Image preview - the first page of the document
>> Download SB-2M4-0001-D056 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2M4-0001 (D056)
April 5, 2013
Subject Material Change of the Protection Sheet on the Contact Glass
FS-1020MFP, FS-1220MFP, FS-1120MFP, FS-1320MFP,
Model l:
FS-1025MFP, FS-1125MFP, FS-1325MFP
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: No particular problem is expected.
Serial Nos. of the Affected Machines: Please refer to the next page.
Topic
The PET film on the DP contact glass might be removed and scrapped as unnecessary packaging material at the
machine setup together with the protection sheet for the contact glass which is also made of the PET film and is the
transit package.
Therefore, the material of the protection sheet was changed in order to prevent the wrong disposal.
Content of Changes
The material of the protection sheet was changed from the transparent PET film to the white coating paper.
New protection sheet (to be disposed)
PET film on the DP contact glass
(Not to be disposed)
KYOCERA Document Solutions Europe
Customer Services & Support Division (TCSD)
(Page.2/2)
Service Bulletin Ref. No. 2M4-0001 (D056)
April 5, 2013
Model Destination Product Code Serial Number
FS-1120MFP KDE 1102M53NX0 NSR3301976
KDRU/KDE 1102M53RU0 NWB3303097
FS-1320MFP KDE (KDIS) 1102M53NL0 NZJ3302717
FS-1025MFP KDE 1102M63NX0 NSV3302675
KDRU/KDE 1102M63RU0 NWC3205283
FS-1125MFP KDE 1102M73NX0 Next production
KDRU/KDE 1102M73RU0 NWD3305388
FS-1325MFP KDE (KDIS) 1102M73NL0 NZK3306770
* The serial number information of FS-1020MFP/FS-1220MFP will not be available since these models do not use the PET film
on the DP contact glass.
