ----------------------- TP-10-019
print failure with a certain PDF file NP-Z10006
TP-090229, MAIN
2 Measures against the KPDL error The KDPL error occurred when directly printing a LWIK-12379
certain PDF file from a USB memory in duplex mode.
Therefore, this was corrected.
556269 FAX
3 Support for Mexico The Mexican country code was added.
Program No. Check Ver. Status Current Remark
SUM Date Ver.
ENGINE 2H9_1000005001 3eaf 005.001 2010/11/29 - -
New
MAIN 2H9_2F00024005 - 024.005 2011/8/20 023.001 FS-1028MFP upgrade
New
MAIN 2JN_2F00024005 - 024.005 2011/8/20 023.001 FS-1128MFP upgrade
SCANNER 2H9_1200004001 - 004.001 2011/2/22 -
Optional language Korean
2H9_81KR001004 - 001.004 - -
KR (for KMKR)
Optional language Simplified Chinese
2H9_81CN001005 - 001.005 - -
CN (for KTST)
Optional language Brazilian Portuguese
2H9_81BR001008 - 001.008 - -
BR (for KMBR)
New
FAX BOOT/APL 2H9_5500007002 - 007.002 - 006.001 Except KTST
upgrade
FAX BOOT/APL 2H9_5700N05001 - N05.001 - - For KTST
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the problem described above arises.
Serial Nos. of the Affected Machines: From the available timing in the September 2011* production
*The above is the plan at the present moment. Please note that this information is subject to change.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/2)
Service Bulletin Ref. No. 2H9-0029 (B335)
October 27, 2011
Content of Changes
No. Item Details Ctl No. FW
DDNS registration failure DDNS could not be registered In the DHCP environment. TC-10-038 MAIN
4
Therefore, this was corrected
510299 MAIN
5 Measures against the The F000 error appeared with a certain PS data. Therefore, TP-10-232,
F000 error with a PS data this was corrected. #1115873
548199 MAIN
6 SEM command failure when ---------------------- TP-10-248:
KPDL (auto) is set NP-Z10078
TP-090393 MAIN
7 Measures against the print Print position was shifted with a certain file. Therefore, this NP-Z09091
position shifts with a certain was corrected.
file
TP-10-164, MAIN
8 Measures against the duplex Upper part of the image on the second side was not printed NP-Z10059
print failure with a certain file when printing a certain file in duplex. Therefore, this was
corrected.
551597 MAIN
9 Measures against the charge The charge counter was reset to 0 when the original TC-11-005
counter reset EEPROM was attached after replacement of the main
board. Therefore, this was corrected.
553795 MAIN
10 Measures against the missing --------------------- TP-11-016,
upper left corner logo image #1183062
with a certain data
556915 MAIN
11 Measures against the print Undefined error appeared when printing a certain data. TP-10-287,
error with a certain data Therefore, this was corrected. #1140708
554411 MAIN
12 Measures against the text Wrong letters in a larger font were printed when directly TP-11-055,
output failure when directly printing a certain PDF file. Therefore, this was corrected. KMA-D-1102-06
printing a certain PDF file
550328 MAIN
13 Measures against the drawing When a part of large size drawing was printed, it was not TP-070090
print failure printed. Therefore, this was corrected. NP-Z07031-2
556903 MAIN
14 Measures against the process The process lockup occurred when printing a certain PDF TP-10-252,
lockup when printing a certain file after the MacOS 10.6 Preview. Therefore, this was UTS-10-039
PDF file corrected.
556895 MAIN
15 Measures against the ---------------- TP-10-279
character pitch shift right after NP-Z10088
change of the resolution
556919 MAIN
16 Measures against the duplex Duplex output data was printed in simplex. Therefore, this TP-10-282
print failure was corrected. NP-Z10090
547593 MAIN
17 Measures against the FAX ---------------- TF-11-002
address search failure NP-Z11008
18 559892 MAIN
Measures against the print Printing failed and "PDFConversionError" report was output TP-10-190,
failure when directly printing a when directly printing a certain PDF file. Therefore, this was #1082064,
certain PDF file corrected.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
