Image preview - the first page of the document
>> Download SB-PCI-0251-A115_2 documenatation <<
Text preview - extract from the document
(Revised issue 2) (Page.1/6)
Service Bulletin Ref. No. PCI-0251(A115)
[Parts Change Information] March 8, 2012
Subject Part Change Information
FS-2000D, FS-3900DN, FS-4000DN, FS-6950DN, FS-2020D,
FS-3920DN, FS-4020DN, FS-6970DN, FS-2025D, FS-3925DN,
FS-4025DN, FS-6975DN, FS-C5100DN, FS-C5200DN,
Model
FS-C5300DN, FS-C5350DN, FS-C5400DN, FS-C8500DN,
FS-1120D, FS-1320D, FS-1370DN, FS-1116MFP, FS-1028MFP,
FS-1128MFP
This time, the description with (-->) was revised from the previous information.
The parts list errata were corrected, and the part numbers were added. (P5)
Topic
The following parts were changed.
P.2 <(For KME) Bundle of CD-ROM and the Installation Guide>
FS-2020D, FS-3920DN, FS-4020DN, FS-6970DN, FS-C5100DN, FS-C5200DN, FS-
C5300DN, FS-C5350DN, FS-C5400DN, FS-C8500DN
P.3-2 <(For KMKR) Change of the outer case>
FS-C5350DN
P.4-1 <(For KMA) Change of the switching regulator (service part)>
FS-1028MFP, FS-1128MFP
P.4-2
FS-1120D, FS-1320D
P.5-1
FS-2000D, FS-3900DN, FS-4000DN, FS-6950DN, FS-2020D, FS-3920DN, FS-4020DN,
FS-6970DN, FS-2025D, FS-3925DN, FS-4025DN, FS-6975DN
P.5-2
FS-1116MFP
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Revised issue 2) (Page.2/6)
Service Bulletin Ref. No. PCI-0251(A115)
[Parts Change Information] March 8, 2012
<(For KME) Bundle of CD-ROM and the Installation Guide --> From May 2010
production>
FS-2020D, FS-3920DN, FS-4020DN, FS-6970DN, FS-C5100DN, FS-C5200DN, FS-C5300DN,
FS-C5350DN, FS-C5400DN, FS-C8500DN
Upon the request by a sales company, CD-ROM, QUICK INSTALLATION GUIDE and SAFETY GUIDE, etc. are
now bundled at the production site, that were locally implemented on the sales company side before.
[CD-ROM]
[QUICK INSTALLATION GUIDE]
[SAFETY GUIDE]
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Revised issue 2) (Page.3/6)
Service Bulletin Ref. No. PCI-0251(A115)
[Parts Change Information] March 8, 2012
SEFETY GUIDE is commonly used with following models:
FS-2020D/FS-3920DN/FS-4020DN/FS-6970DN
FS-C5100DN/FS-C5200DN/FS-C5300DN/FS-C5400DN
FS-C8500DN/FS-3040MFP/FS-3140MFP
Model Name Specifications
FS-2020D KME From XEX0559670
FS-3920DN KME Under examination
FS-4020DN KME From XEZ0521472
FS-6970DN KME Under examination
Serial Nos. of the FS-C5100DN KME From XEU0541394
Affected Machines
FS-C5200DN KME From XEV0517857
FS-C5300DN KME From XEW0519895
FS-C5350DN KME From QVS0502547
FS-C5400DN KME From XAC0502015
FS-C8500DN KME From QXT0500669
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Revised issue 2) (Page.4/6)
Service Bulletin Ref. No. PCI-0251(A115)
[Parts Change Information] March 8, 2012
<(For KMKR) Change of the outer case --> From the first mass production >
FS-C5350DN
The illustration on the COUTER CASE was changed.
The number of the waste toner boxes was changed from 2 to 1.
[Old] [New]
<(For KMA) Change of the switching regulator (service part) --> After the stock of old
part is used up>
FS-1028MFP, FS-1128MFP
Due to the change of the SWITCHING REGULATOR for KMA specifications, the part code of the PARTS
SWITCHING REGULATOR 120V was changed for the parts handling reason.
Q'ty Com pati-
No. Old Part New Part Description bility SP Remarks
No. No.
Old New Old New
302H994290 302H994291 PARTS SWITCHING REGULATOR
1 1 1 O O O -
2H994290 2H9994291 120V SP
After the stock of old part is used up.>
FS-1120D, FS-1320D
In order to improve the assembly process, the shape of the GUIDE RETARD was changed.
The part code is not changed.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Revised issue 2) (Page.5/6)
Service Bulletin Ref. No. PCI-0251(A115)
[Parts Change Information] March 8, 2012
Length changed
From April 2010 production>
FS-2000D, FS-3900DN, FS-4000DN, FS-6950DN, FS-2020D, FS-3920DN, FS-4020DN, FS-
6970DN, FS-2025D, FS-3925DN, FS-4025DN, FS-6975DN
For common use with the new models, the shape of the COVER LEFT was changed.
Due to this change, the following parts were changed.
COVER LEFT
Height of rib was changed.
[Old] 3 mm; [New] 5 mm
Com pati-
Old Part New Part Q'ty bility
No. No. No. Description SP Remarks
Old New Old New
302J004061 302J004062
1 COVER LEFT 1 1 O O O -
2J004061 2J004062
302F904060 302F904061
2 COVER LEFT 1 1 O O O -
2F904060 2F904061
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Revised issue 2) (Page.6/6)
Service Bulletin Ref. No. PCI-0251(A115)
[Parts Change Information] March 8, 2012
FS-1116MFP
The Ref.No. marked on the illustration in the Parts List was corrected since they were reversed.
[Wrong] [Correct]
Fig. Ref. Part No. Description Fig. Ref. Part No. Description
(-->) (-->)
(-->) (-->)
42 302G470130 302G470110 UNIT PAPER SUPPORT
UNIT PAPER TRAY 42
2G470130 2G470110
9 9
(-->) (-->)
(-->) (-->)
43 302G470110 302G470130 UNIT PAPER TRAY
UNIT PAPER SUPPORT 43
2G470110 2G470130
FIG.9 MFP UNIT
The part with [O] in the SP column is a regular maintenance part. "+" Mark at the head of the description
indicates that it is a ccomponent part.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
